Industrial Process Control Solution — BACHMANN DIO16-C | MX Series
Where This Product Is Used
The BACHMANN DIO16-C is a 16-channel digital I/O module engineered for demanding industrial environments where reliable signal acquisition and discrete output control are mission-critical. Typical deployment scenarios include:
- Wind Turbine Control Systems — Integrated into BACHMANN MX controller racks for pitch control, safety relay monitoring, and grid-connection status feedback.
- Power Generation & Substation Automation — Monitoring breaker status, protection relay trip signals, and auxiliary contact states across HV/MV switchgear panels.
- Industrial Process Plants — Valve open/close feedback, pump run/fault status, and motor starter interlock logic in oil & gas, chemical, and water treatment facilities.
- Machine Tool & Press Control — Interfacing with limit switches, proximity sensors, and safety light curtains in CNC and stamping applications.
- Building Automation & HVAC — Fan status, damper position, and fire/smoke alarm discrete input aggregation within BMS architectures.
- Test & Measurement Rigs — High-density digital signal routing in automated test equipment (ATE) and hardware-in-the-loop (HIL) simulation platforms.
Technical Specifications
| Part Number | DIO16-C |
| Manufacturer | BACHMANN Electronic GmbH |
| Module Type | Digital Input / Output (Mixed) |
| Channel Count | 16 Channels (configurable I/O) |
| Compatible Rack | BACHMANN MX Series Controller Rack |
| Signal Standard | IEC 61131-2 compliant digital signals |
| Programming Standard | IEC 61131-3 (SolutionCenter / M-Target) |
| Mounting | Backplane slot-mount (MX rack) |
| Weight | 520 g |
| SKU / Order Code | DIO16-C |
Full electrical ratings, isolation specs, and environmental parameters are available in the BACHMANN DIO16-C datasheet. Contact us for documentation.
Why Engineers Specify This Model
- High Channel Density — 16 configurable digital channels in a single backplane slot reduces rack space and wiring complexity versus discrete relay modules.
- Native MX Ecosystem Integration — Plug-and-play compatibility with BACHMANN MX200, MX213, and MX220 CPUs; no external gateway or protocol converter required.
- Deterministic Real-Time Performance — Synchronized with the MX rack’s real-time bus for sub-millisecond I/O update cycles, critical for safety and fast-response control loops.
- Robust Industrial Design — Designed for continuous operation in harsh environments with wide temperature tolerance and vibration resistance per IEC standards.
- Simplified Diagnostics — Per-channel status LEDs and SolutionCenter software diagnostics enable rapid fault isolation without external test equipment.
- Long Product Lifecycle — BACHMANN’s industrial-grade product roadmap ensures long-term availability and backward compatibility for multi-decade plant assets.
Complete System Bill of Materials
A typical BACHMANN MX-based control node using the DIO16-C includes the following components:
- BACHMANN MX200 / MX213 / MX220 — CPU Module
- BACHMANN DIO16-C — Digital I/O Module (this item)
- BACHMANN PS24 / PS240 — Power Supply Module
- BACHMANN MX Rack / Backplane — Chassis
- BACHMANN AIO288 / AIO208 — Analog I/O Module (if mixed signals required)
- BACHMANN CM202 / CM203 — Communication Module (Profibus / CANopen / EtherCAT)
- Terminal blocks, shielded I/O cables, and DIN-rail mounting hardware
Konmask.com stocks multiple BACHMANN MX series modules. Contact our team to source a complete matched BOM.
Compliance & Industry Standards
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- IEC 61131-3 — Programmable Controllers: Programming Languages
- CE Marking — European Electromagnetic Compatibility & Low Voltage Directives
- UL / cUL Listed (verify current certification status with BACHMANN datasheet)
- RoHS Compliant — Restriction of Hazardous Substances
- GL / DNV Type Approval (applicable variants for marine & offshore use)
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers in energy, manufacturing, and infrastructure sectors. Our sourcing and quality process for the BACHMANN DIO16-C includes:
- Verified Supply Chain — Modules sourced from authorized distributors and certified secondary-market channels with full traceability documentation.
- Pre-Shipment Inspection — Visual inspection, label verification, and functional power-on checks performed before dispatch.
- Authentic Packaging — Original BACHMANN packaging, firmware labels, and serial numbers preserved and verified.
- Warranty & Return Policy — 90-day warranty against defects in materials and workmanship. Contact support for RMA procedures.
- Export Compliance — All shipments comply with applicable export control regulations. End-user documentation available on request.
How to Source This Part
- Add to Cart — Place your order directly on Konmask.com with secure checkout.
- Request a Quote — For volume orders (>3 units), OEM projects, or BOM sourcing, email support@konmask.com for a formal quotation within 24 hours.
- Confirm Compatibility — Share your MX rack model and firmware version; our engineers will verify slot and software compatibility before shipment.
- Expedited Shipping — DHL Express, FedEx International Priority, and sea freight options available. Lead time: 3–7 business days for in-stock units.
- Documentation Package — Datasheet, declaration of conformity, and test report provided upon request with every order.
Application-Specific FAQ
Q: Is the DIO16-C compatible with BACHMANN MX200 and MX213 CPUs?
A: Yes. The DIO16-C is designed for the BACHMANN MX backplane and is compatible with all current MX series CPU modules. Confirm firmware version compatibility with your system integrator or contact Konmask support.
Q: Can the channels be configured as all inputs or all outputs?
A: The DIO16-C supports flexible channel configuration via SolutionCenter software. Specific input/output ratio constraints depend on firmware version — refer to the BACHMANN DIO16-C datasheet or contact us for the configuration guide.
Q: What is the maximum cable length for digital I/O signals?
A: Cable length depends on signal voltage level and noise environment. BACHMANN recommends shielded twisted-pair cable; consult the installation manual for maximum run lengths per signal type.
Q: Do you supply the BACHMANN SolutionCenter software license?
A: SolutionCenter licenses are managed by BACHMANN Electronic GmbH. Konmask can assist with hardware procurement; contact BACHMANN or their regional distributor for software licensing.
Q: Can this module be used in a wind turbine safety system (SIL-rated)?
A: The DIO16-C is a standard control module. For SIL-rated safety applications, BACHMANN offers dedicated safety modules (e.g., SIL2-certified variants). Contact us to discuss your safety architecture requirements.
Q: What is your lead time for the DIO16-C?
A: In-stock units ship within 3–7 business days. For urgent requirements, contact support@konmask.com or call +0086 19859288691 for expedited options.
