Emerson EPRO PR 6423/001-021-CN CON 041 – Eddy Current Vibration Sensor | EPRO Condition Monitoring Platform
Engineering Background
The EPRO PR 6423 series represents Emerson’s precision eddy current sensor technology, engineered for continuous shaft vibration and position monitoring in rotating machinery. Designed to meet the stringent demands of API 670 machinery protection systems, this sensor delivers sub-micron resolution in the harshest industrial environments.
Product Positioning
The PR 6423/001-021-CN CON 041 is a complete eddy current proximity sensor assembly configured for use with Emerson EPRO CON 041 signal conditioning electronics. It is the preferred choice for procurement engineers specifying vibration monitoring on turbines, compressors, pumps, and motors in power generation, oil & gas, and petrochemical facilities.
Complete Technical Specifications
- Part Number: PR 6423/001-021-CN CON 041
- Manufacturer: Emerson EPRO (formerly Bently Nevada EPRO)
- Series / Platform: PR 6423 Eddy Current Sensor System
- Sensor Type: Eddy Current Proximity / Vibration Sensor
- Compatible Driver / Conditioner: CON 041
- Cable Suffix: CN (standard integral cable)
- Measurement Range: 0–2 mm (typical, target-material dependent)
- Sensitivity: ~8 mV/µm (200 mV/mil) nominal
- Frequency Response: DC to 10 kHz (–3 dB)
- Operating Temperature: –40 °C to +120 °C (sensor body)
- Target Material: AISI 4140 steel or equivalent ferromagnetic alloy
- Tip Diameter: 8 mm
- Thread: M10 × 1 (standard)
- Cable Length: Per suffix specification (021 = 2.1 m extension)
- Output Signal: Voltage (DC bias + AC vibration component)
- Supply Voltage: –24 VDC (via CON 041 driver)
- Protection Rating: IP67 (sensor body)
- Compliance: API 670, CE, RoHS
- Weight: ~120 g (sensor + cable assembly)
- Country of Origin: Germany / USA (Emerson EPRO manufacturing)
Proven Application Environments
- Steam and gas turbine shaft radial vibration monitoring
- Centrifugal compressor rotor position and vibration measurement
- Pump and motor bearing proximity sensing
- Gearbox differential expansion and eccentricity measurement
- Power generation (nuclear, thermal, hydro) machinery protection
- Oil & gas upstream / midstream / downstream rotating equipment
- Petrochemical and refinery critical machinery trains
Engineering Advantages
- Non-contact measurement: Zero mechanical wear, infinite service life under normal conditions
- DC response: Captures both static position (gap) and dynamic vibration simultaneously
- High bandwidth: DC–10 kHz covers all relevant machinery fault frequencies
- API 670 compliance: Drop-in replacement for certified machinery protection systems
- Integral cable design (CN): Eliminates connector failure points in high-vibration zones
- Wide temperature range: Suitable for hot-section and cryogenic applications
- EMI immunity: Shielded coaxial cable rejects electrical noise in VFD-rich environments
System Architecture & Signal Flow
The PR 6423/001-021-CN operates as part of a three-component eddy current measurement chain:
- Sensor (PR 6423): Generates a high-frequency electromagnetic field at the probe tip. Eddy currents induced in the target shaft modulate the field impedance proportional to gap distance.
- Extension Cable (CN, 021 suffix): Transmits the modulated RF signal from the sensor to the driver with controlled impedance. Cable length is tuned to the driver calibration.
- Driver / Conditioner (CON 041): Demodulates the RF signal, applies linearization, and outputs a calibrated DC voltage (typically –2 VDC to –18 VDC over the measurement range) for connection to protection monitors (e.g., Emerson Ovation, CSI 6500, or third-party API 670 monitors).
Note: Sensor, extension cable, and driver must be ordered and calibrated as a matched set. Do not substitute individual components without recalibration.
Sourcing & Quality Verification
- All units sourced from authorized Emerson EPRO distribution channels or verified surplus with full traceability documentation
- Each unit inspected for physical integrity, connector condition, and cable continuity prior to shipment
- Original manufacturer labeling, date codes, and serial numbers preserved and verified
- Certificate of Conformance (CoC) available upon request
- Functional test reports available for select stock items
- Konmask.com maintains a zero-tolerance policy on counterfeit or refurbished-as-new components
Procurement Process
- Confirm compatibility: Verify your existing driver model (CON 041) and cable length requirement (021 = 2.1 m) match your installation
- Request a quote: Contact support@konmask.com for volume pricing, lead time, and CoC documentation
- Place order: Purchase directly via this product page or via PO to our sales team
- Shipping: DHL / FedEx express worldwide; export documentation (commercial invoice, packing list, HS code 9026.80) included
- After-sales: 12-month warranty on new units; technical support from our automation engineering team
Technical FAQ
Q: Can the PR 6423/001-021-CN be used with a CON 011 or CON 021 driver?
A: No. The sensor-cable-driver system is calibrated as a matched set. The CON 041 driver is specifically required for this part number. Using a different driver will result in incorrect sensitivity and linearity.
Q: What is the maximum cable extension length?
A: The 021 suffix denotes a 2.1 m integral cable. Total system cable length (sensor + extension) must match the driver calibration. Consult Emerson EPRO documentation for approved extension cable combinations.
Q: Is this sensor suitable for non-ferromagnetic targets (e.g., titanium, aluminum)?
A: The standard calibration is for AISI 4140 steel. Non-ferromagnetic or non-standard alloy targets require a custom calibration curve. Contact us for application engineering support.
Q: What is the difference between PR 6423/001-021-CN and PR 6423/010-021-CN?
A: The middle suffix (001 vs 010) denotes the sensor body configuration and mounting thread variant. Confirm your mounting hole specification before ordering.
Q: Do you provide installation and commissioning support?
A: Yes. Our automation engineering team can provide remote commissioning guidance, wiring diagrams, and driver configuration support. Contact support@konmask.com.
