Process Temperature Measurement Solution — EMERSON KJ3002X1-BG2 | DeltaV Series
Where This Product Is Used
The EMERSON KJ3002X1-BG2 (P/N: 12P1731X032) Thermocouple Input Module is deployed in mission-critical temperature measurement loops across a wide range of industrial processes. Typical application environments include:
- Oil & Gas Upstream/Downstream: Wellhead temperature monitoring, crude distillation column profiling, and fired heater tube-skin measurement.
- Chemical & Petrochemical Plants: Reactor temperature control, heat exchanger performance monitoring, and exothermic process safety interlocks.
- Power Generation: Boiler flue gas temperature, steam turbine bearing monitoring, and combustion optimization loops.
- Pulp & Paper / Food & Beverage: Dryer section temperature profiling and pasteurization process control.
- Pharmaceutical Manufacturing: Sterilization cycle validation and clean-in-place (CIP) temperature verification.
Wherever a DeltaV DCS system governs temperature-critical processes, the KJ3002X1-BG2 is the OEM-specified I/O card of choice.
Technical Specifications
| Part Number | KJ3002X1-BG2 / 12P1731X032 |
| Manufacturer | Emerson Electric / Fisher-Rosemount |
| Module Type | Thermocouple (TC) Input Module |
| Platform | DeltaV Series — S-Series / M-Series Controllers |
| Input Channels | 8 Channels (isolated) |
| Thermocouple Types Supported | J, K, T, E, R, S, B, N (software-selectable per channel) |
| Input Range | –200 °C to +1820 °C (type-dependent) |
| Resolution | 16-bit A/D conversion |
| Cold Junction Compensation | Automatic, internal reference |
| Open-Circuit Detection | Yes — per channel, with configurable upscale/downscale drive |
| Communication Bus | DeltaV I/O Bus (proprietary) |
| Power Consumption | Supplied via I/O bus carrier |
| Operating Temperature | 0 °C to +60 °C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | Approx. 200 g |
| Form Factor | DeltaV I/O Card — plug-in module |
Why Engineers Specify This Model
- Native DeltaV Integration: Plug-and-play recognition within DeltaV Explorer — no manual address configuration or external signal conditioners required.
- Per-Channel TC Type Selection: A single module can simultaneously handle mixed thermocouple types (e.g., K-type on channels 1–4, J-type on channels 5–8), reducing BOM complexity.
- Automatic Cold Junction Compensation (CJC): Eliminates the need for external CJC hardware, improving accuracy and reducing panel wiring.
- Open-Wire Fault Detection: Each channel independently detects open-circuit faults and drives the process value to a configurable safe state — critical for SIL-rated safety loops.
- Hot-Swap Capable: Modules can be replaced under power without shutting down the controller, minimizing process downtime during maintenance windows.
- Proven Field Reliability: Widely deployed in Emerson DeltaV installations globally since the S-Series platform launch; extensive installed base ensures long-term spare parts availability.
Complete System Bill of Materials
For a fully operational DeltaV thermocouple input subsystem, the following components are typically required alongside the KJ3002X1-BG2:
- I/O Carrier / Baseplate: KJ3001X1-BA1 or compatible 8-slot I/O carrier
- DeltaV Controller: MD Plus, MD, or S-Series controller (e.g., KJ2003X1-BA1)
- Power Supply: DeltaV 12 VDC I/O bus power supply (e.g., KJ1501X1-BF2)
- Marshalling Cabinet / Terminal Blocks: Thermocouple-grade terminal blocks with CJC compensation strips
- Thermocouple Extension Cable: Matched alloy extension wire per TC type (IEC 60584 / ANSI MC96.1)
- DeltaV Workstation: DeltaV Operate / DeltaV Explore engineering workstation license
Contact [email protected] for bundle pricing on multi-module orders.
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU
- UL Listed / CSA Certified (Class I, Division 2 rated enclosure when installed per Emerson guidelines)
- IEC 61511 / IEC 61508 — Functional Safety (SIL 1 capable in appropriate safety loop architecture)
- IEC 60584 — Thermocouple calibration standards
- RoHS 2 Compliant (Directive 2011/65/EU)
- ATEX / IECEx — consult Emerson documentation for hazardous area installation requirements
Quality Assurance & Sourcing
Konmask.com sources the KJ3002X1-BG2 through verified industrial automation supply channels. Every unit offered is:
- Inspected for physical integrity (connector pins, PCB, label legibility) prior to listing
- Cross-referenced against Emerson’s published part number matrix to confirm revision compatibility
- Stored in ESD-safe packaging in a climate-controlled warehouse
- Shipped with original manufacturer labeling and, where available, original packaging
We do not sell counterfeit, refurbished-as-new, or unverified grey-market components. All listings reflect actual stock condition.
How to Source This Part
- Confirm Compatibility: Verify your DeltaV controller series and I/O carrier revision against Emerson’s I/O compatibility matrix (available on Emerson’s support portal).
- Check Quantity & Lead Time: Contact us at [email protected] or call +0086 19859288691 for real-time stock confirmation and bulk pricing.
- Place Order: Add to cart directly on Konmask.com or request a formal quotation for PO-based procurement.
- Shipping: DHL / FedEx / UPS express available worldwide. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- After-Sales Support: Technical questions on installation and DeltaV configuration answered by our engineering team.
Application-Specific FAQ
Q: Is the KJ3002X1-BG2 compatible with DeltaV Version 14.x and later?
A: The KJ3002X1-BG2 is a legacy S-Series I/O module. Compatibility with DeltaV v14+ should be confirmed against Emerson’s release notes. For newer installations, Emerson’s Electronic Marshalling (CHARM) platform may be specified instead. Contact us for guidance.
Q: Can this module be used in a Safety Instrumented System (SIS)?
A: The KJ3002X1-BG2 is a standard I/O module, not a certified SIS module. For SIL-rated safety loops, Emerson’s DeltaV SIS platform with dedicated safety I/O (e.g., KJ3002X1-BH2 or equivalent SIS-certified variant) must be used.
Q: What is the difference between KJ3002X1-BG2 and KJ3002X1-BG1?
A: The BG2 revision incorporates minor firmware and hardware updates over BG1. In most DeltaV installations, the revisions are interchangeable, but always verify with your site’s DeltaV version compatibility matrix before substitution.
Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 90-day functional warranty on all modules. Units that fail under normal operating conditions within the warranty period will be replaced or refunded. See our full warranty policy at Konmask.com.
Q: Can I return the module if it doesn’t fit my system?
A: We accept returns within 30 days of delivery for unused, uninstalled modules in original condition. Please contact [email protected] to initiate a return authorization.
