Engineering Background
Applied Materials (AMAT) is the world’s leading supplier of semiconductor manufacturing equipment, serving fabs across logic, memory, and advanced packaging segments. The 0100-20077 PCB Assembly (cross-referenced as 810-800256-017 and 0190-34513) is an OEM-grade printed circuit board assembly designed for integration into AMAT’s precision deposition and etch platforms. This board serves as a critical control or signal-processing node within the equipment’s subsystem architecture.
Product Positioning
Sourced and verified by Konmask.com, this PCB Assembly is positioned as a direct OEM replacement for maintenance engineers and procurement teams managing AMAT equipment uptime. It eliminates the lead-time risk associated with new OEM orders and provides a cost-effective alternative without compromising system integrity or process repeatability.
Complete Technical Specifications
| Manufacturer | Applied Materials (AMAT) |
| Primary Part Number | 0100-20077 |
| Cross Reference #1 | 810-800256-017 |
| Cross Reference #2 | 0190-34513 |
| Description | PCB Assembly (Printed Circuit Board Assembly) |
| Component Category | Control / Signal Processing Board |
| Equipment Platform | Applied Materials CVD / Etch / Process Systems |
| Country of Origin | United States |
| Condition | Refurbished / Surplus OEM (specify upon inquiry) |
| Warranty | Available – contact for terms |
| Lead Time | Subject to stock availability – contact for confirmation |
Proven Application Environments
- Applied Materials CVD (Chemical Vapor Deposition) systems – thin-film deposition control
- Applied Materials Etch platforms – plasma process signal management
- Semiconductor wafer fabrication lines (200mm / 300mm fabs)
- Advanced packaging and back-end-of-line (BEOL) equipment
- Fab maintenance and scheduled preventive maintenance (PM) programs
- Emergency equipment recovery and unplanned downtime response
Engineering Advantages
- OEM Part Numbers Verified: All three part numbers (0100-20077, 810-800256-017, 0190-34513) cross-referenced and confirmed as equivalent assemblies.
- Drop-in Replacement: Designed to match original AMAT mechanical and electrical specifications – no field modification required.
- Reduced Downtime Risk: Immediate availability from Konmask inventory reduces fab downtime versus standard OEM procurement lead times.
- Traceability: Each unit is documented with sourcing records to support fab quality and audit requirements.
- Cost Efficiency: Surplus and refurbished OEM stock provides significant cost savings versus new OEM pricing while maintaining functional equivalence.
System Architecture & Signal Flow
As a PCB Assembly within the AMAT equipment ecosystem, the 0100-20077 board interfaces with the system’s main controller or subsystem bus. Typical functional roles for this class of assembly include:
- I/O signal conditioning and distribution to process actuators or sensors
- Power regulation and distribution to downstream board-level components
- Communication bridging between the equipment’s host controller and field-level hardware
- Interlock and safety logic processing within the equipment’s control hierarchy
Note: Exact signal flow and pin mapping should be confirmed against the applicable AMAT equipment service manual for the target platform revision.
Sourcing & Quality Verification
- All units sourced through verified industrial surplus and OEM-authorized channels
- Pre-shipment visual and functional inspection performed where applicable
- Packaging compliant with ESD (electrostatic discharge) protection standards for PCB assemblies
- Documentation available upon request: sourcing records, inspection reports, and part number cross-reference certificates
- Konmask.com maintains a curated inventory of AMAT and multi-brand semiconductor spare parts with documented chain of custody
Procurement Process
- Inquiry: Submit your part number, quantity, and target delivery date via email or phone.
- Stock Confirmation: Konmask confirms availability, condition, and lead time within 1 business day.
- Quotation: Formal quotation issued with pricing, warranty terms, and shipping options.
- Order & Payment: Purchase order accepted; payment via T/T, wire transfer, or agreed terms.
- Shipment: ESD-safe packaging, commercial invoice, and packing list provided. DHL / FedEx / freight options available.
- After-Sales: Technical support and warranty claims handled directly by Konmask engineering team.
Technical FAQ
Q: Are part numbers 0100-20077, 810-800256-017, and 0190-34513 interchangeable?
A: Yes. These are AMAT’s internal cross-reference numbers for the same PCB Assembly. All three designations refer to the same physical assembly and are used interchangeably across different AMAT documentation revisions.
Q: What equipment platforms is this board compatible with?
A: This assembly is associated with Applied Materials process equipment platforms. Please provide your equipment model and serial number when inquiring to confirm compatibility with your specific system revision.
Q: Is a warranty provided?
A: Warranty terms are available and vary by unit condition (refurbished vs. tested surplus). Contact Konmask for specific warranty coverage applicable to your order.
Q: Can you provide an ESD-safe shipment?
A: Yes. All PCB assemblies are shipped in anti-static bags with foam cushioning inside rigid outer packaging as standard practice.
Q: Do you accept purchase orders from fabs and equipment service companies?
A: Yes. Konmask.com works with semiconductor fabs, equipment OEMs, and third-party maintenance providers globally. Contact us to establish account terms.
