Vibration & Proximity Monitoring Solution – Emerson EPRO PR6423/015-000 | EPRO Series
Where This Product Is Used
The Emerson EPRO PR6423/015-000 is an 8mm eddy current proximity sensor engineered for continuous, non-contact measurement of shaft displacement, vibration, and position in rotating machinery. It is widely deployed in:
- Steam & Gas Turbines – radial shaft vibration and axial position monitoring per API 670
- Centrifugal Compressors – rotor dynamic analysis and surge detection
- Pumps & Fans – bearing housing vibration and shaft orbit measurement
- Gearboxes – gear mesh frequency and differential expansion tracking
- Hydro Turbines & Motor-Generator Sets – air-gap and eccentricity monitoring
- Petrochemical & Refinery Plants – continuous machinery protection systems
- Power Generation Facilities – OEM and retrofit machinery protection panels
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | PR6423/015-000 |
| Brand / Series | Emerson EPRO |
| Sensor Tip Diameter | 8 mm |
| Cable Length | 1.5 m (integral cable) |
| Measurement Principle | Eddy Current (Non-contact) |
| Linear Range | 0 – 2 mm (nominal) |
| Sensitivity | 8 mV/µm (with compatible driver) |
| Operating Temperature | -35 °C to +120 °C |
| Target Material | Steel / Stainless Steel (AISI 4140 reference) |
| Protection Rating | IP67 |
| Connector | Integral coaxial cable, compatible with CON021 / CON041 drivers |
| Weight | Approx. 120 g |
| Compatible Drivers | PR6423 series, CON021, CON041 |
Why Engineers Specify This Model
- API 670 Compliant – meets the industry standard for machinery protection systems in oil & gas
- Non-contact measurement – zero mechanical wear, ideal for 24/7 continuous operation
- High linearity & repeatability – reliable shaft position data for predictive maintenance programs
- 8mm tip size – optimal for standard journal bearing applications and tight installation envelopes
- Integral 1.5m cable – reduces field wiring complexity and connector failure points
- Wide temperature range – suitable for hot sections of turbines and outdoor installations
- Drop-in replacement – fully compatible with existing EPRO PR6423 series installations
Complete System Bill of Materials
A complete eddy current measurement chain using the PR6423/015-000 typically includes:
- Sensor: PR6423/015-000 (this item) – 8mm probe, 1.5m cable
- Extension Cable: PR6422/xxx-xxx – field-selectable length (3m, 5m, 9m)
- Driver / Signal Conditioner: CON021 or CON041 – converts sensor impedance to 4–20 mA or voltage output
- Monitoring System: Emerson Bently Nevada 3500 series rack or equivalent
- Mounting Hardware: Stainless steel bracket, lock nut, and jam nut (application-specific)
Compliance & Industry Standards
- API 670 – Machinery Protection Systems (5th Edition)
- IEC 60068 – Environmental Testing
- CE Marking – EMC Directive 2014/30/EU
- RoHS Compliant
- ISO 10816 / ISO 7919 – Mechanical vibration evaluation guidelines
Quality Assurance & Sourcing
All Emerson EPRO components supplied by Konmask.com are:
- Sourced from authorized distributors and verified surplus channels
- Inspected for physical integrity, connector condition, and cable continuity prior to dispatch
- Shipped with original manufacturer packaging where available
- Traceable to batch documentation upon request
- Backed by our 90-day quality guarantee on all stocked items
How to Source This Part
- Add to Cart – for immediate in-stock orders with standard lead time
- Request a Quote – for volume orders (5+ units), OEM pricing, or project-based procurement
- Contact Our Team – for urgent requirements, cross-reference verification, or system integration support
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the PR6423/015-000 compatible with Bently Nevada 3500 series monitors?
A: Yes. When paired with a CON021 or CON041 driver, the output signal is fully compatible with Bently Nevada 3500 series proximity inputs.
Q: What is the difference between PR6423/015-000 and PR6423/010-000?
A: The /015-000 variant features a 1.5m integral cable, while /010-000 has a 1.0m cable. Tip diameter and sensitivity are identical.
Q: Can this sensor measure non-ferrous targets?
A: The PR6423 series is calibrated for AISI 4140 steel. Non-ferrous targets (aluminum, titanium) will require recalibration of the driver output.
Q: What is the recommended gap setting for radial vibration measurement?
A: Typically 1.0 mm (center of linear range), corresponding to approximately −10 VDC output with a standard CON021 driver.
Q: Do you provide calibration certificates?
A: Calibration certificates from the original manufacturer are provided where available. Third-party calibration can be arranged upon request.
