Semiconductor Lithography Laser Heating Solution – ASML 4022.436.1723 | Laser Assembly Series
The ASML 4022.436.1723 / 112052-8 Laser Heater Assembly (cross-references: TI-XZ 0200-36543, BLM-013468) is a precision thermal management component engineered for ASML photolithography platforms. Designed to maintain laser source temperature stability within tight tolerances, this assembly is critical to maintaining beam quality, exposure consistency, and system uptime in high-volume semiconductor manufacturing environments.
Where This Product Is Used
This laser heater assembly is specified for use in the following environments and applications:
- ASML DUV / EUV Lithography Systems – Maintains laser excimer or solid-state source at operating temperature during wafer exposure cycles.
- Semiconductor Wafer Fabrication (Wafer Fab Equipment / WFE) – Installed in front-end-of-line (FEOL) lithography cells at leading-edge fabs (logic, DRAM, NAND).
- Laser Source Thermal Stabilization – Prevents thermal drift that causes CD (critical dimension) variation and overlay errors.
- Preventive Maintenance & Scheduled Replacement – Used by ASML field service engineers and in-house fab maintenance teams during planned PM cycles.
- Spare Parts Inventory (Fab Stores) – Stocked as a critical spare to minimize unplanned downtime risk on high-utilization lithography tools.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | ASML |
| Primary Part Number | 4022.436.1723 |
| Secondary Part Number | 112052-8 |
| Cross-Reference / Alias | TI-XZ 0200-36543 | BLM-013468 |
| Assembly Type | Laser Heater Assembly (LASER ASSY) |
| Series / Module | TI-XZ Thermal Interface – XZ Axis |
| Weight | 2,600 g (approx.) |
| Country of Origin | Netherlands (NL) |
| Application Platform | ASML DUV / EUV Lithography Systems |
| Condition | New / Refurbished (specify on inquiry) |
Why Engineers Specify This Model
- OEM Part Number Traceability – Dual part number (4022.436.1723 + 112052-8) with BLM and TI-XZ cross-references ensures exact fit and form compliance with ASML BOM requirements.
- Thermal Precision – Engineered to ASML’s internal thermal interface specifications for the XZ-axis laser module, ensuring repeatable temperature control critical to sub-nanometer overlay performance.
- Drop-in Replacement – Maintains original mounting geometry, connector pinout, and thermal interface material (TIM) compatibility — no field modification required.
- Minimizes Tool Downtime – Fast-swap design supports rapid PM execution, reducing mean time to repair (MTTR) on critical lithography assets.
- Sourced from Verified Supply Chain – Konmask.com sources from authorized distributors and certified secondary market suppliers with full documentation.
Complete System Bill of Materials
This assembly is typically used alongside the following ASML subsystem components (available on request):
- ASML Laser Source Module (excimer / solid-state)
- ASML Beam Delivery Unit (BDU) components
- ASML Thermal Interface Pads / TIM materials
- ASML XZ-Axis Motion Stage components
- ASML Power Supply Units (PSU) for laser subsystem
- ASML Control Electronics / PCB assemblies
Contact Konmask.com with your full BOM list for consolidated sourcing and volume pricing.
Compliance & Industry Standards
- SEMI S2 – Environmental, Health & Safety guidelines for semiconductor manufacturing equipment.
- SEMI S8 – Ergonomic guidelines for semiconductor equipment.
- RoHS / REACH – Compliance documentation available upon request for applicable sub-components.
- ASML Internal Quality Standards – Part manufactured and/or qualified to ASML’s internal IQ/OQ/PQ validation protocols.
- ESD Safe Handling – Packaged and shipped in ESD-protective materials per ANSI/ESD S20.20.
Quality Assurance & Sourcing
Konmask.com applies a multi-stage verification process for all ASML spare parts:
- ✅ Part Number Verification – Primary and secondary PN confirmed against ASML documentation.
- ✅ Physical Inspection – Visual and dimensional inspection prior to shipment.
- ✅ Documentation Package – Certificate of Conformance (CoC), packing list, and traceability records provided.
- ✅ ESD & Packaging – Anti-static bag, foam cushioning, and labeled outer carton.
- ✅ Lead Time Transparency – Confirmed stock availability or realistic lead time communicated before order confirmation.
How to Source This Part
- Submit an RFQ – Email [email protected] with your required quantity, delivery timeline, and destination country.
- Receive Quote – We respond within 1 business day with pricing, lead time, and available condition (new / refurbished).
- Order Confirmation – Purchase order accepted via email; proforma invoice issued for payment processing.
- Shipment & Tracking – Shipped via DHL / FedEx / UPS with full tracking and export documentation (commercial invoice, packing list, COO).
- After-Sales Support – Technical questions and warranty claims handled by our engineering support team.
Application-Specific FAQ
Q: Is this part compatible with all ASML lithography tool generations?
A: This assembly is identified by ASML part number 4022.436.1723 and is intended for specific ASML platforms. Please confirm your tool model and serial number when submitting an RFQ so we can verify compatibility.
Q: Can you supply both new and refurbished units?
A: Yes. Konmask.com can source new (OEM) and certified refurbished units depending on availability. Condition is clearly stated on the quotation and CoC.
Q: What is the typical lead time?
A: Lead time varies by stock availability. In-stock units ship within 3–5 business days. Out-of-stock items typically have a 2–6 week lead time. Contact us for real-time availability.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and CoC. Export compliance screening is performed for all international orders.
Q: Can I order multiple ASML part numbers in one shipment?
A: Absolutely. Konmask.com specializes in consolidated ASML BOM sourcing. Submit your full parts list for a single consolidated quote.
