Multi-Axis Motion Control Solution – BECKHOFF AX5118-0000 | AX5000 Series
Where This Product Is Used
The BECKHOFF AX5118-0000 is a single-channel digital compact servo drive from the AX5000 series, engineered for high-precision, high-dynamic motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers – Axis interpolation for milling, turning, and grinding with sub-millisecond cycle times.
- Robotic Arms & Gantry Systems – Coordinated multi-axis motion via EtherCAT FSoE safety integration.
- Packaging & Filling Machines – High-speed pick-and-place, indexing conveyors, and servo-driven cam profiles.
- Printing & Converting Equipment – Register control and tension management requiring tight velocity loops.
- Semiconductor & Electronics Assembly – Ultra-precise positioning stages with low-ripple torque output.
- Plastics Injection Molding – Clamp, injection, and ejector axis control with force feedback.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | AX5118-0000 |
| Series | AX5000 Digital Compact Servo Drive |
| Manufacturer | BECKHOFF Automation |
| Drive Channels | 1-channel (single-axis) |
| Fieldbus Interface | EtherCAT (CoE – CANopen over EtherCAT) |
| Feedback Systems Supported | EnDat 2.1/2.2, Hiperface, Resolver, SinCos, SSI, BiSS |
| Safety Function | STO (Safe Torque Off), optional TwinSAFE FSoE |
| Control Modes | CSP, CSV, CST (IEC 61800-7 / CiA 402) |
| Supply Voltage | 3 × 200–480 V AC, 50/60 Hz |
| Protection Class | IP20 |
| Cooling | Convection / forced air (model-dependent) |
| Communication Cycle | Down to 62.5 µs EtherCAT cycle |
| Weight | ~300 g (drive unit) |
Why Engineers Specify This Model
- Native EtherCAT Integration – Plug-and-play with BECKHOFF TwinCAT 3 PLC/NC runtime; no gateway required.
- Compact Form Factor – Slim bookshelf design minimizes cabinet footprint while delivering full servo performance.
- Universal Feedback Compatibility – Supports all major encoder protocols, reducing motor sourcing constraints.
- Integrated Safety – STO certified to SIL 2 / PLd; optional FSoE for safe motion profiles without external safety relays.
- Scalable Architecture – Shares DC bus with other AX5000 drives for energy recovery and reduced inrush current.
- TwinCAT Scope & Diagnostics – Real-time oscilloscope and auto-tuning tools reduce commissioning time significantly.
Complete System Bill of Materials
A typical AX5118-0000 servo system requires the following components:
- BECKHOFF AX5118-0000 – Servo Drive (this unit)
- BECKHOFF AX5000 Power Supply Module (AX5190 or AX5191) – DC bus supply
- Compatible AM8000 / AM8500 Series Servo Motor with EnDat encoder
- EtherCAT cable (Cat 5e shielded, M8/RJ45)
- BECKHOFF CX or IPC with TwinCAT 3 NC/PTP or CNC license
- 24 V DC auxiliary power supply (e.g., BECKHOFF PS2000)
- Motor power cable and feedback cable (pre-assembled or field-wired)
- Cabinet-mount DIN rail, terminal blocks, and EMC filter
Compliance & Industry Standards
- CE Marking – EU Machinery Directive 2006/42/EC & Low Voltage Directive 2014/35/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- IEC 61800-5-1 – Adjustable Speed Electrical Power Drive Systems
- IEC 62061 / ISO 13849-1 – Functional Safety (SIL 2 / PLd for STO)
- EtherCAT Conformance – ETG (EtherCAT Technology Group) certified
- RoHS 2 Compliant – Directive 2011/65/EU
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for B2B buyers. Every unit offered through our platform is:
- Sourced from authorized distributors or verified surplus channels with full traceability
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with original manufacturer packaging where available
- Backed by our 30-day return policy for DOA (Dead on Arrival) units
- Supported by our technical team for pre-sales specification and compatibility queries
How to Source This Part
- Confirm your application requirements – rated current, motor feedback type, safety level, and TwinCAT version.
- Contact us via email or phone with your PO or RFQ; we respond within 1 business day.
- Receive a formal quotation including lead time, shipping options (DHL/FedEx/sea freight), and export documentation.
- Place your order – payment via T/T bank transfer, PayPal, or trade assurance platforms.
- Track shipment – all orders include tracking and commercial invoice for customs clearance.
Application-Specific FAQ
Q: Is the AX5118-0000 compatible with third-party motors (non-BECKHOFF)?
A: Yes. The AX5118-0000 supports standard encoder protocols (EnDat, Hiperface, Resolver, SSI, BiSS), making it compatible with motors from Siemens, Lenze, Rexroth, and others, provided the feedback interface matches.
Q: Can this drive be used without TwinCAT?
A: The AX5000 series is optimized for TwinCAT 3 NC. While EtherCAT CoE allows third-party master controllers, full auto-tuning and diagnostic features require TwinCAT.
Q: What is the difference between AX5118-0000 and AX5118-0010?
A: The -0010 variant includes an additional multi-feedback option card. The -0000 covers the standard encoder interfaces listed above. Confirm your motor’s feedback type before ordering.
Q: Do you provide export documentation for customs?
A: Yes. We provide commercial invoice, packing list, and HS code declaration. ECCN/EAR classification support is available on request for regulated destinations.
Q: What is the lead time for AX5118-0000?
A: Stock availability varies. Contact us for a real-time inventory check. Expedited shipping via DHL Express is available for urgent requirements.
