DC Bus Energy Storage Solution – BOSCH KM 3300-T | KM3300 Series
Where This Product Is Used
The BOSCH KM 3300-T (Part No. 054915-103) is a DC bus capacitor module from the KM3300 series, engineered for energy buffering and voltage stabilization in high-performance servo drive and motion control systems. It is widely deployed in the following industrial environments:
- CNC Machining Centers – Stabilizes DC bus voltage during rapid axis acceleration/deceleration cycles, preventing drive faults and protecting spindle drives.
- Injection Molding Machines – Absorbs regenerative energy from hydraulic servo pumps, reducing heat dissipation and extending drive service life.
- Automated Assembly Lines – Provides ride-through energy during brief power interruptions, maintaining production continuity.
- Robotics & Multi-Axis Motion Systems – Buffers peak current demands across shared DC bus architectures, enabling coordinated multi-axis operation.
- Printing & Packaging Machinery – Smooths voltage transients caused by high-inertia web tension control systems.
- Semiconductor & Electronics Manufacturing – Supports precision motion stages where voltage ripple directly impacts positioning accuracy.
Technical Specifications
| Manufacturer | BOSCH (Rexroth) |
| Part Number | 054915-103 |
| Model / SKU | KM 3300-T |
| Series | KM3300 |
| Product Type | DC Bus Capacitor Module |
| Function | DC bus energy storage & voltage buffering |
| Compatible Drive Series | BOSCH Rexroth DKS, HDS, KDS servo drive systems |
| Mounting | Panel / cabinet rail mount |
| Weight | 1,220 g (approx.) |
| Condition | New / Refurbished / Tested (specify on inquiry) |
| Origin | Germany |
Why Engineers Specify This Model
- Proven KM3300 Platform – The KM3300 series is a field-validated capacitor module family used globally in BOSCH Rexroth servo drive installations for over two decades.
- Drop-In Replacement – Exact OEM form factor and electrical interface; no firmware changes or mechanical modifications required.
- Regenerative Energy Recovery – Captures braking energy from servo axes and feeds it back to the DC bus, reducing net energy consumption by up to 30% in cyclic applications.
- Voltage Ride-Through – Maintains DC bus integrity during micro-interruptions (typically <20 ms), preventing costly production stops.
- Reduced Drive Stress – Decouples peak current demands from the supply rectifier, extending the operational lifespan of connected drive modules.
Complete System Bill of Materials
The KM 3300-T is typically integrated as part of a BOSCH Rexroth servo drive cabinet. Common companion components include:
- BOSCH Rexroth DKS / HDS / KDS Servo Drive Modules
- BOSCH Rexroth KW / KDA Power Supply Modules
- BOSCH Rexroth DSF / DSS Servo Motors
- DC Bus Connecting Bars & Shielded Power Cables
- BOSCH CNC Controller (e.g., CC220, CC300 series)
- 24 VDC Control Power Supply
Contact support@konmask.com for complete drive system sourcing and BOM matching.
Compliance & Industry Standards
- Designed and manufactured in compliance with CE Marking directives (Low Voltage Directive & EMC Directive)
- Meets IEC 61800 (Adjustable Speed Electrical Power Drive Systems) requirements
- Compatible with ISO 13849 safety-rated machine control architectures
- RoHS-compliant materials (verify with OEM datasheet for specific production batch)
Quality Assurance & Sourcing
At Konmask.com, every BOSCH KM 3300-T unit undergoes a structured inspection process before shipment:
- Visual inspection for physical damage, corrosion, and label integrity
- Capacitance and ESR (Equivalent Series Resistance) bench testing
- DC bus connector and terminal torque verification
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
We source directly from authorized distributors, OEM surplus channels, and decommissioned production lines with full traceability documentation.
How to Source This Part
- Submit your inquiry via support@konmask.com or WhatsApp +0086 19859288691.
- Provide your machine model, drive series, and required quantity.
- Receive a formal quotation with lead time and shipping options within 24 hours.
- Confirm order — we accept T/T, PayPal, and major trade payment terms.
- Shipment via DHL / FedEx / UPS with full tracking and export documentation.
Application-Specific FAQ
Q: Is the KM 3300-T compatible with all BOSCH Rexroth DKS drive variants?
A: The KM3300 series is designed for use with BOSCH Rexroth DKS, HDS, and KDS series drives that share a common DC bus architecture. Always verify the bus voltage rating and connector type against your specific drive model before installation.
Q: Can this module be used as a standalone UPS for the drive system?
A: No. The KM 3300-T is a DC bus buffer, not an uninterruptible power supply. It provides short-duration ride-through (milliseconds range) and regenerative energy storage, not sustained backup power.
Q: What is the typical service life of the capacitor module?
A: Electrolytic capacitor life is temperature-dependent. Under rated operating conditions, BOSCH Rexroth capacitor modules are designed for a minimum 10-year service life. Elevated ambient temperatures significantly reduce this figure.
Q: Do you provide installation support?
A: Yes. Our technical team can provide wiring diagrams, parameter settings, and remote commissioning guidance. Contact us at support@konmask.com.
Q: Can I return the module if it does not fit my application?
A: We offer a 30-day return policy for unused, uninstalled modules in original packaging. Please contact us before returning any item.
