EMERSON KJ3002X1-BC1 12P0681X072 Analog Input Module | Replacement, Equivalent & Selection Guide
The EMERSON KJ3002X1-BC1 (Part No. 12P0681X072) is a high-precision Analog Input Module designed for the DeltaV™ Distributed Control System (DCS) platform. It provides reliable analog signal acquisition for process control environments in oil & gas, chemical, power generation, and other industrial sectors. This page serves as a comprehensive selection and sourcing reference for engineers, procurement specialists, and system integrators.
Technical Specifications
- Manufacturer: Emerson Electric / Fisher-Rosemount
- Part Number: KJ3002X1-BC1
- Reference Number: 12P0681X072
- Module Type: Analog Input (AI)
- Platform: DeltaV™ DCS Series
- Signal Types: 4–20 mA, 1–5 V (HART-compatible)
- Channels: 8-channel analog input
- Resolution: 16-bit A/D conversion
- Isolation: Channel-to-channel and channel-to-bus isolation
- Communication: DeltaV fieldbus backplane interface
- Power Supply: Supplied via DeltaV carrier/backplane
- Operating Temperature: 0°C to 60°C
- Certifications: CE, UL, FM (intrinsically safe variants available)
- Weight: Approx. 200 g
- Form Factor: DeltaV I/O card, plug-in module
Compatible Replacement & Equivalent Models
The following models are commonly referenced as functional equivalents or direct replacements for the KJ3002X1-BC1. Always verify firmware revision and carrier compatibility before substitution:
- KJ3002X1-BA1 – Earlier revision of the same AI module family; functionally equivalent in most DeltaV configurations
- KJ3002X1-BB1 – Intermediate revision; compatible with DeltaV v10.x and above
- KJ3002X1-BC2 – Upgraded variant with enhanced EMI shielding; drop-in replacement
- KJ3221X1-BA1 – 8-channel AI with HART pass-through; suitable for HART-enabled field devices
- KJ3002X1-BD1 – Latest revision in the KJ3002 series; recommended for new installations
- Third-party equivalents: Consult Konmask technical team for validated cross-reference to Yokogawa, Honeywell, or ABB analog input modules with DeltaV adapter solutions
Why Choose the Original Model
- Native DeltaV Integration: Plug-and-play compatibility with DeltaV M-Series, S-Series, and MX-Series controllers — no additional configuration required
- Proven Field Reliability: Widely deployed in critical process industries with documented MTBF exceeding 100,000 hours
- HART Transparency: Supports HART protocol pass-through for advanced diagnostics and field device management
- Emerson Lifecycle Support: Covered under Emerson’s Smart SIS and PlantWeb architecture; firmware updates and technical bulletins available
- Regulatory Compliance: Meets IEC 61511 SIL requirements for safety-instrumented systems when used in certified configurations
Typical Applications
- Temperature, pressure, flow, and level measurement in continuous process plants
- Oil & gas upstream/downstream SCADA and DCS integration
- Chemical reactor monitoring and batch process control
- Power plant boiler and turbine control loops
- Pharmaceutical manufacturing with 21 CFR Part 11 audit trail requirements
- Water treatment and municipal utility automation
System Compatibility
- DCS Platform: Emerson DeltaV™ v9.3 and above (v11.x–v15.x fully validated)
- Carrier Compatibility: 2-wide, 4-wide, and 8-wide DeltaV I/O carriers
- Controller Compatibility: MD, MD Plus, MX, M5, S-Series DeltaV controllers
- Redundancy: Supports simplex and redundant I/O configurations
- Fieldbus: Not applicable (traditional 4–20 mA wiring; separate FOUNDATION Fieldbus modules available)
Selection Guide
Use the following criteria to confirm the KJ3002X1-BC1 is the right module for your application:
- Signal type: Requires 4–20 mA or 1–5 V analog inputs → ✅ KJ3002X1-BC1 is suitable
- HART requirement: If HART device management is needed → consider KJ3221X1-BA1 instead
- Channel count: Need more than 8 channels per slot → consider KJ3002X1-BD1 or multi-module carrier layout
- SIL rating: SIL 2/3 safety loop → verify with Emerson SIS documentation; dedicated SIS modules may be required
- DeltaV version: Running v9.x or earlier → confirm firmware compatibility before ordering
- Revision matching: Mixing BC1 with BA1/BB1 revisions in redundant pairs is generally supported but should be validated in your specific DeltaV version release notes
Quality Assurance & Sourcing
- All modules sourced through Konmask.com are inspected for physical integrity, label authenticity, and functional verification prior to shipment
- Surplus and refurbished units are clearly labeled with condition grade (New Surplus / Refurbished / Used-Tested)
- Original factory packaging preserved where available; anti-static packaging used for all shipments
- Traceability documentation (COC, test reports) available upon request for critical applications
- 30-day return policy on verified non-functional units; warranty terms available on request
How to Order
- Online: Add to cart directly from this page — stock availability shown in real time
- Inquiry: Email [email protected] with your PO number, required quantity, and delivery timeline
- Phone/WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Bulk / Project Orders: Request a formal quotation for orders of 3+ units or project-based procurement
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days
Replacement & Compatibility FAQ
Q: Can I replace KJ3002X1-BC1 with KJ3002X1-BA1 without reconfiguring DeltaV?
A: In most cases yes — the module type is recognized identically by DeltaV. However, confirm your DeltaV version supports the BA1 revision and check for any applicable Emerson Product Data Sheets or Field Change Notices.
Q: Is the KJ3002X1-BC1 compatible with DeltaV SIS (Safety Instrumented System)?
A: The standard KJ3002X1-BC1 is not a certified SIS module. For SIL-rated loops, use Emerson’s dedicated SIS I/O modules (e.g., KJ3002X1 SIS variants) and consult your functional safety engineer.
Q: What is the difference between 12P0681X072 and other 12P0681X0xx reference numbers?
A: The 12P0681X0xx suffix denotes the manufacturing revision or regional variant. X072 is the standard commercial release. Contact Konmask for cross-reference verification if you have a different suffix.
Q: Can this module be used outside of a DeltaV system?
A: No — the KJ3002X1-BC1 is designed exclusively for the DeltaV backplane architecture and cannot be used as a standalone or third-party DCS module without significant hardware adaptation.
Q: Do you offer exchange / repair services?
A: Yes. Konmask partners with certified repair facilities for DeltaV I/O modules. Contact us with your failed unit details for a repair quotation.
