Precision Motion Control Solution — NSK MCS06020P10K-302BZ | MCS Series
Where This Product Is Used
The NSK MCS06020P10K-302BZ Linear Stage Bearing Table is engineered for high-precision linear motion applications across demanding industrial and research environments. Typical deployment scenarios include:
- Semiconductor Wafer Handling & Inspection — Sub-micron positioning accuracy required for wafer alignment, lithography stage support, and optical inspection gantries.
- PCB Assembly & SMT Pick-and-Place — Reliable, repeatable linear travel for component placement heads and vision alignment systems.
- Laser Cutting & Marking Systems — Smooth, low-vibration travel for laser head positioning in CO₂ and fiber laser platforms.
- Coordinate Measuring Machines (CMM) — High-stiffness linear axis for dimensional metrology and quality inspection fixtures.
- Medical Device Manufacturing — Cleanroom-compatible motion for catheter assembly, micro-dispensing, and diagnostic equipment.
- Laboratory Automation & Life Sciences — Precise sample positioning for microscopy stages, liquid handling robots, and genomic sequencers.
- Optical Alignment & Photonics — Vibration-isolated linear travel for fiber alignment, lens positioning, and interferometry setups.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | NSK Ltd. |
| Part Number | MCS06020P10K-302BZ |
| Series | MCS (Monocarrier Stage) |
| Table Width | 60 mm |
| Lead / Ball Screw Pitch | 20 mm |
| Stroke | 100 mm (nominal — verify datasheet) |
| Drive Type | Ball Screw (Precision Ground) |
| Accuracy Grade | P10 (positioning accuracy class) |
| Preload Class | K (light preload) |
| Bearing Type | Linear Ball Bearing (recirculating) |
| Lubrication | Grease-lubricated (factory pre-filled) |
| Material | Hardened steel rail, aluminium alloy carriage |
| Weight | Approx. 400 g |
| Operating Temperature | 0 °C to +60 °C |
| Mounting Interface | Standard bolt pattern per NSK MCS series |
Note: Always cross-reference with the official NSK MCS series datasheet for your specific application load and duty cycle requirements.
Why Engineers Specify This Model
- Integrated Monocarrier Design — Rail, carriage, ball screw, and end blocks are factory-assembled and pre-aligned, eliminating field alignment errors and reducing integration time by up to 60%.
- P10 Accuracy Grade — Precision-ground ball screw delivers consistent positioning repeatability, critical for closed-loop servo and stepper-driven axes.
- K-Class Light Preload — Optimised for applications requiring low drive torque with minimal backlash, ideal for servo-driven positioning without excessive motor heating.
- Compact 60 mm Profile — Space-efficient cross-section fits within tight machine envelopes without sacrificing load capacity or rigidity.
- NSK Quality Pedigree — Manufactured under NSK’s global precision motion standards, with traceability to ISO quality management systems.
- Drop-in Replacement Compatibility — Standard MCS series bolt pattern ensures direct interchangeability with existing NSK MCS installations.
Complete System Bill of Materials
For a fully functional linear axis using the MCS06020P10K-302BZ, engineers typically specify the following complementary components:
- Servo motor or stepper motor with appropriate frame size (NEMA 17 / NEMA 23 or IEC equivalent)
- Motor coupling (jaw-type or bellows coupling, 6–10 mm bore)
- Motor mounting bracket (NSK MCS series compatible)
- Linear encoder or magnetic scale (optional, for closed-loop feedback)
- Home / limit switches (NPN or PNP, M8 inductive proximity type)
- Motor driver / servo amplifier (matched to motor specifications)
- Machine controller or PLC (e.g., Siemens S7-1200, Mitsubishi FX5U, Omron NX series)
- Cable carrier / energy chain for moving cable management
- Mounting base plate or sub-frame (aluminium profile or machined plate)
Contact support@konmask.com for BOM assistance and compatible component sourcing.
Compliance & Industry Standards
- ISO 9001 — NSK manufacturing facilities operate under ISO 9001 certified quality management systems.
- RoHS Compliant — Materials and lubricants selected to meet RoHS Directive 2011/65/EU requirements.
- CE Marking — Suitable for integration into CE-marked machinery when installed per NSK installation guidelines.
- JIS B 1192 — Conforms to Japanese Industrial Standards for ball screw accuracy grades.
- SEMI Standards — Applicable for semiconductor equipment integration per SEMI equipment guidelines (verify with your SEMI compliance officer).
Quality Assurance & Sourcing
Konmask.com sources NSK linear stage components exclusively through authorised distribution channels and verified industrial surplus networks. Every unit offered is subject to the following quality process:
- Visual and dimensional inspection upon receipt
- Verification of part number markings and NSK branding authenticity
- Functional travel check (smooth, backlash-free operation confirmed)
- Photographic documentation of actual stock condition
- Secure anti-static and foam-padded packaging for shipment
Condition is clearly stated on each listing (New / Surplus New / Refurbished). Contact us if you require a condition report or inspection photos prior to purchase.
How to Source This Part
- Add to Cart — Purchase directly online with HKD pricing. Multi-unit discounts available for orders of 3+ units.
- Request a Quote — Email support@konmask.com with your required quantity, delivery timeline, and destination country for a formal quotation.
- Confirm Lead Time — In-stock units ship within 1–3 business days from our warehouse. Out-of-stock units are sourced on request with typical lead times of 2–6 weeks.
- International Shipping — We ship globally via DHL Express, FedEx International, and SF Express. Export documentation (commercial invoice, packing list, HS code 8482.10) provided as standard.
- Payment — T/T bank transfer, PayPal, and major credit cards accepted. Letter of Credit (L/C) available for orders above USD 5,000.
Application-Specific FAQ
Q: Can this stage be used in a vertical (Z-axis) orientation?
A: Yes. The MCS series ball screw design supports vertical mounting. However, a motor brake or counterbalance is strongly recommended to prevent table drop during power-off conditions. Consult NSK’s load capacity tables for vertical duty cycle ratings.
Q: What is the maximum dynamic load capacity?
A: Refer to the NSK MCS06020 series datasheet for rated dynamic and static load values. As a general guide, the 60 mm width MCS series supports dynamic loads in the range of 1.5–4.0 kN depending on travel speed and duty cycle. Contact us for the full datasheet.
Q: Is this compatible with Siemens, Mitsubishi, or Omron servo systems?
A: Yes. The MCS06020P10K-302BZ is mechanically agnostic — it interfaces with any servo or stepper motor via a standard coupling. Electrical compatibility depends on your motor and driver selection, not the stage itself.
Q: What lubrication interval is recommended?
A: NSK recommends re-lubrication every 500–1,000 km of travel or every 6 months under normal operating conditions, whichever comes first. Use NSK Grease LG2 or equivalent lithium-based grease. Avoid mixing grease types.
Q: Can Konmask supply a matched pair for a dual-axis XY stage?
A: Yes. We can source matched units from the same production batch for XY gantry configurations. Please specify your XY stroke requirements and payload when enquiring.
Q: Do you provide a warranty?
A: New and Surplus New units carry a 90-day functional warranty against manufacturing defects. Refurbished units carry a 30-day warranty. Warranty claims are processed via support@konmask.com.
