EMERSON KJ3221X1-BA1 DeviceNet Communication Card | Replacement, Equivalent & Selection Guide
The EMERSON KJ3221X1-BA1 (Part No. 12P2531X102) is a DeviceNet communication card designed for the DeltaV S-Series distributed control system. It enables seamless integration of DeviceNet field devices — including sensors, actuators, and drives — into the DeltaV process automation environment. As an authorized sourcing partner, Konmask.com supplies genuine, tested, and traceable units with full documentation support.
Technical Specifications
- Manufacturer: Emerson Electric / Fisher-Rosemount
- Model Number: KJ3221X1-BA1
- Part Number: 12P2531X102
- Product Series: DeltaV S-Series
- Function: DeviceNet Scanner / Communication Card
- Protocol: DeviceNet (CAN-based, IEC 62026-3)
- Bus Speed: 125 kbps / 250 kbps / 500 kbps (auto-detect)
- Max Nodes: Up to 64 nodes per network segment
- Power Supply: Supplied via DeltaV S-Series carrier
- Operating Temperature: 0°C to 60°C
- Weight: 180 g
- Certifications: CE, UL, ODVA Conformance Tested
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or functional equivalents. Always verify firmware compatibility and DeltaV version support before substitution:
- EMERSON KJ3221X1-BA2 — Revised hardware revision; functionally equivalent, check carrier slot compatibility
- EMERSON KJ3221X1-BB1 — Extended temperature variant for harsh environments
- Rockwell 1769-SDN — CompactLogix DeviceNet Scanner; requires gateway or protocol converter for DeltaV integration
- Rockwell 1756-DNB — ControlLogix DeviceNet Bridge; third-party integration via OPC or EtherNet/IP gateway
- Hilscher CIFX 50-DN — Universal DeviceNet master card; suitable for PC-based SCADA bridging
Note: Third-party replacements require additional configuration. Contact Konmask for cross-reference validation.
Why Choose the Original KJ3221X1-BA1
- Native DeltaV Integration: Plug-and-play with DeltaV S-Series carriers — no additional drivers or gateways required
- Certified ODVA Conformance: Ensures interoperability with all ODVA-certified DeviceNet devices
- Emerson Firmware Support: Eligible for DeltaV software updates and Emerson Global Services support contracts
- Proven Reliability: Widely deployed in oil & gas, chemical, and power generation industries
- Traceability: Full manufacturing traceability and certificate of conformance available
Typical Applications
- Oil & gas upstream/downstream process control
- Chemical and petrochemical plant automation
- Power generation and utilities
- Pharmaceutical batch processing (FDA 21 CFR Part 11 environments)
- Water and wastewater treatment facilities
- Pulp and paper manufacturing
System Compatibility
- DCS Platform: Emerson DeltaV S-Series (S-Plus, SX, SQ controllers)
- DeltaV Software: v10.3 and above (v13+ recommended for full feature support)
- Carrier Compatibility: DeltaV 8-slot and 12-slot S-Series carriers
- Field Devices: Any ODVA-certified DeviceNet device (Class 1 and Class 3 connections)
- Not Compatible With: DeltaV M-Series or MD-Series controllers without adapter hardware
Selection Guide
Use this guide to confirm the KJ3221X1-BA1 is the right card for your application:
- Step 1 — Confirm DCS Platform: Verify your controller is DeltaV S-Series (SX, SQ, or S-Plus)
- Step 2 — Check Slot Availability: Confirm an open I/O slot on your S-Series carrier
- Step 3 — Count DeviceNet Nodes: Ensure total node count ≤ 64 per card; add additional cards for larger networks
- Step 4 — Verify Bus Speed: Match bus speed (125/250/500 kbps) to existing network configuration
- Step 5 — DeltaV Version: Confirm DeltaV software version ≥ v10.3; upgrade if necessary
- Step 6 — Quantity: For redundancy-critical applications, consider ordering a spare unit
Quality Assurance & Sourcing
- ✅ Genuine OEM Units: Sourced directly from authorized Emerson distributors and certified supply chains
- ✅ Pre-shipment Testing: Each unit undergoes functional verification before dispatch
- ✅ Certificate of Conformance: Available upon request for regulated industries
- ✅ Anti-counterfeit Verification: Holographic labels and serial number traceability
- ✅ Warranty: 12-month warranty against manufacturing defects
- ✅ Export Compliance: EAR/ECCN classification available; export documentation supported
How to Order
- Add the KJ3221X1-BA1 (12P2531X102) to your cart on this page
- For bulk orders (>3 units) or urgent requirements, contact us directly for priority pricing
- Provide your DeltaV version and application details for pre-sales technical validation
- Request a formal quotation with lead time confirmation via support@konmask.com
Replacement & Compatibility FAQ
Q: Can KJ3221X1-BA1 replace KJ3221X1-BA2?
A: Yes, in most cases. The BA2 is a hardware revision of the BA1. Verify your DeltaV version supports both revisions before swapping.
Q: Is this card compatible with DeltaV M-Series?
A: No. The KJ3221X1-BA1 is designed exclusively for the S-Series carrier architecture. M-Series requires a different card family.
Q: Can I use a Rockwell 1756-DNB as a drop-in replacement?
A: No. The 1756-DNB is a ControlLogix module and requires a separate controller platform. Integration with DeltaV would require an OPC or EtherNet/IP gateway.
Q: What is the lead time for KJ3221X1-BA1?
A: Standard stock items ship within 3–7 business days. Contact us for current availability and expedited options.
Q: Do you provide installation support?
A: Yes. Konmask offers remote technical support for DeltaV configuration and DeviceNet commissioning. Contact support@konmask.com.
