GE DS200PTCTG1BAA – Signal Conditioner Board | Mark V Speedtronic Platform
Engineering Background: The DS200PTCTG1BAA is a precision signal conditioning board engineered by GE (General Electric) for deployment within the Mark V Speedtronic turbine control system — one of the most widely deployed gas and steam turbine control platforms in the power generation and oil & gas industries. This board serves as a critical interface layer between field instrumentation and the Mark V control processor, ensuring signal integrity across demanding industrial environments.
Product Positioning: Designed for procurement engineers and maintenance teams responsible for turbine control system uptime, the DS200PTCTG1BAA provides a direct OEM-equivalent replacement path for aging Mark V installations. Konmask.com maintains verified stock of this module to support both planned maintenance outages and emergency replacement scenarios.
Complete Technical Specifications
- Part Number: DS200PTCTG1BAA
- Manufacturer: GE (General Electric)
- Series / Platform: Mark V Speedtronic Turbine Control System
- Module Type: Signal Conditioner Board
- Form Factor: PCB Card Module
- Weight: 4,460 g (approx.)
- Condition: Surplus / Refurbished (tested and verified)
- Country of Origin: USA
- Compatibility: GE Mark V Speedtronic turbine control panels
- Signal Types Supported: Analog and discrete signal conditioning
- Operating Environment: Industrial control cabinet, DIN-rail or card rack mounting
- Communication Interface: Backplane-integrated per Mark V architecture
Proven Application Environments
- Gas turbine control systems (Frame 5, Frame 6, Frame 7, Frame 9 series)
- Steam turbine governor and protection systems
- Combined-cycle power plant automation
- Compressor station control in oil & gas pipelines
- LNG plant turbine-driven compressor control
- Refinery and petrochemical rotating equipment control
- Utility-scale power generation facilities
Engineering Advantages
- Signal Integrity: Conditions raw field signals to precise levels required by Mark V processor cards, eliminating noise and drift that can trigger spurious trips.
- Direct OEM Replacement: Identical form, fit, and function to original GE factory specification — no firmware modification or recalibration required upon installation.
- Reduced Downtime Risk: Stocked and ready to ship, minimizing mean time to repair (MTTR) for critical turbine assets.
- Broad Compatibility: Supports multiple Mark V panel configurations across GE’s turbine product range.
- Proven Field Reliability: Thousands of units in service globally across power generation and process industries.
System Architecture & Signal Flow
Within the Mark V Speedtronic architecture, the DS200PTCTG1BAA resides in the I/O card rack and interfaces directly with field wiring termination boards. Raw analog signals (4–20 mA, thermocouple, RTD, or discrete contact inputs) are received, filtered, scaled, and buffered before being passed to the Mark V core processor via the internal backplane bus. This conditioning stage is essential for maintaining the ±0.1% accuracy class required by turbine protection logic.
Signal flow: Field Instrument → Terminal Board → DS200PTCTG1BAA → Mark V Backplane → Processor (TCCA/TCDA) → Control Output
Sourcing & Quality Verification
- All units sourced from verified industrial surplus channels and authorized dismantlers
- Full visual inspection: PCB, connectors, component condition, and board markings
- Functional bench test performed prior to listing
- Anti-static packaging with humidity indicator card
- Serialized tracking and documentation available upon request
- 30-day return policy for DOA (Dead on Arrival) units
Procurement Process
- Confirm Part Number: Verify DS200PTCTG1BAA against your panel BOM or existing board label.
- Request Quote: Contact support@konmask.com with quantity and required delivery date.
- Order Confirmation: Receive proforma invoice with lead time and shipping options (DHL / FedEx / sea freight).
- Quality Documentation: Test report and inspection certificate issued with shipment.
- Delivery & Installation: Board arrives in anti-static packaging, ready for direct installation.
Technical FAQ
Q: Is the DS200PTCTG1BAA compatible with Mark VI or Mark VIe systems?
A: No. This board is designed specifically for the Mark V architecture. Mark VI and Mark VIe use a different I/O and backplane standard. Please contact us to identify the correct part for your system.
Q: Does this board require recalibration after installation?
A: In most cases, no. The DS200PTCTG1BAA is a passive/semi-active conditioning board. However, we recommend verifying signal scaling against your Mark V configuration file after installation.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For bulk orders or specific revision requirements, lead time is 5–10 business days.
Q: Can you provide a test report?
A: Yes. A functional test report is available upon request and included with all orders over 2 units.
Q: Do you accept returns?
A: Yes. We offer a 30-day DOA return policy. Units must be returned in original packaging with the original shipping documentation.
