Industrial Motion Control Solution – SIEMENS 6AV7260-5GA10-0BX0 | SIMATIC Panel PC 677B
Where This Product Is Used
The SIEMENS 6AV7260-5GA10-0BX0 (S/N: 5E32600250) is a SIMATIC Panel PC 677B — a ruggedized industrial panel PC with integrated motion control capabilities. It is deployed across demanding industrial environments including:
- CNC Machine Tools – Coordinating multi-axis servo motion with real-time HMI visualization on the shop floor
- Automotive Assembly Lines – Managing robotic arm sequencing, conveyor synchronization, and quality inspection stations
- Packaging & Filling Machines – High-speed motion profiling for cam-based and electronic gearing applications
- Printing & Converting Equipment – Tension control, register mark detection, and web guiding with sub-millisecond response
- Semiconductor & Electronics Manufacturing – Precision pick-and-place, wafer handling, and cleanroom-compatible panel PC integration
- Material Handling & Logistics – Crane control, automated storage/retrieval systems (AS/RS), and AGV fleet management
- Power Generation & Utilities – Turbine governor control, pump station automation, and substation HMI panels
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | SIEMENS AG |
| Part Number | 6AV7260-5GA10-0BX0 |
| Serial Number | 5E32600250 |
| Product Family | SIMATIC Panel PC 677B |
| Product Type | Industrial Panel PC / Motion Controller |
| Form Factor | Panel-mount, front-IP65 rated |
| Display | 15″ TFT LCD, 1024×768 (XGA) |
| Processor | Intel Core 2 Duo / Celeron (generation-dependent) |
| Operating System | Windows XP Embedded / Windows 7 (factory configured) |
| Expansion Slots | PCI / PCIe slots for motion control cards |
| Communication | PROFIBUS, PROFINET, Ethernet, USB, RS-232/422/485 |
| Power Supply | 24 V DC (SELV) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +60 °C |
| Protection Rating | IP65 (front panel) |
| Weight | 19 kg |
| Certifications | CE, UL, cULus, ATEX (zone-dependent) |
Why Engineers Specify This Model
- Unified HMI + Motion Platform – Eliminates the need for a separate IPC and HMI terminal; one device handles visualization, logic, and motion coordination
- SIMATIC Ecosystem Integration – Native compatibility with STEP 7, TIA Portal, WinCC, and SIMOTION Scout engineering tools
- Rugged Industrial Design – IP65 front panel, vibration-resistant construction, and wide operating temperature range for harsh factory environments
- Expandable Architecture – PCI/PCIe slots allow integration of SIMOTION D motion control cards, fieldbus adapters, and I/O expansion modules
- Long-Term Availability – SIEMENS industrial PCs are supported with spare parts and firmware for 10+ years post-production
- Proven Reliability – Deployed in thousands of installations globally across automotive, food & beverage, and heavy industry sectors
Complete System Bill of Materials
For a complete SIMATIC Panel PC 677B motion control system, engineers typically specify the following companion components:
- SIMOTION D4x5-2 – Motion control module (PCIe) for multi-axis servo coordination
- SINAMICS S120 – Servo drive system for axis power and feedback
- 1FK7 / 1FT7 Servo Motors – SIEMENS synchronous servo motors matched to S120 drives
- SCALANCE X-200 – Industrial Ethernet switch for PROFINET network backbone
- SITOP PSU300S – 24 V DC stabilized power supply for panel PC and I/O
- ET 200SP / ET 200M – Distributed I/O stations for remote field signals
- SIMATIC S7-1500 – Optional PLC for safety and process logic offloading
Contact support@konmask.com for a complete BOM quotation tailored to your application.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU
- UL / cULus Listed – Recognized for use in North American industrial installations
- IEC 61131-3 – Programming environment supports all five standard PLC languages
- IEC 62061 / ISO 13849 – Safety function integration available via SIMOTION safety options
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
- PROFINET Certified – PI (PROFIBUS & PROFINET International) conformance tested
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS unit undergoes a structured verification process before shipment:
- Serial Number Authentication – Cross-referenced against SIEMENS production records and authorized distributor databases
- Physical Inspection – Label integrity, connector condition, housing damage assessment, and firmware version verification
- Functional Power-On Test – BIOS POST, OS boot verification, and communication port continuity check
- Documentation Package – Original datasheet, EU Declaration of Conformity, and Konmask inspection report included
We source exclusively from authorized SIEMENS distributors, OEM decommissions, and certified industrial surplus channels. Counterfeit product is never knowingly listed.
How to Source This Part
- Request a Quote – Email support@konmask.com with your project requirements and required delivery date
- Receive Stock Confirmation – We confirm availability, condition grade (New / Refurbished / Surplus), and lead time within 24 hours
- Review Inspection Report – We provide photos, serial number verification, and test results before payment
- Secure Payment – T/T bank transfer, PayPal, or trade assurance accepted; proforma invoice issued
- Tracked Global Shipping – DHL / FedEx / UPS express with full customs documentation (HS Code: 8537.10); delivery to 150+ countries
Application-Specific FAQ
Q: Is the 6AV7260-5GA10-0BX0 still in production by SIEMENS?
A: This model is in the mature/legacy phase. Konmask.com maintains surplus stock to support ongoing maintenance and replacement needs. Contact us for long-term supply agreements.
Q: Can this Panel PC run TIA Portal and WinCC simultaneously?
A: Yes. The Panel PC 677B is designed to run SIEMENS engineering and runtime software concurrently, subject to the installed CPU and RAM configuration.
Q: What is the warranty on this unit?
A: Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available upon request.
Q: Do you provide export documentation for customs clearance?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and HS code declaration (8537.10) for all international shipments.
Q: Can you supply multiple units for a production line retrofit?
A: Yes. We specialize in bulk procurement for OEM retrofits and system integrators. Contact us for volume pricing.
