BOMBARDIER DCC2223A-3EST125-977 – Transit Traction Drive Control Unit | BOMBARDIER Propulsion Platform
Engineering Background
The DCC2223A-3EST125-977 is a purpose-engineered Drive Control Unit (DCU) developed by BOMBARDIER Transportation for deployment in urban rail and light transit propulsion systems. It forms the core intelligence layer of the traction drive chain, translating high-level speed and torque commands into precise IGBT gate-drive signals for the traction inverter.
Product Positioning
Designed for procurement engineers and rolling-stock maintenance teams requiring a direct OEM-equivalent replacement or spare-pool addition. The DCC2223A-3EST125-977 is stocked and verified by Konmask.com as a genuine BOMBARDIER assembly, suitable for both scheduled overhaul programs and emergency line-restoration scenarios.
Complete Technical Specifications
- Part Number / SKU: DCC2223A-3EST125-977
- Manufacturer: BOMBARDIER Transportation
- Module Type: Drive Control Unit (DCU)
- Platform Compatibility: BOMBARDIER MITRAC / Propulsion Series
- Function: Traction inverter gate-drive control, speed/torque regulation, fault diagnostics
- Communication Interface: MVB / CAN (platform-dependent)
- Operating Voltage: Per OEM specification (24 VDC logic supply typical)
- Operating Temperature: -25 °C to +70 °C (per BOMBARDIER environmental class)
- Protection Class: IP54 (enclosure-mounted)
- Approvals / Standards: EN 50155, EN 50121-3-2 (railway EMC)
- Country of Origin: Canada
- Weight (unit): ~3.3 kg (shipping weight per OEM data)
Proven Application Environments
- Urban metro and light rail traction inverter control loops
- BOMBARDIER FLEXITY and MOVIA rolling-stock platforms
- Depot overhaul and scheduled preventive maintenance programs
- Emergency spare-pool replenishment for transit authorities
- OEM-equivalent retrofit on legacy BOMBARDIER propulsion systems
Engineering Advantages
- OEM Pedigree: Manufactured to BOMBARDIER production specifications — no third-party clone risk
- Plug-and-Play Replacement: Direct form/fit/function match; no firmware re-flashing required in standard swap scenarios
- Integrated Diagnostics: On-board fault logging reduces MTTR and simplifies root-cause analysis
- Thermal Robustness: Designed for continuous duty in high-vibration, wide-temperature rail environments
- Long Service Life: BOMBARDIER-grade component selection supports 20+ year vehicle lifecycle
System Architecture & Signal Flow
The DCC2223A-3EST125-977 sits between the Vehicle Control Unit (VCU) and the traction inverter power stage. It receives torque/speed reference signals via the vehicle bus (MVB/CAN), executes the PWM modulation algorithm, and outputs isolated gate-drive pulses to the IGBT modules. Simultaneously, it monitors DC-link voltage, phase currents, and thermal sensors, feeding real-time status back to the VCU and the onboard diagnostic recorder.
Signal path: VCU → [MVB/CAN] → DCC2223A-3EST125-977 → [Gate Drive] → IGBT Inverter → Traction Motor
Sourcing & Quality Verification
- All units sourced from authorized BOMBARDIER distribution channels or certified MRO partners
- Pre-shipment functional verification and visual inspection performed by Konmask technical staff
- Serialized traceability records available upon request for fleet documentation
- Packaging: anti-static shielded bag + foam-lined export carton; compliant with IEC 61340-5-1
Procurement Process
- Submit your RFQ or place order directly on Konmask.com
- Receive order confirmation with lead time and shipping estimate within 1 business day
- Unit dispatched with packing list, inspection report, and traceability documentation
- Post-delivery technical support available via email or phone
Technical FAQ
Q: Is this a new or refurbished unit?
A: Please contact us to confirm current stock condition. Both new OEM and professionally refurbished units may be available depending on inventory.
Q: Can this unit be used on non-BOMBARDIER platforms?
A: The DCC2223A-3EST125-977 is designed specifically for BOMBARDIER propulsion architectures. Cross-platform use requires engineering validation.
Q: What warranty is provided?
A: Konmask.com provides a standard 90-day functional warranty. Extended warranty options available — contact support for details.
Q: Do you provide installation support?
A: Yes. Our technical team can provide commissioning guidance and documentation. Contact support@konmask.com.
