FUJI NP1PS-117R – High-Performance CPU Module | MICREX-NX Series Platform
Engineering Background
The FUJI NP1PS-117R is a central processing unit module designed for the MICREX-NX programmable logic controller platform — FUJI Electric’s flagship mid-to-large scale industrial automation architecture. Built to IEC 61131-3 standards, this CPU module serves as the computational core for complex discrete and process control applications across demanding industrial environments. Konmask.com sources this module directly through verified OEM and authorized distribution channels, ensuring full traceability and authenticity for mission-critical deployments.
Product Positioning
The NP1PS-117R targets automation engineers and system integrators who require deterministic scan-cycle performance, robust I/O expansion capability, and long-term platform continuity. It is the preferred choice for new installations and legacy MICREX-NX system expansions where backward compatibility and proven field reliability are non-negotiable.
Complete Technical Specifications
| Manufacturer | FUJI Electric Co., Ltd. |
| Part Number | NP1PS-117R |
| Series / Platform | MICREX-NX |
| Module Type | CPU Module (Central Processing Unit) |
| Program Memory | 117K steps (ladder / structured text) |
| Data Memory | High-capacity internal data registers |
| I/O Points (Max) | Up to 4,096 I/O points (system-dependent) |
| Communication Ports | RS-232C loader port; optional Ethernet / FL-net via expansion |
| Programming Standard | IEC 61131-3 (Ladder, SFC, ST, FBD) |
| Scan Time | High-speed deterministic execution |
| Power Supply | Supplied via backplane (NP1B-□□ series base unit) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 10% to 90% RH (non-condensing) |
| Vibration Resistance | IEC 60068-2-6 compliant |
| Weight | Approx. 160 g |
| Mounting | DIN rail / panel mount via MICREX-NX base unit |
| RoHS Compliance | Yes |
| Country of Origin | Japan |
Proven Application Environments
- Automotive Manufacturing — Body assembly lines, press control, and robotic cell coordination
- Food & Beverage Processing — Hygienic conveyor sequencing, batch control, and CIP cycle management
- Semiconductor Fabrication — Clean-room equipment control with deterministic timing requirements
- Water Treatment & Utilities — SCADA-integrated pump station and filtration control
- Packaging Machinery — High-speed pick-and-place, labeling, and case-packing lines
- Chemical & Petrochemical Plants — Continuous process monitoring with redundancy support
- Building Automation & Infrastructure — HVAC, elevator control, and energy management systems
Engineering Advantages
- Large Program Capacity (117K Steps) — Accommodates complex multi-zone control logic without segmentation constraints
- Deterministic Scan Cycle — Ensures predictable real-time response for time-sensitive process control
- Scalable I/O Architecture — Supports up to 4,096 I/O points via modular expansion on MICREX-NX backplane
- IEC 61131-3 Multi-Language Support — Engineers can use Ladder, SFC, ST, or FBD within a single project
- Long Product Lifecycle — FUJI Electric’s commitment to extended platform support reduces obsolescence risk
- Hot-Swap Compatible Base Design — Minimizes downtime during module replacement in supported configurations
- Robust EMC Performance — Designed for electrically noisy industrial environments per IEC standards
System Architecture & Signal Flow
The NP1PS-117R slots into the MICREX-NX base unit (NP1B series), where it communicates with I/O modules, special function modules, and communication modules via the internal high-speed backplane bus. The CPU executes the user program cyclically: Input Refresh → Program Execution → Output Refresh → Peripheral Service. External programming and monitoring is performed via the RS-232C loader port using FUJI’s SX-Programmer Expert (D300win) software. For networked architectures, FL-net or Ethernet communication modules can be added to the same base unit to integrate the NP1PS-117R into plant-wide SCADA or MES systems.
Sourcing & Quality Verification
- OEM Traceability — All units sourced through verified FUJI Electric authorized channels with full documentation
- Pre-Shipment Inspection — Each module undergoes visual inspection and functional verification before dispatch
- Authentic Labeling — Original FUJI Electric part labels, serial numbers, and date codes intact
- Packaging Integrity — Anti-static ESD packaging with humidity indicator cards for sensitive electronics
- Warranty Coverage — 12-month warranty against manufacturing defects from date of shipment
Procurement Process
- Inquiry & Quotation — Contact support@konmask.com with your project BOM or required quantity for a formal quotation within 24 hours
- Order Confirmation — Purchase order accepted via email; proforma invoice issued for payment processing
- Payment — T/T (bank transfer), PayPal, or other agreed terms; payment confirmation triggers order fulfillment
- Shipment — DHL / FedEx / UPS express with full tracking; export documentation (commercial invoice, packing list, COO) provided
- After-Sales Support — Technical assistance available post-delivery; RMA process for warranty claims
Technical FAQ
Q: Is the NP1PS-117R compatible with older MICREX-F series bases?
A: No. The NP1PS-117R is designed exclusively for the MICREX-NX platform (NP1B series base units). It is not backward-compatible with MICREX-F or MICREX-SX hardware.
Q: What programming software is required?
A: FUJI SX-Programmer Expert (D300win) is the standard tool. Ensure you have the correct version compatible with NX-series CPU firmware.
Q: Can this CPU support redundant configurations?
A: Redundancy configurations depend on the specific MICREX-NX system design. Please consult the FUJI NX-series system manual or contact our technical team for your specific topology.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 1–3 business days. For large quantities or special configurations, lead time will be confirmed at quotation stage.
Q: Do you provide a test report or inspection certificate?
A: Yes. A pre-shipment inspection report is available upon request. Third-party inspection can be arranged for large orders.
