Dunkermotoren PLG52-E40R24-GR42X40 DC Servo Motor | Integrated Encoder & Planetary Gearbox
The Dunkermotoren PLG52-E40R24-GR42X40 is a precision-engineered DC servo motor assembly combining a brushed DC motor core, an incremental encoder (E40R24), and a compact planetary gearbox (GR42X40) into a single integrated drive unit. Designed and manufactured in Germany, this assembly is a trusted solution for OEM machine builders and system integrators requiring reliable, compact servo motion in demanding industrial environments.
Part Numbers: 482-14811-00 | M1819-0002 | 263958-001
SKU: PLG52-E40R24-GR42X40-482-14811-00-M1819-0002-263958-001
Brand: Dunkermotoren (a Ametek company)
Origin: Germany
Complete Technical Specifications
- Motor Series: PLG52 Brushed DC Servo Motor
- Encoder Model: E40R24 – Incremental Encoder, 24 PPR
- Gearbox Model: GR42X40 – Planetary Gearbox, 42mm frame
- Motor Type: Brushed DC Permanent Magnet Servo Motor
- Frame Size: 52mm (motor) / 42mm (gearbox)
- Country of Origin: Germany (DE)
- Weight: Approx. 360 g (complete assembly)
- Part Numbers: 482-14811-00 / M1819-0002 / 263958-001
- Shaft Output: Planetary gearbox output shaft (GR42X40)
- Encoder Resolution: 24 pulses per revolution (PPR), incremental
- Mounting: Standard flange mount compatible with PLG52 series
- Condition: New / Surplus / Refurbished (specify at inquiry)
Proven Application Environments
- Automated assembly and pick-and-place machines
- Medical device actuators and laboratory automation
- Packaging and labeling equipment
- Robotics joint drives and end-effector positioning
- Semiconductor handling and precision stage control
- Textile and printing machinery feed drives
- AGV (Automated Guided Vehicle) drive modules
Engineering Advantages
- Integrated Assembly: Motor + encoder + gearbox pre-assembled and factory-aligned — eliminates coupling errors and reduces installation time.
- Planetary Gearbox Efficiency: GR42X40 planetary stage delivers high torque density with minimal backlash, ideal for precision positioning.
- Incremental Feedback: E40R24 encoder provides closed-loop position and velocity feedback compatible with standard servo drives and motion controllers.
- German Engineering: Manufactured to Dunkermotoren’s ISO-compliant quality standards with rigorous production testing.
- Compact Form Factor: 52mm motor frame with 42mm gearbox enables integration into space-constrained machine designs.
- Long Service Life: Precision brushed commutation system designed for extended duty cycles in industrial environments.
System Architecture & Signal Flow
The PLG52-E40R24-GR42X40 assembly operates as follows:
- Power Input → DC motor armature (PLG52 core) converts electrical energy to rotational torque.
- Encoder Feedback → E40R24 incremental encoder mounted on motor shaft outputs A/B quadrature signals (24 PPR) to the motion controller for closed-loop control.
- Gearbox Output → GR42X40 planetary gearbox reduces speed and multiplies torque at the output shaft for load actuation.
- Controller Interface → Compatible with standard PWM servo amplifiers and DC servo drives accepting encoder feedback.
Sourcing & Quality Verification
- All units sourced from authorized distributors, OEM surplus channels, or factory-refurbished stock.
- Each unit undergoes visual inspection and functional verification prior to shipment.
- Part numbers cross-referenced against Dunkermotoren official documentation: 482-14811-00 / M1819-0002 / 263958-001.
- Certificate of conformance available upon request for regulated industries.
- Packaging: Anti-static bag + foam-lined carton for safe international transit.
Procurement Process
- Step 1: Confirm part number and quantity with our technical team via support@konmask.com or +0086 19859288691.
- Step 2: Receive formal quotation with lead time and shipping options (DHL / FedEx / sea freight).
- Step 3: Place order via Konmask.com secure checkout or bank transfer (T/T).
- Step 4: Shipment with tracking number and packing list within 1–3 business days of payment confirmation.
- Step 5: Post-delivery technical support available for integration assistance.
Technical FAQ
Q: What is the voltage rating of the PLG52 motor?
A: The PLG52 series is available in multiple voltage configurations. Please contact us with your part number 482-14811-00 to confirm the exact rated voltage for this unit.
Q: Is the E40R24 encoder compatible with Siemens / Allen-Bradley / Mitsubishi drives?
A: Yes. The E40R24 outputs standard TTL-level A/B incremental signals compatible with most industrial servo drives. Confirm your drive’s encoder input specification before ordering.
Q: What is the gear ratio of the GR42X40 gearbox?
A: The GR42X40 designation indicates a 42mm frame planetary gearbox. The exact reduction ratio is configuration-specific — please provide your full part number for confirmation.
Q: Can you supply a datasheet or dimensional drawing?
A: Yes. Technical documentation is available upon request. Contact support@konmask.com with your part number.
Q: Do you offer warranty on this unit?
A: All units carry a 90-day functional warranty against defects. Extended warranty options available for volume orders.
