Burkert Type 2030 Piston-Operated Diaphragm Valve | Replacement, Equivalent & Selection Guide
The Burkert Type 2030 is a piston-operated diaphragm valve designed for precise flow control in demanding process environments. Operating at 5.5–7 Bar, this valve is widely used in semiconductor, pharmaceutical, and chemical processing systems. Part numbers covered: 95763693 / TTLA08-11 / F-MFC_AI_4 / 3808-020005-11 / 3881-020010-12.
Technical Specifications
- Brand: Burkert
- Series / Type: Type 2030
- Part Numbers: 95763693, TTLA08-11, F-MFC_AI_4, 3808-020005-11, 3881-020010-12
- Valve Type: Piston-Operated Diaphragm Valve
- Operating Pressure: 5.5–7 Bar
- Actuation: Pneumatic (piston-driven)
- Media Compatibility: Corrosive gases, ultra-pure liquids, aggressive chemicals
- Body Material: PTFE / PFA (wetted parts)
- Diaphragm Material: PTFE
- Connection: Tube / VCR / face-seal fittings (application-dependent)
- Weight: Approx. 2.6 kg
- Certifications: CE, RoHS compliant
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the Burkert Type 2030 in similar applications:
- Burkert Type 2031 – Pneumatically operated, similar diaphragm design, higher Cv options
- Burkert Type 2000 – Solenoid-operated diaphragm valve, suitable for on/off control
- Swagelok SS-DLV Series – Diaphragm valve for high-purity gas service
- Parker Hannifin Series 4 Diaphragm Valve – Compatible pressure range, PTFE wetted parts
- SMC VXD Series – Piston-operated, similar port sizing for process gas lines
- Entegris / Mykrolis Diaphragm Valves – Semiconductor-grade equivalents for ultra-pure media
Note: Always verify port size, Cv rating, pressure rating, and media compatibility before substituting. Contact Konmask for cross-reference verification.
Why Choose the Original Model
- Proven reliability in semiconductor fab and pharmaceutical GMP environments
- Precise pressure control at 5.5–7 Bar with minimal dead volume
- Ultra-pure wetted surfaces — PTFE diaphragm prevents contamination
- OEM-validated for MFC (Mass Flow Controller) integration (F-MFC_AI_4 configuration)
- Long service life with low maintenance diaphragm replacement design
- Drop-in compatibility with existing Burkert pneumatic actuator systems
Typical Applications
- Semiconductor wafer fabrication — process gas isolation and control
- Mass Flow Controller (MFC) inlet/outlet valve integration
- Pharmaceutical and biotech — sterile fluid handling
- Chemical processing — corrosive media flow control
- Laboratory analytical instruments — precise micro-flow regulation
- Ultra-pure water (UPW) systems in cleanroom environments
System Compatibility
- MFC Systems: Compatible with F-MFC_AI_4 mass flow controller configurations
- Pneumatic Supply: Requires clean dry air or N₂ at 5.5–7 Bar pilot pressure
- Control Interface: Compatible with standard 4–20 mA or digital valve controllers
- Mounting: Panel mount or inline installation; compatible with Burkert Type 8694 / 8695 valve islands
- Cross-reference OEM systems: Applied Materials, Tokyo Electron (TEL), Lam Research process tool platforms
Selection Guide
Use the following criteria to confirm the Burkert Type 2030 is the right valve for your application, or to identify a suitable alternative:
- Pressure range: If your system operates at 5.5–7 Bar pilot pressure → Type 2030 is a direct fit
- Media type: For corrosive or ultra-pure gas/liquid → PTFE-lined Type 2030 or equivalent Swagelok/Parker high-purity valve
- Control mode: On/off only → consider Burkert Type 2000 (solenoid); proportional control → Type 2030 or Type 2031
- Port size: Match tube OD or VCR fitting size to your existing process line
- Cycle life: High-cycle applications (>1M cycles) → verify diaphragm material and request extended-life variant
- Certifications required: SEMI F57, USP Class VI, or FDA compliance → confirm with Konmask sourcing team
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified OEM surplus channels
- Each valve undergoes visual inspection, pressure test, and functional verification before shipment
- Traceability documentation (CoC, test reports) available upon request
- Packaging: anti-static bag + foam-lined export carton for safe international shipping
- Lead time: In-stock units ship within 3–5 business days; sourced units within 2–4 weeks
How to Order
- Confirm part number: 95763693 or cross-reference via TTLA08-11 / 3808-020005-11 / 3881-020010-12
- Specify quantity and required delivery timeline
- Request a quote via support@konmask.com or add to cart directly
- Provide application details for compatibility verification if needed
- Payment: T/T, PayPal, or credit card accepted; export documentation provided
Replacement & Compatibility FAQ
Q: Can the Burkert Type 2031 directly replace the Type 2030?
A: In most cases yes — the Type 2031 shares the same diaphragm design and similar pressure ratings. Verify Cv value and port configuration before substituting.
Q: What does part number TTLA08-11 refer to?
A: TTLA08-11 is a Burkert internal configuration code indicating tube size, actuator type, and seal material. It maps directly to the Type 2030 base model with specific options.
Q: Is the F-MFC_AI_4 designation an MFC-specific variant?
A: Yes — F-MFC_AI_4 indicates this valve is configured for Mass Flow Controller analog input (4–20 mA) integration, optimized for semiconductor gas delivery systems.
Q: Can I use a Parker or Swagelok diaphragm valve as a drop-in replacement?
A: Functionally possible if pressure, Cv, and port specs match. However, OEM system qualification may require re-validation. Contact Konmask for a detailed cross-reference.
Q: Do you provide warranty on used or surplus units?
A: Yes — all units carry a 90-day functional warranty. Extended warranty available on request.
