Allen-Bradley 1769-OF4VI 4-Channel Analog Output Module | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1769-OF4VI is a 4-channel analog output module designed for the Rockwell Automation CompactLogix platform. It delivers selectable voltage (0–10 V / ±10 V) and current (0–20 mA / 4–20 mA) outputs, making it a versatile choice for precise process control in industrial automation systems. At Konmask.com, we supply genuine and equivalent modules with full traceability to support your MRO and project procurement needs.
Technical Specifications
- Part Number: 1769-OF4VI
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: Compact I/O (1769)
- Output Channels: 4 (individually configurable)
- Output Type: Voltage & Current (selectable per channel)
- Voltage Output Range: 0–10 VDC, ±10 VDC
- Current Output Range: 0–20 mA, 4–20 mA
- Supply Voltage: 24–28 VDC
- Resolution: 16-bit (voltage), 15-bit + sign (current)
- Backplane Current Draw: 75 mA @ 5 VDC; 0 mA @ 24 VDC
- Operating Temperature: 0–60 °C (32–140 °F)
- Dimensions (H × W × D): 118 × 35 × 87 mm
- Weight: ~0.9 kg
- Certifications: UL, CE, RCM, EAC
- Communication: CompactLogix backplane (1769 bus)
Compatible Replacement & Equivalent Models
If the 1769-OF4VI is unavailable or you need a cost-effective alternative, the following models offer compatible functionality:
- 1769-OF4 — Standard 4-ch analog output (current only, 4–20 mA); same 1769 form factor
- 1769-OF2 — 2-channel analog output; suitable for smaller I/O count applications
- 1769-OF8C — 8-channel current output; ideal for expanded channel requirements
- 1769-OF8V — 8-channel voltage output; direct voltage-only replacement with more channels
- Siemens 6ES7135-4GB01-0AB0 — ET 200S analog output; cross-brand equivalent for Siemens PROFINET systems
- Mitsubishi Q64DAN — MELSEC-Q 4-ch analog output; cross-brand equivalent for Mitsubishi Q-series PLCs
Note: Cross-brand replacements require hardware and software reconfiguration. Contact our engineers for a compatibility assessment.
Why Choose the Original 1769-OF4VI
- Native integration with Studio 5000 Logix Designer — zero additional configuration overhead
- Simultaneous voltage and current output on the same module — reduces slot count and wiring complexity
- 16-bit resolution ensures high-accuracy setpoint control for valves, drives, and positioners
- Hot-swap capable within the CompactLogix chassis — minimizes downtime during maintenance
- Full Rockwell Automation firmware and diagnostic support via RSLinx / FactoryTalk
Typical Applications
- Analog setpoint control for variable-frequency drives (VFDs) and servo amplifiers
- Process control loops: flow, pressure, temperature, and level regulation
- Valve positioner and actuator control in oil & gas, water treatment, and chemical plants
- Machine automation and motion coordination in OEM equipment
- Building automation and HVAC control systems
System Compatibility
- Compatible Controllers: 1769-L16ER, 1769-L18ER, 1769-L24ER, 1769-L27ERM, 1769-L30ER, 1769-L33ER, 1769-L36ERM, and all CompactLogix 5370/5380 controllers
- Bus: 1769 Compact I/O backplane
- Software: Studio 5000 Logix Designer v21+, RSLogix 5000 v20+
- Max Modules per System: Up to 30 (left-side bank) depending on controller model
Selection Guide
Use the table below to select the right analog output module for your application:
| Model | Channels | Output Type | Resolution | Best For |
|---|---|---|---|---|
| 1769-OF4VI | 4 | Voltage + Current | 16-bit | Mixed V/I applications, high accuracy |
| 1769-OF4 | 4 | Current only | 13-bit | Standard 4–20 mA loops |
| 1769-OF2 | 2 | Voltage + Current | 16-bit | Low channel count, space-saving |
| 1769-OF8C | 8 | Current only | 16-bit | High-density current output |
| 1769-OF8V | 8 | Voltage only | 16-bit | High-density voltage output |
Quality Assurance & Sourcing
- Genuine OEM: Sourced directly from authorized Rockwell Automation distributors with full traceability
- Inspection: Every unit undergoes visual, functional, and firmware-version verification before shipment
- Packaging: Original anti-static packaging with factory seals preserved where applicable
- Warranty: 12-month replacement warranty on all units supplied by Konmask.com
- Documentation: Certificate of conformance and test report available on request
How to Order
- Confirm your controller model and available 1769 bus slots
- Verify required output type (voltage, current, or mixed) and channel count
- Add 1769-OF4VI to cart or contact us for bulk/project pricing
- Provide your PO number, delivery address, and any special requirements
- Receive order confirmation with lead time and tracking within 24 hours
📧 Email: support@konmask.com | 📞 Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can the 1769-OF4VI replace the 1769-OF4 directly?
A: Yes, it is a drop-in slot replacement. However, you must update the I/O configuration in Studio 5000 to reflect the new module type and reconfigure channel output modes.
Q: Is the 1769-OF4VI compatible with MicroLogix controllers?
A: No. The 1769 Compact I/O series is designed exclusively for CompactLogix controllers. MicroLogix uses the 1762 (MicroLogix 1200) or 1766 (MicroLogix 1400) I/O bus.
Q: What is the difference between 1769-OF4VI and 1769-OF4V?
A: The 1769-OF4VI supports both voltage and current outputs per channel. The 1769-OF4V is voltage-output only. Choose 1769-OF4VI for maximum flexibility.
Q: Can I mix voltage and current outputs on the same 1769-OF4VI module?
A: Yes. Each of the 4 channels can be independently configured as voltage or current output via software.
Q: Do you supply refurbished units?
A: We supply both new OEM and certified-refurbished units. All refurbished units are clearly labeled and carry the same 12-month warranty.
