Motion Control Solution – BERGER LAHR TLC411F | IFM Series Stepper Motor Drive
Where This Product Is Used
The BERGER LAHR TLC411F stepper motor drive controller is engineered for precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers – Axis positioning and feed-rate control for milling, turning, and drilling operations
- Packaging Machinery – High-speed indexing, label applicators, and form-fill-seal lines requiring repeatable step accuracy
- Textile & Printing Equipment – Tension control and web-guiding systems where smooth micro-stepping is critical
- Semiconductor Handling – Wafer transport and pick-and-place gantries demanding sub-millimeter repeatability
- Laboratory Automation – Pipetting robots, sample carousels, and analytical instrument stages
- Conveyor & Material Handling – Synchronised multi-axis belt drives in automotive and electronics assembly lines
Technical Specifications
- Part Number / SKU: TLC411F
- Brand: BERGER LAHR (Schneider Electric Motion)
- Series: IFM / TLC
- Device Type: Stepper Motor Drive Controller
- Weight: 2,130 g (approx. 4.7 lb)
- Mounting: DIN rail / panel mount (verify with datasheet)
- Communication Interface: Refer to OEM datasheet for fieldbus options
- Operating Temperature: Refer to OEM datasheet
- Certifications: CE (verify with OEM documentation)
Why Engineers Specify This Model
- Proven IFM Platform – The TLC series has decades of field deployment across European and Asian OEM machine builders, providing a mature, well-documented control architecture.
- Micro-stepping Precision – Reduces resonance and audible noise versus full-step drives, enabling smoother motion profiles in sensitive applications.
- Compact Form Factor – Fits standard control cabinet layouts without requiring custom mounting hardware.
- Drop-in Replacement Availability – Konmask.com stocks tested units to support legacy machine maintenance without costly redesigns.
- Broad Motor Compatibility – Compatible with a wide range of 2-phase and 4-phase stepper motors commonly used in European-designed machinery.
Complete System Bill of Materials
For a fully operational stepper axis, engineers typically specify the following alongside the TLC411F:
- 2-phase or 4-phase stepper motor (NEMA 23 / NEMA 34 frame)
- 24 VDC or 48 VDC regulated power supply (capacity matched to motor current)
- Motion controller or PLC with pulse/direction output (e.g., Schneider Electric Modicon, Siemens S7)
- Shielded motor cable (twisted-pair, ≥ 0.75 mm²)
- DIN rail terminal blocks and cable management
- Encoder feedback module (optional, for closed-loop verification)
- Emergency stop relay and safety contactor per IEC 60204-1
Compliance & Industry Standards
- CE Marking – Designed to meet EU Machinery Directive and Low Voltage Directive requirements
- IEC 61800 – Adjustable speed electrical power drive systems
- IEC 60204-1 – Safety of machinery, electrical equipment of machines
- RoHS – Confirm RoHS status with OEM documentation for specific production date codes
Quality Assurance & Sourcing
All units listed on Konmask.com undergo the following before dispatch:
- Visual inspection for physical damage, corrosion, and label integrity
- Power-on functional verification where applicable
- Anti-static packaging with humidity indicator card
- Traceable documentation retained for each unit
We source from authorised distributors, OEM overstock, and verified industrial surplus channels. Counterfeit-risk mitigation is a core part of our procurement process.
How to Source This Part
- In-Stock Orders: Add to cart and check out — most orders ship within 1–3 business days from our Fujian, China warehouse.
- Bulk / Project Quotes: Email support@konmask.com with your BOM quantity and project timeline for volume pricing.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day response on critical machine-down situations.
- Export & Customs: We handle export documentation (commercial invoice, packing list, CO) for international shipments.
Application-Specific FAQ
Q: Is the TLC411F compatible with Siemens S7-300/400 PLC pulse outputs?
A: Yes, the TLC411F accepts standard pulse/direction signals. Verify voltage levels (5 V vs. 24 V) against your PLC output card specification before wiring.
Q: Can this drive be used for closed-loop stepper control?
A: The TLC411F is an open-loop drive. Closed-loop operation requires an external encoder and a motion controller that supports encoder feedback correction.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical lead time is 2–4 weeks depending on sourcing channel.
Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 90-day functional warranty on all tested units. See our warranty policy for full terms.
Q: Can you supply the matching stepper motor for this drive?
A: Contact us with your torque, speed, and frame-size requirements and we will recommend a compatible motor from our catalog.
