Allen-Bradley 1783-ETAP1F EtherNet/IP Tap – Stratix Network TAP Series
Imagine a critical production line where engineers need to diagnose intermittent network faults on a live EtherNet/IP segment — but every diagnostic tool they connect disrupts traffic, triggers nuisance faults, or forces a costly line shutdown. Without a passive network tap, your maintenance team is flying blind: packet captures are impossible without interruption, root-cause analysis drags on for days, and unplanned downtime compounds. The Allen-Bradley 1783-ETAP1F eliminates this dilemma entirely by providing a transparent, always-on monitoring access point that never touches the live data stream.
The 1783-ETAP1F occupies a precise niche within Rockwell Automation’s Stratix EtherNet/IP TAP family — it is engineered specifically for full-duplex, copper-media EtherNet/IP segments operating at 10/100 Mbps. As industrial networks migrate toward converged architectures under the Purdue Model and IEC 62443 security frameworks, passive taps have become indispensable infrastructure in smart manufacturing, oil & gas, and automotive assembly plants worldwide. The 1783-ETAP1F is the Rockwell-native answer to that demand, fully integrated with Studio 5000, FactoryTalk, and the broader Connected Enterprise ecosystem.
Technical Specifications
- Part Number: 1783-ETAP1F
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: Stratix EtherNet/IP TAP
- Media Type: Copper (RJ45)
- Network Speed: 10/100 Mbps, Full-Duplex
- Protocol: EtherNet/IP (CIP)
- Tap Type: Passive, non-intrusive network tap
- Monitor Port: 1× dedicated monitor/SPAN port
- Power Supply: 24V DC (redundant input capable)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Enclosure Rating: IP20 (panel-mount)
- Certifications: UL, CE, cULus
- Mounting: DIN rail
- Weight: Approx. 1,200 g (with packaging)
Note: Specifications are based on published Rockwell Automation documentation. Always verify against the official product bulletin before final engineering design.
Key Features & Benefits
- Zero-Impact Monitoring: Passive tap architecture copies traffic to the monitor port without injecting any packets into the live network — production continuity is guaranteed.
- Full-Duplex Capture: Simultaneously captures both transmit and receive streams, giving network engineers complete visibility into bidirectional EtherNet/IP traffic.
- Plug-and-Play Integration: Recognized natively by Rockwell Automation’s FactoryTalk Network Manager and Studio 5000 Logix Designer, reducing commissioning time.
- Fail-Safe Design: In the event of power loss, the tap maintains the network link between the two inline ports — no single point of failure for your control network.
- DIN Rail Mounting: Standard 35 mm DIN rail form factor fits directly into existing control panel layouts without additional hardware.
- Redundant Power Input: Dual 24V DC inputs support redundant power architectures for high-availability installations.
- Compact Footprint: Minimal panel space consumption, ideal for retrofit projects where cabinet real estate is limited.
Industry & Equipment Applications
- Automotive Manufacturing: Monitoring EtherNet/IP segments connecting ControlLogix PLCs to robot controllers and vision systems on assembly lines.
- Oil & Gas: Non-intrusive diagnostics on SIL-rated control networks where any active intervention requires a management-of-change process.
- Food & Beverage: Capturing network traffic for OEE analysis and predictive maintenance without halting hygienic production environments.
- Pharmaceutical: Supporting 21 CFR Part 11 audit trails by enabling passive packet logging on validated control networks.
- Water & Wastewater: Remote diagnostics on distributed SCADA networks where on-site access is infrequent and downtime is unacceptable.
- Discrete Manufacturing: Troubleshooting intermittent CIP connection timeouts between CompactLogix controllers and distributed I/O modules.
System Integration & Compatible Parts
The 1783-ETAP1F is designed to operate seamlessly within Rockwell Automation’s Connected Enterprise architecture. Typical companion components include:
- Managed Switches: Stratix 5700 (1783-BMS series), Stratix 5400 (1783-HMS series)
- Controllers: ControlLogix 5580 (1756-L8x), CompactLogix 5380 (5069-L3x)
- Network Analysis Tools: Wireshark with EtherNet/IP dissector, FactoryTalk Network Manager
- Power Supplies: 1606-XLP series 24V DC power supplies
- Related TAP Models: 1783-ETAP, 1783-ETAP2F (fiber variant)
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 1783-ETAP1F unit undergoes a rigorous multi-stage verification process before shipment:
- Source Verification: Units are sourced exclusively from authorized distributors and verified supply chains with full traceability documentation.
- Visual Inspection: Each unit is inspected for physical integrity, label authenticity, and correct firmware revision markings.
- Functional Check: Where applicable, units are powered on and port-link status is verified prior to packaging.
- Secure Packaging: Anti-static packaging with moisture barrier bags and shock-absorbing foam inserts protect units during international transit.
- Documentation: Certificate of conformance and original manufacturer documentation are included with every shipment upon request.
How to Order
- Submit your inquiry via the “Request a Quote” button or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our technical team will confirm availability, lead time, and pricing within 24 business hours.
- Upon agreement, we issue a proforma invoice and arrange secure payment via T/T, PayPal, or other agreed methods.
- Units are shipped with full tracking and export documentation (commercial invoice, packing list, COO).
Why Choose Konmask.com?
- ✅ Industrial Automation Specialists: We focus exclusively on PLC, DCS, and industrial network components — not a generalist marketplace.
- ✅ Global Export Experience: Serving buyers in 40+ countries with compliant export documentation and reliable logistics partners.
- ✅ Technical Pre-Sales Support: Our engineers can advise on compatibility, firmware versions, and system integration before you commit to a purchase.
- ✅ Competitive Lead Times: Extensive supplier network enables fast sourcing even for discontinued or long-lead Rockwell Automation parts.
- ✅ Transparent Communication: Real-time order status updates and dedicated account management for repeat buyers.
Frequently Asked Questions
Q: Does the 1783-ETAP1F affect network performance or introduce latency?
A: No. The 1783-ETAP1F is a passive tap — it copies traffic to the monitor port optically/electrically without any active processing in the data path. There is zero added latency on the inline network segment.
Q: What happens to the network if the 1783-ETAP1F loses power?
A: The inline network link between the two main ports is maintained even without power. The monitor port output will cease, but the production network remains unaffected.
Q: Is the 1783-ETAP1F compatible with Gigabit EtherNet/IP networks?
A: The 1783-ETAP1F supports 10/100 Mbps copper segments. For Gigabit segments, consult Rockwell Automation’s current TAP portfolio for the appropriate model.
Q: Can Konmask.com supply the 1783-ETAP1F if it is listed as discontinued?
A: Yes. We specialize in sourcing both current and legacy Rockwell Automation components. Contact us with your requirements and we will advise on availability and alternatives.
Q: What certifications does the 1783-ETAP1F carry?
A: The unit carries UL, cULus, and CE certifications. Please refer to the official Rockwell Automation product bulletin for the complete certification list applicable to your region.
