Advantech UNO-1372G-E3AE Fanless Embedded Computer | Replacement, Equivalent & Selection Guide
The Advantech UNO-1372G-E3AE is a fanless, compact industrial box PC designed for demanding automation, machine vision, and edge computing applications. Built on the Intel® Atom™ E3845 quad-core processor, it delivers reliable performance in harsh industrial environments without active cooling. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | UNO-1372G-E3AE |
| Brand | Advantech |
| Series | UNO-1372G |
| Processor | Intel® Atom™ E3845, 1.91 GHz Quad-Core |
| Memory | 4 GB DDR3L SO-DIMM (max 8 GB) |
| Storage | mSATA SSD slot + CFast slot |
| OS Support | Windows 7/10 (32/64-bit), Linux |
| Display | VGA + HDMI dual display |
| Serial Ports | 4× RS-232/422/485 (COM1–COM4) |
| USB | 4× USB 3.0 |
| LAN | 2× GbE (Intel® i210) |
| Expansion | 1× Mini PCIe, 1× mSATA |
| Power Input | 9–36 VDC |
| Operating Temp | -20°C to 60°C |
| Cooling | Fanless (passive cooling) |
| Dimensions | 175 × 120 × 55 mm |
| Weight | Approx. 1.2 kg |
| Certifications | CE, FCC, UL |
Compatible Replacement & Equivalent Models
If the UNO-1372G-E3AE is unavailable or you are evaluating alternatives, the following models offer comparable functionality and form factor:
| Model | Brand | CPU | Key Difference | Compatibility |
|---|---|---|---|---|
| UNO-1372G-J0AE | Advantech | Intel® Celeron® J1900 | Different CPU variant, same platform | Direct drop-in |
| UNO-2271G-E22AE | Advantech | Intel® Atom™ E3826 | Dual-core, lower power | Functional equivalent |
| ARK-1123C-U4A1E | Advantech | Intel® Celeron® N3350 | Compact form, Apollo Lake | Functional equivalent |
| IPC-BX-E3845 | Axiomtek | Intel® Atom™ E3845 | Same CPU, different brand | Functional equivalent |
| eBOX560-880-FL | Axiomtek | Intel® Atom™ E3845 | Extended temp range | Functional equivalent |
| DS-1010 | Kontron | Intel® Atom™ E3845 | DIN-rail mount variant | Functional equivalent |
Note: Always verify I/O pinout, power requirements, and software drivers before substituting in a live system.
Why Choose the Original Model
- Proven platform stability: The UNO-1372G-E3AE has been deployed in thousands of industrial installations worldwide with a documented MTBF exceeding 50,000 hours.
- Advantech ecosystem support: Full compatibility with Advantech WISE-PaaS, ADAM I/O modules, and WebAccess SCADA software.
- Long-term availability: Advantech commits to extended product lifecycle support, reducing redesign risk for OEM customers.
- Fanless reliability: No moving parts means lower maintenance cost and suitability for dusty or vibration-prone environments.
- Wide voltage input: 9–36 VDC accommodates both 12 V and 24 V industrial power rails without additional converters.
Typical Applications
- Factory automation and machine control
- Machine vision and image processing
- Transportation and vehicle-mounted computing
- Building automation and energy management
- Edge gateway for IIoT data acquisition
- Kiosk and digital signage controllers
- Oil & gas remote monitoring stations
System Compatibility
The UNO-1372G-E3AE integrates seamlessly with the following systems and protocols:
- SCADA: Advantech WebAccess, Ignition, WinCC, iFIX
- PLC Communication: Modbus RTU/TCP, PROFINET, EtherNet/IP (via software stack)
- I/O Expansion: Advantech ADAM-4000 / ADAM-6000 series via RS-485 or Ethernet
- Cloud Platforms: Microsoft Azure IoT Hub, AWS IoT Greengrass, Advantech WISE-PaaS
- OS: Windows 10 IoT Enterprise, Ubuntu 20.04 LTS, Yocto Linux
Selection Guide
Use the criteria below to confirm the UNO-1372G-E3AE is the right choice, or to identify the best alternative:
| Requirement | Recommended Model |
|---|---|
| Quad-core Atom, fanless, -20~60°C, 4× COM | UNO-1372G-E3AE ✓ |
| Same platform, lower cost CPU | UNO-1372G-J0AE |
| Need dual-core, lower power consumption | UNO-2271G-E22AE |
| Need DIN-rail mount form factor | DS-1010 (Kontron) |
| Need extended temp (-40°C to 70°C) | eBOX560-880-FL (Axiomtek) |
| Need more PCIe expansion slots | ARK-3520L (Advantech) |
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified secondary market channels.
- Each unit undergoes incoming inspection: visual check, power-on test, and I/O functional verification.
- Original manufacturer packaging and documentation preserved where available.
- Traceability records maintained for every order.
- 30-day return policy for DOA (Dead on Arrival) units.
How to Order
- Confirm the part number: UNO-1372G-E3AE
- Specify required quantity and delivery timeline.
- Contact us via email or phone for bulk pricing and lead time.
- Receive proforma invoice → confirm payment → shipment with tracking.
- DHL / FedEx / UPS international express available; sea freight for large orders.
📧 [email protected] | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Is the UNO-1372G-E3AE still in production?
A: Advantech has transitioned this model to limited availability. Contact us to confirm current stock and lead time.
Q: Can I replace UNO-1372G-E3AE with UNO-1372G-J0AE directly?
A: Yes, the J0AE variant uses the same board and chassis. The CPU differs (Celeron J1900 vs Atom E3845), so verify your performance requirements before substituting.
Q: Does it support Windows 11?
A: The Atom E3845 does not meet Windows 11 TPM 2.0 and CPU requirements. Windows 10 IoT Enterprise LTSC is the recommended OS.
Q: What is the warranty?
A: We offer a 90-day warranty on all units sold through Konmask.com. Extended warranty available upon request.
Q: Can you supply accessories (power adapter, DIN-rail kit, antennas)?
A: Yes. Please specify your requirements when placing an order.
