Turbomachinery Vibration Monitoring Solution – Bently Nevada 31000-16-05-00-063-03-02 | 3300 Series
Where This Product Is Used
The Bently Nevada 31000-16-05-00-063-03-02 Proximity Probe Housing Assembly is engineered for continuous, non-contact vibration and position measurement in rotating machinery. Typical deployment environments include:
- Steam & Gas Turbines – shaft radial vibration monitoring at bearing journals
- Centrifugal Compressors – rotor dynamic displacement measurement in petrochemical and LNG plants
- Pumps & Fans – axial thrust and radial position sensing in power generation facilities
- Gearboxes – gear mesh frequency and shaft orbit analysis
- Marine Propulsion Systems – continuous shaft monitoring in offshore and naval applications
This housing assembly is a critical mechanical interface component that positions and protects the eddy-current probe tip at the precise gap distance required for accurate signal output, typically 1.0 mm (40 mil) nominal gap.
Technical Specifications
| Part Number | 31000-16-05-00-063-03-02 |
| Series | Bently Nevada 3300 / 31000 & 32000 Proximity Probe System |
| Probe Tip Diameter | 8 mm (standard) |
| Cable Length | 5 m (extension cable included per configuration) |
| Thread Size | M10 × 1.0 (metric, per part number suffix) |
| Housing Material | 316 Stainless Steel |
| Temperature Range | –40 °C to +177 °C (–40 °F to +350 °F) |
| Ingress Protection | IP67 (dust-tight, immersion-resistant) |
| Connector Type | MIL-C-5015 bayonet (per suffix -02) |
| Weight | Approx. 1,700 g (complete assembly) |
| Compliance | API 670, CE, RoHS |
Why Engineers Specify This Model
- API 670 Compliant – meets the industry standard for machinery protection systems, accepted by EPC contractors and end-users globally
- Full Part-Number Traceability – each suffix digit encodes probe length, cable length, armored jacket, connector type, and mounting thread, eliminating field ambiguity
- 316 SS Housing – resists H₂S, chloride, and hydrocarbon environments common in upstream oil & gas
- Drop-in Replacement – dimensionally identical to OEM specification; no re-calibration of the 3300 XL monitor required
- Broad Temperature Tolerance – qualified for hot-section turbine bearing pedestals and cryogenic compressor applications alike
Complete System Bill of Materials
For a fully functional Bently Nevada eddy-current measurement loop, the following components are required:
- Proximity Probe – 31000-16-05-00-063-03-02 (this item)
- Extension Cable – 330130-XX-00 (length per application)
- Proximitor® Sensor / Driver – 3300 XL 8 mm (330180-91-00 or equivalent)
- Monitor Module – 3500/42M Proximitor® / Seismic Monitor
- Rack Frame – 3500/05 Power Supply & Rack
- Mounting Hardware – locknut, jam nut, and armored conduit per API 670 §5.4
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 61511 – Functional Safety for SIS applications
- ATEX / IECEx – available in Ex-rated variants for Zone 1 / Zone 2 hazardous areas
- CE Marking – compliant with EU Machinery Directive 2006/42/EC
- RoHS – restriction of hazardous substances compliant
Quality Assurance & Sourcing
All units supplied by Konmask.com are sourced through verified industrial distribution channels. Each assembly undergoes:
- Visual and dimensional inspection against OEM drawings
- Continuity and insulation resistance check on probe cable
- Packaging integrity verification prior to dispatch
- Certificate of Conformance (CoC) available upon request
We do not supply counterfeit, refurbished-as-new, or grey-market parts. Authenticity documentation is available for regulated industries.
How to Source This Part
Stock availability is updated in real time. To place an order or request a formal quotation:
- Online: Add to cart and proceed to checkout — we accept T/T, PayPal, and major credit cards
- Email RFQ: support@konmask.com — include your full part number, quantity, and required delivery date
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock orders ship within 1–3 business days; ex-factory orders quoted individually
- Export: We ship globally via DHL, FedEx, and UPS with full commercial invoice and packing list
Application-Specific FAQ
Q: Is this probe compatible with the Bently Nevada 3500 monitoring system?
A: Yes. The 31000/32000 series probes are fully compatible with the 3500 rack system when paired with the correct Proximitor® driver module. Verify the driver part number matches the probe tip diameter (8 mm for this model).
Q: What is the nominal gap voltage for this probe?
A: The standard operating gap is 1.0 mm (40 mil), corresponding to approximately –10 VDC output from the Proximitor® sensor. Refer to Bently Nevada calibration sheet 141536-01 for the full gap-vs-voltage curve.
Q: Can this housing be used in a Zone 1 ATEX environment?
A: The standard part number is not ATEX-rated. For hazardous area installations, specify the Ex-rated variant or contact us for the appropriate suffix configuration.
Q: Do you provide calibration certificates?
A: We supply OEM calibration data sheets where available. Third-party NIST-traceable calibration can be arranged upon request at additional cost.
Q: What is the difference between the 31000 and 32000 series?
A: The 31000 series uses a standard armored cable jacket; the 32000 series features an extended-temperature, high-flex cable for applications with tight bend radii or elevated ambient temperatures above 150 °C.
