Delta Tau PMAC2A-ETH 603871-108 – Ethernet Multi-Axis Motion Controller | PMAC2A Platform
Engineering Background
The PMAC2A-ETH (603871-108) is a high-performance Ethernet-enabled motion controller board developed by Delta Tau Data Systems, a recognized leader in advanced motion control for CNC, robotics, and industrial automation. The PMAC2A platform has been deployed globally in precision manufacturing, semiconductor equipment, and multi-axis servo systems requiring deterministic real-time control.
Product Positioning
Designed for procurement engineers and system integrators sourcing a proven, field-tested Ethernet motion controller, the PMAC2A-ETH 603871-108 delivers multi-axis coordinated motion, high-speed I/O, and seamless Ethernet connectivity in a single compact board. It is the preferred replacement and upgrade path for legacy PMAC2A installations requiring network-based communication.
Complete Technical Specifications
- Part Number: PMAC2A-ETH 603871-108
- Manufacturer: Delta Tau Data Systems (Delta Tau)
- Platform / Series: PMAC2A
- Communication Interface: Ethernet (10/100 Base-T)
- Motion Axes: Up to 8 axes coordinated motion (expandable)
- Processor: Motorola 56000-series DSP (high-speed real-time)
- Encoder Inputs: Quadrature incremental encoder, SSI, resolver-compatible
- Analog Outputs: ±10 V DAC per axis
- Digital I/O: Onboard general-purpose digital I/O
- Memory: Flash + SRAM for program and parameter storage
- Form Factor: PCB card (board-level module)
- Weight: Approx. 200 g
- Operating Temperature: 0 °C to 60 °C
- Power Supply: Supplied via host backplane or external regulated DC
- Software Compatibility: PEWIN32PRO2, PMAC Executive Pro 2, Delta Tau PLC ladder logic
- Protocol Support: TCP/IP, UDP, Modbus TCP (application-dependent)
- Condition: Genuine surplus / refurbished – tested and verified
Proven Application Environments
- CNC machining centers and multi-axis milling systems
- Semiconductor wafer handling and inspection equipment
- Laser cutting and engraving machines
- Robotic assembly lines and pick-and-place systems
- Medical imaging and laboratory automation platforms
- Printing and converting machinery
- Aerospace test rigs and precision positioning stages
Engineering Advantages
- Ethernet Connectivity: Eliminates proprietary bus dependency; integrates directly into plant Ethernet networks for remote monitoring and programming.
- Real-Time DSP Core: Deterministic servo loop execution at sub-millisecond cycle times ensures precise coordinated motion.
- Multi-Axis Coordination: Native support for linear, circular, and spline interpolation across multiple axes simultaneously.
- Backward Compatibility: Drop-in upgrade for existing PMAC2A installations with minimal re-engineering.
- Flexible I/O Architecture: Supports a wide range of encoder types and analog/digital I/O expansion.
- Field-Proven Reliability: Thousands of units deployed in demanding industrial environments worldwide.
System Architecture & Signal Flow
The PMAC2A-ETH 603871-108 operates as the central motion controller within a distributed automation architecture. The host PC or PLC communicates with the board via Ethernet TCP/IP using Delta Tau’s PCOMM32PRO library or direct socket commands. The DSP executes real-time servo algorithms, generating ±10 V analog command signals to servo drives. Encoder feedback is received directly on-board, closing the position loop at the controller level. Digital I/O lines interface with limit switches, home sensors, and auxiliary machine signals. The board supports background PLC program execution in parallel with foreground motion programs, enabling complex machine sequencing without host intervention.
Sourcing & Quality Verification
- All units sourced from verified industrial surplus channels and authorized distributors.
- Each board undergoes visual inspection, functional power-on test, and communication verification prior to shipment.
- Original Delta Tau firmware preserved; no unauthorized modifications.
- Traceability documentation available upon request for regulated industries.
- Packaging: ESD-safe anti-static bag with foam cushioning and outer carton protection.
Procurement Process
- Confirm Compatibility: Verify your existing PMAC2A backplane and software version against the 603871-108 revision. Contact our engineering team if unsure.
- Request a Quote: Submit your RFQ via email to support@konmask.com for volume pricing and lead time confirmation.
- Place Order: Secure checkout via Konmask.com. Accepts T/T wire transfer, credit card, and PayPal for international orders.
- Shipping: DHL / FedEx / UPS express worldwide. Typical dispatch within 1–3 business days after payment confirmation.
- After-Sales Support: 90-day warranty on all tested units. Technical support available via email and phone.
Technical FAQ
Q: Is the PMAC2A-ETH 603871-108 compatible with my existing PMAC2A system?
A: Yes, the PMAC2A-ETH is designed as a direct upgrade for PMAC2A installations. The Ethernet interface replaces the legacy serial/USB connection. Verify your backplane revision and firmware version for full compatibility.
Q: What software is required to program and commission this board?
A: Delta Tau PEWIN32PRO2 (PMAC Executive Pro 2) is the primary programming environment. PCOMM32PRO library is required for host PC communication via Ethernet.
Q: Can this controller support closed-loop servo control?
A: Yes. The PMAC2A-ETH closes the position loop on-board using encoder feedback, providing high-bandwidth servo control independent of the host PC.
Q: Do you provide a test report or inspection certificate?
A: A functional test report is available upon request. For regulated industries, additional traceability documentation can be arranged.
Q: What is the warranty period?
A: All tested surplus units carry a 90-day warranty covering functional defects. Extended warranty options are available for volume orders.
