CNC Machining & Robotics Motion Control Solution – FANUC A06B-6096-H105 | α Series Servo Amplifier
Where This Product Is Used
The FANUC A06B-6096-H105 is a high-performance servo amplifier module from FANUC’s α (Alpha) Series, engineered for precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machining Centers – Drives X/Y/Z axis servo motors on vertical and horizontal machining centers requiring tight positional accuracy (±0.001 mm).
- CNC Turning Centers & Lathes – Controls spindle and feed axis drives on FANUC 0i, 16i, 18i, 21i, and 30i/31i/32i controller platforms.
- Industrial Robots – Integrated into FANUC robot controllers (R-J3, R-30iA/B) for joint servo drive applications.
- Injection Molding Machines – Provides closed-loop servo control for clamping and injection axis drives.
- Grinding & EDM Equipment – Delivers smooth, low-ripple torque output critical for surface finish quality.
- Automated Assembly Lines – Coordinates multi-axis motion in pick-and-place and gantry systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | A06B-6096-H105 |
| Series | FANUC α (Alpha) Series |
| Module Type | Servo Amplifier Module (Single Axis) |
| Compatible Controllers | FANUC 0i / 16i / 18i / 21i / 30i / 31i / 32i |
| Input Voltage | 3-Phase AC 200–240 V, 50/60 Hz |
| Output Current (Continuous) | 5 A (rated) |
| Feedback Interface | Serial Pulse Coder (SPC) / αA Encoder |
| Communication Bus | FSSB (FANUC Serial Servo Bus) |
| Cooling Method | Forced air cooling (internal fan) |
| Protection Class | IP20 (panel-mount) |
| Weight | 4.46 kg |
| Mounting | DIN rail / panel mount |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 60 °C |
Why Engineers Specify This Model
- FSSB High-Speed Bus – FANUC Serial Servo Bus enables ultra-low latency (62.5 µs cycle) communication between CNC controller and drive, ensuring sub-micron contouring accuracy.
- Adaptive Acceleration Control – Built-in vibration suppression and adaptive tuning reduce mechanical resonance without manual parameter adjustment.
- Regenerative Braking – Integrated regenerative circuit recovers deceleration energy, reducing heat dissipation and extending capacitor life.
- Plug-and-Play Replacement – Direct drop-in replacement for existing α Series installations; no re-parameterization required when swapping identical units.
- Proven Field Reliability – FANUC α Series amplifiers are deployed in millions of machine tools globally with documented MTBF exceeding 50,000 hours.
- Compact Form Factor – Slim module design maximizes cabinet space utilization in retrofit and OEM panel builds.
Complete System Bill of Materials
For a fully operational FANUC servo axis, the following components are typically required alongside the A06B-6096-H105:
- CNC Controller – FANUC 0i-MD / 30i-B (e.g., A02B-0319-B500)
- Servo Motor – FANUC αiS or αiF Series (e.g., A06B-0227-B100)
- Power Supply Module (PSM) – FANUC A06B-6087-H126 or equivalent α Series PSM
- Spindle Amplifier Module (SPM) – A06B-6096-H206 (if spindle axis required)
- Encoder Cable – A66L-0001-0284 (SPC feedback cable, motor to amplifier)
- FSSB Fiber Optic Cable – A66L-6001-0026 (controller to amplifier bus)
- 24 VDC Control Power Supply – A06B-6110-H015 or equivalent
- Emergency Stop / Safety Relay Module – Per machine safety circuit design
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- RoHS Compliant – Restriction of Hazardous Substances Directive 2011/65/EU
- ISO 9001:2015 – Manufactured under FANUC’s certified quality management system
- IEC 61800-3 – Adjustable speed electrical power drive systems EMC requirements
Quality Assurance & Sourcing
Every FANUC A06B-6096-H105 unit offered by Konmask.com undergoes a rigorous pre-shipment verification process:
- ✅ Visual Inspection – PCB, connectors, and housing checked for physical damage, corrosion, or counterfeit indicators.
- ✅ Power-On Functional Test – Unit energized and servo loop closed to verify drive response and alarm-free operation.
- ✅ Firmware Version Check – Software version logged and documented with shipment records.
- ✅ Authenticity Verification – Serial number cross-referenced against FANUC production records where applicable.
- ✅ ESD-Safe Packaging – Shipped in anti-static foam-lined carton with desiccant to prevent moisture ingress during transit.
Units are sourced from decommissioned OEM equipment, authorized distributors, or certified refurbishers. Condition (new / refurbished / tested-used) is clearly stated on each listing.
How to Source This Part
- Confirm your CNC controller model – Check the controller nameplate or FANUC parameter screen (MDI → SYSTEM → CONFIG) to verify compatibility.
- Verify the motor pairing – Match the amplifier current rating to your servo motor’s rated current (αiS 4/4000 → 5 A amplifier).
- Add to cart & request a quote – For volume orders (3+ units) or urgent requirements, contact us directly for priority allocation.
- Receive with documentation – Each shipment includes a test report, packing list, and tracking number via DHL / FedEx / SF Express.
📦 Lead Time: In-stock units ship within 1–2 business days. Out-of-stock units: 7–15 business days sourcing lead time.
🌍 Shipping: Worldwide. Export documentation (commercial invoice, packing list, CO if required) provided for customs clearance.
Application-Specific FAQ
Q: Is the A06B-6096-H105 compatible with FANUC 0i-MF controllers?
A: Yes. The α Series amplifier is compatible with FANUC 0i-MF, 0i-TF, and 0i-PF controllers via FSSB. Verify the axis count and amplifier slot assignment in the CNC parameters (PRM 1023).
Q: Can this module replace an A06B-6096-H106 or H108?
A: The H105, H106, and H108 differ in output current rating (5 A, 10 A, 20 A respectively). Substitution is only permissible if the replacement unit’s current rating meets or exceeds the motor’s rated current. Do not downsize the amplifier current rating.
Q: What alarm codes indicate a failed servo amplifier?
A: Common FANUC alarms pointing to amplifier failure include SV401 (VRDY OFF), SV436 (Soft thermal OVC), SV417 (Servo parameter error), and LED fault codes on the amplifier front panel (e.g., “8” = IPM fault, “A” = overcurrent). Always check the amplifier LED display before replacement.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. Warranty covers drive failure under normal operating conditions. Physical damage, incorrect installation, or overvoltage events are excluded.
Q: Can you supply the matching PSM and SPM modules?
A: Yes. Contact us with your full BOM and we will provide a consolidated quote for the complete α Series drive stack.
