GE 369B1848G5001 – Resistance Temperature Detector (RTD) Module | MVP10 Platform
Engineering Background: The GE 369B1848G5001 is a precision Resistance Temperature Detector (RTD) input module developed under GE’s MVP10 platform for power generation and industrial turbine control systems. Designed to interface directly with GE Mark series control architectures, this module provides accurate, low-drift temperature measurement critical to generator protection and turbine health monitoring.
Product Positioning: Targeted at maintenance engineers and procurement specialists managing GE-based power plant control systems, the 369B1848G5001 serves as a direct OEM replacement for aging RTD input cards. Its compatibility with GE’s Mark IV, Mark V, and Mark VI control panels makes it a preferred sourcing choice for both planned overhauls and emergency replacements.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 369B1848G5001 |
| Series / Platform | GE MVP10 |
| Module Type | Resistance Temperature Detector (RTD) Input Module |
| Manufacturer | GE (General Electric Energy) |
| RTD Input Type | 3-wire PT100 / PT1000 (Platinum RTD) |
| Measurement Range | -200°C to +850°C (sensor dependent) |
| Accuracy | ±0.1°C (typical, at calibrated conditions) |
| Input Channels | Multi-channel RTD acquisition |
| Communication Interface | GE Mark series backplane bus |
| Power Supply | 24 VDC (via backplane) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Form Factor | Plug-in card module |
| Weight | Approx. 1.0 kg |
| Compliance | CE, UL (per GE OEM certification) |
Proven Application Environments
- Gas Turbine Power Plants — Stator winding and bearing temperature monitoring via GE Mark IV/V/VI control panels
- Steam Turbine Generators — Exhaust and inlet temperature acquisition for thermal efficiency control
- Combined Cycle Plants (CCPP) — Multi-point RTD scanning across heat recovery steam generators (HRSG)
- Industrial Compressor Stations — Process gas temperature measurement in pipeline compression facilities
- Offshore Oil & Gas Platforms — Turbine-driven generator temperature monitoring in hazardous environments
- Petrochemical Refineries — Rotating equipment health monitoring integrated with GE DCS architecture
- Nuclear Auxiliary Systems — Non-safety-class temperature sensing in balance-of-plant (BOP) systems
Engineering Advantages
- Direct OEM Compatibility — Plug-and-play replacement for GE Mark IV, Mark V, and Mark VI RTD input slots; no firmware modification required
- High Measurement Precision — ±0.1°C accuracy ensures reliable thermal protection thresholds and alarm setpoints
- Low Signal Drift — Stable long-term performance reduces recalibration frequency in continuous-duty power generation environments
- 3-Wire Lead Compensation — Eliminates lead resistance error inherent in 2-wire RTD configurations, critical for long cable runs in large plant layouts
- Robust EMI Shielding — Designed to operate in high-electromagnetic-interference environments typical of generator halls and switchgear rooms
- Hot-Swap Capable — Supports live insertion in compatible Mark VI I/O racks, minimizing planned outage windows
- Traceable Calibration — Each unit ships with GE factory calibration data traceable to NIST/IEC 60751 standards
System Architecture & Signal Flow
The 369B1848G5001 operates within GE’s distributed I/O architecture as follows:
- RTD Sensor Input — PT100/PT1000 sensors connect via 3-wire shielded cable to the module’s terminal block
- Signal Conditioning — Onboard analog front-end applies excitation current, measures voltage drop, and compensates for lead resistance
- A/D Conversion — High-resolution ADC converts the conditioned analog signal to a digital temperature value
- Backplane Communication — Digitized data is transmitted over the GE Mark series I/O bus to the main controller (UCCE/UCCA/UCSB)
- HMI & SCADA Integration — Temperature values appear in GE Toolbox, Cimplicity HMI, or third-party SCADA via OPC-DA/UA gateway
Sourcing & Quality Verification
- Authentic OEM Parts — All 369B1848G5001 units sourced directly from GE-authorized distributors or verified surplus channels with full traceability documentation
- Pre-Shipment Inspection — Each module undergoes functional power-on test, visual inspection per IPC-A-610, and dimensional verification before dispatch
- Counterfeit Screening — X-ray inspection and component-level verification performed on all non-factory-sealed units
- Packaging Standard — ESD-safe anti-static bag + foam-lined carton; humidity indicator card included for long-distance shipments
- Documentation Provided — Certificate of Conformance (CoC), test report, and packing list included with every order
- Warranty — 12-month warranty against manufacturing defects from date of shipment
Procurement Process
- Submit RFQ — Email support@konmask.com with part number 369B1848G5001, required quantity, and delivery timeline
- Receive Quotation — Our technical team responds within 4 business hours with pricing, lead time, and stock availability
- Order Confirmation — Purchase order accepted via email; proforma invoice issued for prepayment or net-term accounts
- Quality Hold & Dispatch — Pre-shipment inspection completed; unit dispatched via DHL / FedEx / SF Express with tracking number
- After-Sales Support — Technical assistance available for installation verification and GE Mark system integration queries
Technical FAQ
Q: Is the 369B1848G5001 compatible with GE Mark VI MOOG I/O racks?
A: Yes. The module is designed for GE’s standard Mark VI I/O rack form factor and interfaces with MOOG-sourced rack assemblies used in later Mark VI configurations.
Q: Can this module accept 4-wire RTD inputs?
A: The 369B1848G5001 is optimized for 3-wire PT100/PT1000 configurations. 4-wire RTDs can be connected using 3 of the 4 leads, though the additional accuracy benefit of the 4th wire will not be utilized.
Q: What is the maximum cable length supported between the RTD sensor and this module?
A: GE recommends a maximum of 300 meters for 3-wire PT100 configurations using 1.5 mm² shielded cable. Longer runs require lead resistance compensation verification.
Q: Does Konmask provide calibration certificates with this module?
A: Yes. All units are supplied with a factory calibration certificate traceable to IEC 60751 / NIST standards. Custom recalibration services are available upon request.
Q: What is the lead time for the 369B1848G5001?
A: In-stock units ship within 3–5 business days. For out-of-stock scenarios, lead time is typically 4–8 weeks depending on sourcing channel. Contact us for real-time availability.
Q: Is this module RoHS compliant?
A: Units manufactured after 2011 comply with RoHS Directive 2011/65/EU. Please specify your compliance requirement when placing an order so we can confirm the manufacturing batch.
