Industrial HMI Solution – B&R 4PP350.0571-K01 | Power Panel 350 Series
Where This Product Is Used
The B&R 4PP350.0571-K01 Power Panel 350 is a compact, high-performance HMI touch panel engineered for demanding industrial environments. Engineers and system integrators specify this unit across a wide range of applications:
- Machine Tool Control – CNC machining centers, lathes, and milling stations requiring real-time operator feedback and parameter adjustment.
- Packaging Machinery – High-speed filling, sealing, and labeling lines where intuitive touchscreen control reduces changeover time.
- Automotive Assembly Lines – Body-in-white welding stations, press lines, and conveyor control panels demanding rugged, panel-mount HMIs.
- Food & Beverage Processing – Hygienic production environments where sealed front panels and easy-clean surfaces are essential.
- Water & Wastewater Treatment – SCADA-connected pump stations and filtration systems requiring reliable local operator interfaces.
- Building Automation & HVAC – Energy management systems, chiller plants, and air-handling unit control panels.
- Pharmaceutical Manufacturing – Batch process control and recipe management in GMP-compliant facilities.
Technical Specifications
- Part Number: 4PP350.0571-K01
- Series: Power Panel 350
- Manufacturer: B&R (Bernecker & Rainer Industrie-Elektronik GmbH)
- Display Size: 5.7″ SVGA TFT Color LCD
- Resolution: 640 × 480 px (VGA)
- Touchscreen Type: Resistive touch
- Processor: Intel Atom / B&R integrated CPU
- Operating System: B&R Automation Runtime
- Communication Interfaces: Ethernet (RJ45), USB, CAN, RS232/RS485
- Fieldbus Support: POWERLINK, Modbus TCP, EtherNet/IP (via configuration)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +60 °C
- Protection Rating: IP65 (front panel)
- Power Supply: 24 V DC
- Weight: Approx. 1.6 kg
- Mounting: Panel cut-out, flush mount
- Certifications: CE, UL, cUL
Why Engineers Specify This Model
- Integrated PLC + HMI – Combines visualization and control in a single compact unit, reducing panel space and wiring complexity.
- B&R Automation Studio Compatible – Seamless programming with B&R’s unified engineering environment; no additional HMI software license required.
- IP65 Front Panel – Dust-tight and water-jet resistant, suitable for wash-down and harsh factory floor environments.
- POWERLINK Real-Time Ethernet – Deterministic, cycle-time-precise communication with B&R I/O modules and drives.
- Compact 5.7″ Form Factor – Ideal for space-constrained control cabinets and machine-mounted operator panels.
- Long Product Lifecycle – B&R’s commitment to long-term availability ensures spare parts and support for installed base protection.
Complete System Bill of Materials
For a complete B&R Power Panel 350 control system, engineers typically specify the following companion components:
- I/O Modules: B&R X20 Series digital/analog I/O (e.g., X20DI9371, X20DO9322)
- Power Supply: B&R X20PS9400 or equivalent 24 V DC DIN-rail PSU
- Communication Module: B&R X20BC0083 POWERLINK controller node
- Servo Drives: B&R ACOPOS P3 or ACOPOSmulti for motion control integration
- Programming Software: B&R Automation Studio 4.x (free download, license per project)
- Panel Mounting Hardware: Standard M4 panel clamps (included) + IP65 gasket seal
- Cables: Shielded Ethernet Cat5e/Cat6 for POWERLINK; USB-A to USB-B for programming
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and EMC Directive 2014/30/EU.
- UL / cUL Listed – Recognized for use in North American industrial control panels per UL 508A.
- IEC 61131-3 – Programming environment supports all five standard PLC languages.
- IP65 (IEC 60529) – Front panel ingress protection verified for solid particles and water jets.
- RoHS Compliant – Manufactured without restricted hazardous substances per EU Directive 2011/65/EU.
Quality Assurance & Sourcing
Konmask.com specializes in sourcing genuine, tested industrial automation components from verified supply chains. Every B&R 4PP350.0571-K01 unit we supply undergoes:
- Visual inspection for physical damage, label integrity, and connector condition.
- Power-on functional verification where applicable.
- Cross-referencing of firmware version and hardware revision against B&R documentation.
- Secure anti-static packaging with humidity indicator cards for international shipment.
We source from authorized distributors, OEM decommissions, and certified refurbishers — never from unverified grey-market channels.
How to Source This Part
- In Stock: Add to cart and check out directly — most orders ship within 1–3 business days.
- Lead Time / MOQ: Contact us for volume pricing, blanket orders, or urgent delivery requirements.
- Custom Configuration: Need a specific firmware version or accessory bundle? Email us before ordering.
- Global Shipping: We ship worldwide via DHL Express, FedEx International, and UPS. Export documentation (commercial invoice, packing list, COO) provided on request.
- Payment: T/T (wire transfer), PayPal, and major credit cards accepted. Net-30 available for qualified accounts.
Application-Specific FAQ
Q: Is the 4PP350.0571-K01 compatible with B&R Automation Studio 4.x?
A: Yes. This Power Panel 350 unit is fully supported by Automation Studio 4.x for both PLC programming and HMI visualization development.
Q: Can this panel replace an older B&R 4PP320 or 4PP420 unit?
A: Mechanical and electrical compatibility varies by revision. Contact our technical team with your existing part number and we will confirm interchangeability before you order.
Q: What is the maximum number of I/O points supported?
A: Via POWERLINK, the Power Panel 350 can address up to 240 X20 I/O modules in a single network segment, supporting thousands of I/O points depending on module type.
Q: Does this unit support OPC UA or MQTT for IIoT connectivity?
A: OPC UA server functionality is available through B&R Automation Runtime with the appropriate software option. MQTT requires a custom mapp Technology or Automation Runtime configuration.
Q: What warranty do you offer?
A: Konmask.com provides a 90-day functional warranty on all units. Extended warranty and service contracts are available — contact us for details.
