Allen-Bradley 150-F135NBDB SMC Flex Smart Motor Controller | Replacement, Equivalent & Selection Guide
The Allen-Bradley 150-F135NBDB is a high-performance SMC Flex Smart Motor Controller manufactured by Rockwell Automation. Rated at 135A / 480V AC, it delivers advanced soft-start and soft-stop control for three-phase AC induction motors, reducing mechanical stress and extending motor life in demanding industrial environments.
Konmask.com supplies genuine and compatible 150-F135NBDB units with full traceability, supporting B2B buyers worldwide with fast quotation and reliable sourcing.
Technical Specifications
- Part Number: 150-F135NBDB
- Series: SMC Flex
- Manufacturer: Allen-Bradley / Rockwell Automation
- Motor Current Rating: 135A (Full Load)
- Supply Voltage: 200–480V AC, 3-Phase, 50/60 Hz
- Control Voltage: 100–240V AC
- Starting Method: Soft Start / Soft Stop
- Communication: DeviceNet (built-in)
- Protection Class: IP20 (open type)
- Bypass Contactor: Internal bypass included
- Overload Protection: Electronic, Class 10/15/20/30 selectable
- Enclosure: Open / Panel Mount
- Catalog Number Breakdown: 150 = SMC Flex | F = Frame F | 135 = 135A | N = No options | B = Internal bypass | D = DeviceNet | B = 100–240V control
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or alternatives to the 150-F135NBDB. Always verify electrical ratings and communication protocol before substitution.
- 150-F135NBD – Same frame, without internal bypass; requires external bypass contactor
- 150-F135NBDB-S – With Safe-Off option; suitable for SIL 2 / PLd safety applications
- 150-F180NBDB – Next frame up (180A); use when motor FLA exceeds 135A
- 150-F108NBDB – Lower rating (108A); suitable for smaller motor loads
- SMC-3 / SMC-50 – Older Allen-Bradley SMC series; not direct drop-in, requires wiring adaptation
- Siemens 3RW44 – Third-party equivalent soft starter; different communication protocol
- ABB PSE / PSTB Series – Alternative brand soft starters; verify bypass and control voltage compatibility
- Schneider Electric Altistart 48 – Comparable soft starter; different mounting and wiring
Why Choose the Original 150-F135NBDB
- ✅ Native DeviceNet integration – seamless communication with Allen-Bradley PLCs and ControlLogix/CompactLogix systems
- ✅ Internal bypass contactor – eliminates need for external bypass, reducing panel space and wiring complexity
- ✅ Advanced motor protection – electronic overload, phase loss, stall, and jam detection built-in
- ✅ Flexible control modes – current limit start, voltage ramp, torque control, and pump control modes
- ✅ Rockwell ecosystem compatibility – fully supported by Studio 5000, RSLogix 5000, and FactoryTalk software
- ✅ Proven reliability – widely deployed in water/wastewater, HVAC, mining, and manufacturing industries
Typical Applications
- Pumps and compressors (water treatment, HVAC, oil & gas)
- Conveyors and material handling systems
- Fans and blowers in industrial ventilation
- Mixers and agitators in food & beverage processing
- Crushers and mills in mining and aggregate industries
- Large HVAC chillers and cooling tower fans
System Compatibility
- PLC Platforms: ControlLogix, CompactLogix, MicroLogix (via DeviceNet scanner)
- Network: DeviceNet (built-in); optional EtherNet/IP with 150-SM4 communication module
- Software: Studio 5000 Logix Designer, RSNetWorx for DeviceNet, FactoryTalk View
- Motor Types: Standard 3-phase AC induction motors, NEMA Design A/B
- Bypass: Internal bypass rated for continuous full-voltage operation after soft start
Selection Guide
Use the table below to select the correct SMC Flex model for your application:
| Parameter | Specification | Recommended Model |
|---|---|---|
| Motor FLA ≤ 108A, 480V, DeviceNet, bypass | 108A / 480V | 150-F108NBDB |
| Motor FLA ≤ 135A, 480V, DeviceNet, bypass | 135A / 480V | 150-F135NBDB ✓ |
| Motor FLA ≤ 180A, 480V, DeviceNet, bypass | 180A / 480V | 150-F180NBDB |
| Safety application (SIL 2 / PLd required) | 135A / 480V + Safe-Off | 150-F135NBDB-S |
| No network communication required | 135A / 480V, standalone | 150-F135NB |
Note: Always confirm motor nameplate FLA and service factor before selecting controller rating. Derate for high-altitude or high-ambient-temperature installations per Rockwell publication 150-UM009.
Quality Assurance & Sourcing
- 🔍 Traceability: All units supplied with verifiable lot codes and manufacturer documentation where available
- 📦 Packaging: Original OEM packaging or anti-static protective packaging for surplus stock
- 🏭 Source: Authorized distributor stock, factory-sealed surplus, and certified refurbished options available
- ✔️ Inspection: Pre-shipment functional and visual inspection on all units
- 🌐 Global Shipping: DHL / FedEx / UPS express available; export documentation provided
How to Order
- Confirm your motor FLA, supply voltage, and required communication protocol
- Add 150-F135NBDB to cart, or contact us for bulk/project pricing
- Provide your shipping address and preferred freight method at checkout
- Receive order confirmation and tracking within 1 business day
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://konmask.com
Replacement & Compatibility FAQ
Q: Can I replace a 150-F135NBD with a 150-F135NBDB?
A: Yes. The NBDB adds an internal bypass contactor. If your panel already has an external bypass, you can use either model, but the NBDB simplifies wiring.
Q: Is the 150-F135NBDB compatible with EtherNet/IP?
A: Not natively. It uses DeviceNet. Add the 150-SM4 EtherNet/IP communication module for IP-based network integration.
Q: Can a Siemens 3RW44 replace the 150-F135NBDB directly?
A: Electrically comparable, but the DeviceNet communication and Rockwell software integration will not carry over. Significant reprogramming and wiring changes are required.
Q: What is the warranty on units from Konmask.com?
A: We offer a 12-month warranty on all new OEM units and a 6-month warranty on certified surplus/refurbished units.
Q: Do you provide installation support?
A: Yes. Our technical team can provide wiring diagrams, parameter setup guidance, and commissioning support via email or video call.
