Turbine Control Solution – GE DS200TCPAG1AJD | Mark VI Series
Where This Product Is Used
The GE DS200TCPAG1AJD is a Turbine Control Processor (TCP) board designed for use within GE’s Mark VI Turbine Control System. It is deployed across a wide range of mission-critical industrial environments where precise turbine sequencing, protection, and real-time process control are required:
- Gas Turbine Power Plants – Controls fuel metering, speed governing, and startup/shutdown sequencing for GE Frame 5, 6, 7, and 9 gas turbines.
- Steam Turbine Facilities – Manages steam admission valves, overspeed protection, and load control in combined-cycle and cogeneration plants.
- LNG & Petrochemical Compressor Trains – Provides closed-loop control for turbine-driven centrifugal compressors in upstream and midstream oil & gas operations.
- Industrial Cogeneration Plants – Integrates with plant DCS for coordinated power and heat output management.
- Marine Propulsion Systems – Applied in naval and commercial vessel turbine control architectures requiring high-reliability processor boards.
Technical Specifications
- Part Number: DS200TCPAG1AJD
- Manufacturer: GE (General Electric)
- Series: Mark VI Turbine Control System
- Board Type: Turbine Control Processor (TCP)
- Form Factor: VME-based plug-in board
- Operating Voltage: +5 VDC / ±15 VDC (supplied via backplane)
- Communication: IONet Ethernet (proprietary GE protocol), RS-232/RS-485 serial
- Processor Architecture: Dual-redundant capable; supports TMR (Triple Modular Redundancy) configurations
- Operating Temperature: 0°C to +60°C
- Weight: 540 g
- Compatibility: GE Mark VI, Mark VIe control cabinets
- Firmware: Field-upgradeable via GE Toolbox software
Why Engineers Specify This Model
- Drop-in Replacement: Direct form-fit-function replacement for failed or end-of-life TCP boards in existing Mark VI panels — no cabinet modification required.
- TMR Architecture Support: Supports triple-redundant control configurations, ensuring zero unplanned downtime in critical power generation assets.
- Proven Field Reliability: Widely deployed across GE’s global installed base of 10,000+ Mark VI-controlled turbines.
- Integrated Diagnostics: Onboard self-test and fault logging reduce MTTR (Mean Time to Repair) during outage windows.
- Long Service Life: Designed for 20+ year operational environments typical of power generation infrastructure.
Complete System Bill of Materials
The DS200TCPAG1AJD typically operates alongside the following Mark VI system components:
- DS200TCQAG1AJD – Turbine Control I/O Board
- DS200SDCCG3A – System Definition Card
- DS200IOCAG1A – I/O Controller Board
- DS200EXPAG1AJD – Expansion Board
- IS200TTURH1C – Turbine Trip Relay Board
- DS200TCRAG1AJD – Turbine Control Relay Board
- GE Mark VI Control Cabinet (R, S, T panels)
Contact support@konmask.com for complete BOM sourcing assistance.
Compliance & Industry Standards
- Designed and manufactured to IEC 61511 (Functional Safety for Process Industry)
- Compliant with NEMA ICS 2 industrial control standards
- Suitable for installations governed by NERC CIP cybersecurity frameworks (with appropriate network segmentation)
- RoHS-compliant manufacturing process
- CE marking applicable for EU installations
Quality Assurance & Sourcing
Every DS200TCPAG1AJD unit sourced through Konmask.com undergoes the following quality process:
- ✅ Visual inspection for physical damage, corrosion, and component integrity
- ✅ Functional bench test under simulated Mark VI backplane conditions
- ✅ Firmware version verification and documentation
- ✅ Anti-static packaging with humidity indicator cards
- ✅ Full traceability documentation provided upon request
We source from decommissioned power plant inventories, authorized distributors, and OEM surplus channels — never counterfeit or grey-market supply chains.
How to Source This Part
- Add to cart and complete checkout for in-stock units with same-day dispatch.
- For bulk orders (3+ units), contact support@konmask.com for volume pricing.
- Need a specific firmware revision or factory-new unit? Submit your RFQ with your Mark VI panel serial number for exact match sourcing.
- Emergency AOG (Aircraft on Ground) / plant-down priority shipping available — call +0086 19859288691.
Application-Specific FAQ
Q: Is the DS200TCPAG1AJD compatible with both Mark VI and Mark VIe systems?
A: The DS200TCPAG1AJD is primarily designed for Mark VI. Mark VIe systems use a different processor architecture (IS200 series). Please confirm your panel generation before ordering.
Q: Can this board be used in a simplex (non-redundant) configuration?
A: Yes. While it supports TMR, it can be configured for simplex or dual-redundant operation depending on your system’s safety requirements.
Q: What GE Toolbox version is required for firmware updates?
A: GE Toolbox version 04.03 or later is recommended. Contact us for firmware documentation specific to your revision suffix (G1AJD).
Q: Do you provide a warranty?
A: Yes — all units carry a 90-day functional warranty. Extended warranty options are available for long-term maintenance contracts.
Q: Can you source the complete Mark VI control panel?
A: Yes. Konmask.com specializes in complete Mark VI panel sourcing, including R/S/T cabinets, I/O packs, and HMI workstations. Contact us with your project scope.
