Allen-Bradley 193-ESM-IG-30A-T – Ethernet/IP Smart Motor Controller I/O Expansion Module | E3 Plus Platform
Engineering Background
The Allen-Bradley 193-ESM-IG-30A-T is a dedicated I/O expansion module engineered for the E3 Plus Electronic Overload Relay platform. Designed by Rockwell Automation, this module extends the native I/O capability of the E3 Plus relay by adding isolated digital inputs and outputs accessible over an Ethernet/IP network — enabling seamless integration into modern ControlLogix, CompactLogix, and GuardLogix control architectures without additional gateway hardware.
Product Positioning
Targeted at OEM machine builders and plant engineers who require deterministic, network-transparent motor protection with distributed I/O expansion, the 193-ESM-IG-30A-T eliminates the need for standalone I/O modules in motor control center (MCC) applications. Its compact DIN-rail form factor and plug-in connectivity to the E3 Plus relay make it the preferred choice for high-density MCC panel designs where space and wiring cost are critical constraints.
Complete Technical Specifications
- Catalog Number: 193-ESM-IG-30A-T
- Series: E3 Plus Electronic Overload Relay Expansion
- Manufacturer: Allen-Bradley / Rockwell Automation
- Module Type: Ethernet/IP Smart Motor Controller I/O Expansion Module
- Current Rating: 30 A
- Communication Protocol: Ethernet/IP (IEEE 802.3)
- Digital Inputs: Isolated digital inputs (24 V DC)
- Digital Outputs: Isolated digital outputs
- Supply Voltage: 24 V DC (via E3 Plus relay bus)
- Isolation: Galvanically isolated I/O channels
- Mounting: Direct plug-in to E3 Plus relay (no DIN rail adapter required)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: -40 °C to +85 °C
- Relative Humidity: 5% to 95% non-condensing
- Protection Rating: IP20
- Certifications: UL, CE, RoHS
- Weight: Approx. 500 g
- Country of Origin: United States
Proven Application Environments
- Motor Control Centers (MCC) with Ethernet/IP backbone
- Pump and fan control panels requiring remote I/O monitoring
- Conveyor and material handling systems integrated with ControlLogix PLCs
- HVAC and building automation motor protection applications
- Water/wastewater treatment plant motor management
- Oil & gas upstream and midstream motor control panels
- Automotive assembly line motor protection with Studio 5000 integration
Engineering Advantages
- Native Ethernet/IP: Direct integration with Rockwell Automation Studio 5000 / RSLogix 5000 — no EDS file workarounds required.
- Isolated I/O Channels: Galvanic isolation prevents ground loop interference in noisy industrial environments.
- Plug-and-Play Expansion: Mounts directly onto the E3 Plus relay without additional wiring harnesses, reducing panel assembly time by up to 40%.
- Deterministic Network Performance: Ethernet/IP CIP messaging ensures sub-10 ms I/O update rates for time-critical motor protection logic.
- Compact Footprint: Minimal panel real estate consumption — ideal for high-density MCC designs.
- Diagnostic Transparency: Exposes motor current, trip history, and I/O status directly to the PLC tag database for predictive maintenance integration.
System Architecture & Signal Flow
The 193-ESM-IG-30A-T connects directly to the expansion port of the E3 Plus Electronic Overload Relay (catalog series 193-EC*). The module bridges the relay’s internal motor protection data — including current measurement, trip status, and thermal model state — with the plant’s Ethernet/IP network. The PLC (ControlLogix / CompactLogix) communicates with the module via Class 1 implicit I/O messaging, receiving real-time motor status and sending output commands within a single network scan. Isolated digital inputs on the module accept field device signals (e.g., limit switches, pressure switches) and forward them to the PLC tag database without additional I/O modules.
Signal Flow Summary: Field Device → Isolated Digital Input → E3 Plus Internal Bus → Ethernet/IP Network → PLC I/O Tag → Studio 5000 Logic
Sourcing & Quality Verification
- All units sourced from authorized Rockwell Automation distribution channels or verified surplus with full traceability documentation.
- Each module undergoes incoming inspection: visual check, label verification (date code, series letter), and functional power-on test where applicable.
- Counterfeit risk mitigation: holographic Rockwell Automation labels, catalog number laser engraving, and PCB revision markings are verified against Rockwell’s published specifications.
- Packaging: original Rockwell Automation anti-static bag and box where available; otherwise repackaged in ESD-safe materials with inspection report included.
- Warranty: 12-month Konmask.com warranty covering manufacturing defects.
Procurement Process
- Step 1: Confirm compatibility — verify your E3 Plus relay catalog number supports the ESM-IG expansion module (consult Rockwell Publication 193-UM002).
- Step 2: Submit RFQ or place order directly via Konmask.com product page.
- Step 3: Receive order confirmation with lead time and shipping details within 1 business day.
- Step 4: Shipment with tracking number; typical delivery 3–7 business days internationally.
- Step 5: Post-delivery technical support available via support@konmask.com or +0086 19859288691.
Technical FAQ
Q: Is the 193-ESM-IG-30A-T compatible with all E3 Plus relay variants?
A: The ESM-IG expansion module is compatible with E3 Plus relays in the 193-EC* series. Verify the specific relay catalog number against Rockwell Publication 193-UM002 for confirmed compatibility.
Q: Can this module be used with a CompactLogix controller?
A: Yes. The module communicates via standard Ethernet/IP CIP protocol and is fully compatible with CompactLogix, ControlLogix, and GuardLogix platforms running Studio 5000 Logix Designer.
Q: What is the maximum cable length for the Ethernet connection?
A: Standard IEEE 802.3 Ethernet — up to 100 m per segment using Cat5e or Cat6 cable. Fiber optic media converters can extend this for larger plant layouts.
Q: Does the module support explicit messaging (MSG instruction)?
A: Yes. In addition to Class 1 implicit I/O, the module supports Class 3 explicit messaging for configuration and diagnostic reads from the PLC ladder logic.
Q: What happens to the outputs if the Ethernet connection is lost?
A: The module enters a configurable fault state — outputs can be set to hold last state or de-energize, depending on the connection configuration in Studio 5000.
