B&R 5P5000:V1407 – Industrial System Controller | Automation Runtime Panel PC
Engineering Background
The B&R 5P5000:V1407 is a high-performance Panel PC from B&R Automation’s Power Panel 5000 series — a platform engineered for demanding industrial environments where deterministic control, integrated HMI, and long-term availability are non-negotiable. Designed to operate within B&R’s Automation Runtime (AR) ecosystem, this unit bridges real-time PLC logic and operator visualization in a single ruggedized enclosure.
Product Positioning
Targeted at OEM machine builders, system integrators, and plant automation engineers, the 5P5000:V1407 delivers a unified control architecture that eliminates the need for separate PLC and HMI hardware. It is the preferred choice for applications requiring high-cycle determinism, multi-axis coordination, and IEC 61131-3 compliance within a compact panel-mount form factor.
Complete Technical Specifications
- Part Number: 5P5000:V1407
- Series: Power Panel 5000 (PP5000)
- Manufacturer: B&R Industrial Automation GmbH
- Form Factor: Panel PC (integrated HMI + Controller)
- Operating System: B&R Automation Runtime (AR) / Windows Embedded (variant-dependent)
- Programming Environment: Automation Studio (IEC 61131-3: LD, FBD, SFC, ST, IL)
- Communication Interfaces: POWERLINK, Ethernet, USB, CAN (configuration-dependent)
- Display: Integrated TFT touchscreen (size per variant)
- I/O Expansion: Via X2X Link or POWERLINK remote I/O modules
- Power Supply: 24 VDC nominal
- Weight: ~500 g
- Mounting: Panel cutout / VESA (variant-dependent)
- Protection Rating: IP65 front panel (typical for PP5000 series)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: -20 °C to +60 °C
- Certifications: CE, UL (series-level)
- Country of Origin: Austria
Proven Application Environments
- Packaging machinery and filling lines requiring synchronized multi-axis motion
- Plastics injection molding with integrated process visualization
- Semiconductor and electronics assembly automation
- Food & beverage processing with hygienic panel-mount requirements
- Printing and converting machines with high-speed cam profiling
- Renewable energy control panels (wind, solar inverter management)
- Water treatment and utilities SCADA edge nodes
Engineering Advantages
- Unified Architecture: Eliminates PLC-to-HMI communication latency by integrating both functions on a single CPU
- Deterministic Control: Automation Runtime guarantees hard real-time task execution with microsecond-level cycle times
- POWERLINK Integration: Open-standard, Ethernet-based fieldbus for isochronous real-time I/O and drive communication
- Scalable I/O: X2X Link allows distributed I/O expansion without additional controllers
- Long-Term Availability: B&R’s 10-year spare parts commitment supports lifecycle planning for OEM machine builders
- Automation Studio Ecosystem: Single IDE for PLC, motion, HMI, safety, and network configuration
- IP65 Front Panel: Suitable for wash-down and dusty industrial environments
System Architecture & Signal Flow
The 5P5000:V1407 operates as the central node in a B&R POWERLINK network. The Automation Runtime kernel manages cyclic task scheduling at the hardware level, with HMI visualization tasks running in parallel under a separate priority class. Field I/O is connected via X2X Link backplane or remote POWERLINK I/O stations. Drive systems (ACOPOSmulti, ACOPOSmotor) communicate over POWERLINK with isochronous real-time synchronization. Safety functions are integrated via SafeLOGIC or SafeIO modules on the same network backbone, eliminating the need for a separate safety PLC.
Sourcing & Quality Verification
- Stock Origin: Sourced from authorized distributors and verified OEM surplus channels
- Inspection Protocol: Each unit undergoes visual inspection, label verification, and functional power-on check prior to shipment
- Authenticity: Serial numbers traceable to B&R production records upon request
- Packaging: Anti-static ESD packaging with desiccant; original B&R carton where available
- Warranty: 90-day Konmask operational warranty; extended warranty available on request
- Documentation: Datasheet, wiring diagram, and Automation Studio project templates available upon order confirmation
Procurement Process
- Step 1 – RFQ: Submit your part number and required quantity via email or the on-site inquiry form
- Step 2 – Quote: Receive a formal quotation within 1 business day including lead time and shipping options
- Step 3 – Order Confirmation: Purchase order accepted via email; proforma invoice issued for prepayment or net terms (qualified accounts)
- Step 4 – Inspection & Dispatch: Unit inspected, photographed, and dispatched within 2–5 business days
- Step 5 – Tracking & Support: Shipment tracking provided; technical support available post-delivery
- Accepted Payment: T/T (Wire Transfer), PayPal, Trade Assurance
- Shipping: DHL Express, FedEx International Priority, sea freight for bulk orders
Technical FAQ
Q: Is the 5P5000:V1407 compatible with Automation Studio 4.x?
A: Yes. The PP5000 series is fully supported in Automation Studio 4.x. Confirm the exact AR version required for your project and we can advise on firmware compatibility.
Q: Can this unit replace an older Power Panel 400/500 series?
A: In most cases yes, with a hardware migration project in Automation Studio. Contact our technical team for a migration feasibility assessment.
Q: Do you supply the matching POWERLINK cables and I/O modules?
A: Yes. Konmask stocks a broad range of B&R accessories including X2X Link cables, POWERLINK hubs, and X20 I/O modules. Request a BOM and we will quote the complete system.
Q: What is the lead time for out-of-stock units?
A: Typical sourcing lead time is 3–15 business days depending on global stock availability. Expedited sourcing available for critical production downtime situations.
Q: Can I request a functional test report before shipment?
A: Yes. A pre-shipment functional test with photographic evidence is available upon request (may incur a nominal testing fee).
