ABB TB805 3BSE008534R1 Bus Outlet | Replacement, Equivalent & Selection Guide
Technical Specifications
- Manufacturer: ABB
- Part Number: TB805
- Reference Number: 3BSE008534R1
- Description: Bus Outlet Module
- Product Series: Advant Controller / S800 I/O Series
- Function: Provides bus connection outlet for S800 I/O modules on Modulebus or PROFIBUS-DP networks
- Mounting: DIN rail compatible
- Weight: 40 g
- Communication Bus: Modulebus / PROFIBUS-DP
- Operating Temperature: 0°C to +55°C (standard industrial range)
- Compliance: CE marked; designed for use in ABB AC800M / AC800F / Advant OCS control systems
Compatible Replacement & Equivalent Models
The TB805 (3BSE008534R1) is a dedicated bus outlet for ABB S800 I/O. The following models may serve as functional equivalents or replacements depending on your system configuration:
- ABB TB806 – Extended bus outlet variant for larger I/O clusters
- ABB TB807 – Bus outlet with redundancy support
- ABB TB820V2 / 3BSE013208R1 – Modulebus Modem (upstream communication module, often paired with TB805)
- ABB TB840A / 3BSE037760R1 – PROFIBUS-DP bus interface, alternative for DP-based architectures
- ABB CI854A / 3BSE030220R1 – PROFIBUS-DP master interface for AC800M (system-level alternative)
Note: Always verify firmware version, bus protocol, and rack compatibility before substituting. Contact Konmask for pre-sales compatibility verification.
Why Choose the Original Model
- Guaranteed Compatibility: Factory-matched to ABB S800 I/O mechanical and electrical bus interface standards
- Firmware Integrity: No re-parameterization required when replacing like-for-like
- Reduced Commissioning Risk: Plug-and-play replacement minimizes downtime in live production environments
- Long-Term Support: ABB spare parts lifecycle support for Advant and AC800 platforms
- Traceability: Original part number 3BSE008534R1 ensures accurate BOM and maintenance records
Typical Applications
- ABB AC800M / AC800F distributed control system (DCS) I/O expansion
- Advant OCS (Operator Control Station) field I/O bus connections
- PROFIBUS-DP segment termination and outlet in process automation
- Power generation, oil & gas, pulp & paper, and chemical plant automation
- Retrofit and upgrade projects on legacy ABB Advant Controller 450/410 systems
System Compatibility
- Control Systems: ABB AC800M, AC800F, Advant Controller 450, Advant Controller 410
- I/O Platform: S800 I/O (AI810, AO810, DI810, DO810, etc.)
- Bus Protocol: Modulebus, PROFIBUS-DP
- Software: Compatible with ABB Control Builder M, Advant Builder
- Not compatible with: S900 I/O series, AC500 PLC platform, or third-party non-ABB bus systems without adaptation
Selection Guide
Use the following criteria to confirm TB805 3BSE008534R1 is the correct part for your application:
- Step 1 – Identify your control system: Confirm you are running AC800M, AC800F, or Advant Controller series.
- Step 2 – Verify bus protocol: TB805 supports Modulebus. If your segment uses PROFIBUS-DP exclusively, consider TB840A or CI854A.
- Step 3 – Check I/O cluster size: TB805 supports standard cluster configurations. For larger clusters, evaluate TB806 or TB807.
- Step 4 – Confirm redundancy requirements: TB805 is non-redundant. For redundant bus outlet needs, specify TB807.
- Step 5 – Review firmware baseline: Ensure your system firmware is compatible with the TB805 hardware revision in stock.
Quality Assurance & Sourcing
- All units sourced from authorized ABB distributors or verified industrial surplus channels
- Each unit undergoes visual inspection and functional verification prior to shipment
- Original packaging and labeling preserved where available
- Batch traceability records maintained for B2B procurement compliance
- Export documentation (commercial invoice, packing list, COO) available on request
How to Order
- Online: Add to cart directly on this page — secure checkout with bank transfer, PayPal, or TT wire
- Email RFQ: Send your BOM or part list to support@konmask.com
- Phone / WhatsApp: +0086 19859288691 (Mon–Sat, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
- MOQ: 1 piece — no minimum order quantity for standard stocking items
Replacement & Compatibility FAQ
Q: Can TB805 replace TB806 directly?
A: Not always. TB806 supports a larger I/O cluster. Verify your cluster node count before substituting.
Q: Is 3BSE008534R1 the only reference number for TB805?
A: Yes, 3BSE008534R1 is the primary ABB catalog reference. Some legacy documents may list it under earlier revision codes — contact us to cross-reference.
Q: Can I use TB805 on a PROFIBUS-DP-only segment?
A: TB805 is primarily a Modulebus outlet. For pure PROFIBUS-DP segments, TB840A or CI854A is recommended.
Q: Do you provide a warranty?
A: Yes — 90-day functional warranty on all units. Extended warranty available for volume orders.
Q: Can you source discontinued or obsolete ABB parts?
A: Yes. Konmask specializes in sourcing obsolete and hard-to-find industrial automation components. Submit an RFQ with your part number.
