Inverter Drive Control Solution – FUJI PRTM-040-MIG15Q901H | FUJI Electric Control Board Series
Where This Product Is Used
The FUJI PRTM-040-MIG15Q901H is a dedicated control board (PCB) designed for use inside FUJI Electric variable frequency drives (VFDs) and inverter systems. It is commonly deployed in the following industrial environments:
- Manufacturing plants – motor speed control on conveyor lines, mixers, and compressors
- HVAC systems – fan and pump inverter drive regulation in commercial buildings
- Water treatment facilities – precise flow control via VFD-driven pumps
- Packaging machinery – synchronised multi-axis motion requiring stable drive control
- Crane & hoist systems – torque-controlled lifting with FUJI inverter platforms
- CNC machining centres – spindle drive control requiring low-noise, high-reliability PCBs
This board serves as the primary control interface between the inverter’s CPU logic and the IGBT power stage, making it a critical component for drive reliability and uptime.
Technical Specifications
| Parameter | Detail |
|---|---|
| Part Number | PRTM-040-MIG15Q901H |
| Manufacturer | FUJI Electric Co., Ltd. |
| Component Type | Inverter / VFD Control Board (PCB Assembly) |
| Compatible Platform | FUJI FRENIC Series Inverters |
| Board Function | Drive control, gate signal processing, fault detection |
| Weight | Approx. 800 g (packaged) |
| Condition | New / Surplus New |
| Shipping | Worldwide – EMS / DHL / FedEx |
Note: Full electrical ratings (voltage, current, frequency range) are defined by the parent inverter unit. Consult the FUJI FRENIC series datasheet for system-level specifications.
Why Engineers Specify This Model
- OEM-grade reliability – manufactured to FUJI Electric’s original design tolerances, ensuring drop-in compatibility with existing drive enclosures
- Reduced downtime – stocking this board as a spare eliminates multi-week lead times from OEM channels during unplanned failures
- Proven gate driver architecture – the MIG15Q901H IGBT module pairing is a well-documented, field-tested combination in FUJI inverter platforms
- Plug-and-play replacement – connector layout and firmware compatibility maintained across production batches
- Traceable sourcing – Konmask.com sources from authorised distributors and verified surplus channels with full documentation
Complete System Bill of Materials
For a complete FUJI inverter drive repair or spare-parts kit, engineers typically source the following alongside the PRTM-040-MIG15Q901H:
- FUJI MIG15Q901H IGBT Power Module
- FUJI FRENIC Series Main Circuit Board
- FUJI Keypad / Operator Panel (TP-E1U or equivalent)
- DC Bus Capacitor Bank (matched to inverter kW rating)
- Gate Driver Optocoupler (e.g., HCPL-316J or equivalent)
- Cooling Fan Assembly (matched to inverter frame size)
Contact support@konmask.com for bundled BOM pricing.
Compliance & Industry Standards
- Manufactured under ISO 9001 quality management system
- Compatible with CE-marked FUJI FRENIC inverter platforms
- RoHS compliance status: subject to original FUJI Electric production batch — confirm with Konmask team for specific lot documentation
- Suitable for use in installations governed by IEC 61800 (adjustable speed electrical power drive systems)
Quality Assurance & Sourcing
Konmask.com applies a multi-stage verification process to all industrial control components:
- Visual inspection – PCB surface, solder joints, connector integrity, and component markings checked against OEM reference
- Functional bench test – where applicable, boards are powered and signal outputs verified prior to dispatch
- Anti-static packaging – all PCBs shipped in ESD-safe bags with foam cushioning and rigid outer carton
- Traceability documentation – purchase records and inspection reports available on request
How to Source This Part
- Add FUJI PRTM-040-MIG15Q901H to your cart and proceed to checkout
- For bulk / project orders (3+ units), email support@konmask.com for a volume quotation
- For urgent same-day enquiries, call or WhatsApp +0086 19859288691
- Lead time: in-stock orders ship within 1–2 business days; ETA varies by destination
- Payment: T/T bank transfer, PayPal, and major credit cards accepted
Application-Specific FAQ
Q: Is the PRTM-040-MIG15Q901H compatible with all FUJI FRENIC inverter models?
A: This board is designed for specific FUJI FRENIC series frames. Please share your inverter’s full model number with our team to confirm compatibility before ordering.
Q: Can I replace just the control board without replacing the IGBT module?
A: Yes, in most cases the control board can be replaced independently. However, if the IGBT module (MIG15Q901H) has also failed, both should be replaced simultaneously to prevent repeat failures.
Q: Do you provide installation support?
A: Konmask.com provides basic installation guidance and wiring reference documentation. For on-site commissioning, we recommend engaging a certified FUJI Electric service partner.
Q: What is your return policy for control boards?
A: Unused boards in original packaging may be returned within 30 days. Boards that have been installed are subject to our technical review process — contact support for details.
Q: Can you source other FUJI Electric spare parts?
A: Yes. Konmask.com maintains an extensive catalogue of FUJI Electric automation components. Submit your parts list to support@konmask.com for availability and pricing.
