GE DS200TCQAG1A Analog I/O Board | Replacement, Equivalent & Selection Guide
The GE DS200TCQAG1A is an Analog Input/Output Board designed for use in General Electric Mark V Turbine Control Systems. It serves as a critical interface for analog signal conditioning, enabling precise monitoring and control of turbine operational parameters. This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to help engineers and procurement teams make confident selection decisions.
Technical Specifications
- Part Number: DS200TCQAG1A
- Manufacturer: General Electric (GE)
- Series: Mark V Turbine Control
- Function: Analog I/O Board (Signal Conditioning & Interface)
- Board Type: Printed Circuit Board (PCB)
- Signal Type: Analog Input / Analog Output
- Weight: 540 g (approx.)
- Condition Available: New, Refurbished, Tested
- Compatibility: GE Mark V Control Panel (TCQA series)
- Operating Environment: Industrial / Power Generation
- RoHS Compliance: Consult datasheet for specific revision
Compatible Replacement & Equivalent Models
The following models are known compatible replacements or functional equivalents for the DS200TCQAG1A. Always verify firmware revision and slot compatibility before substitution:
- DS200TCQAG1B — Revised version of G1A; pin-compatible in most Mark V configurations
- DS200TCQAG2A — Enhanced analog resolution variant; verify I/O channel mapping
- DS200TCDAG1A — Alternative analog I/O board within the TCDA sub-series
- IS200TCQAG1A — Mark VI series equivalent; requires system-level compatibility check
- DS200TCQBG1A — Functional substitute in select turbine panel configurations
Note: Cross-referencing part numbers does not guarantee drop-in compatibility. Always consult GE Mark V system documentation or contact Konmask technical support before replacement.
Why Choose the Original Model
- Exact OEM Fit: DS200TCQAG1A is the factory-specified board for Mark V TCQA panels — no firmware reconfiguration required
- Signal Integrity: Factory-calibrated analog channels ensure measurement accuracy critical for turbine safety loops
- Proven Reliability: Deployed in power generation facilities globally with documented long-term MTBF performance
- Reduced Commissioning Risk: OEM parts eliminate integration uncertainty versus third-party alternatives
- Warranty & Traceability: Sourced units from Konmask include full traceability documentation
Typical Applications
- Gas turbine and steam turbine control systems (GE Frame 5, 6, 7, 9 series)
- Combined-cycle power plant automation
- Industrial compressor control panels
- Analog sensor signal conditioning (thermocouples, RTDs, pressure transducers)
- Turbine speed, temperature, and vibration monitoring loops
- Legacy Mark V panel maintenance and spare parts inventory
System Compatibility
| Control System | Compatibility | Notes |
|---|---|---|
| GE Mark V (TCQA Panel) | ✅ Direct Fit | OEM specification |
| GE Mark V (TCDA Panel) | ⚠️ Verify Slot | Check board slot assignment |
| GE Mark VI | ❌ Not Compatible | Use IS200 series instead |
| GE Mark IV | ❌ Not Compatible | Different architecture |
| Third-party Mark V clones | ⚠️ Case-by-case | Contact support for assessment |
Selection Guide
Use the following decision flow to select the correct analog I/O board for your Mark V system:
- Step 1 — Identify your panel type: Locate the panel designation on your Mark V cabinet (TCQA, TCDA, TCRA, etc.)
- Step 2 — Confirm board slot: Match the slot number in your system drawing to the DS200TCQAG1A position
- Step 3 — Check revision level: G1A vs G1B vs G2A may differ in analog channel count or resolution — verify against your system BOM
- Step 4 — Assess condition requirement: New OEM for critical safety loops; tested refurbished acceptable for non-critical monitoring channels
- Step 5 — Confirm lead time vs. urgency: Konmask maintains ready stock for rapid dispatch — contact us for availability confirmation
Quality Assurance & Sourcing
- Source: Authorized distributors, OEM surplus, and certified refurbishers
- Testing: All refurbished units undergo functional bench testing prior to shipment
- Documentation: Certificate of conformance and test reports available on request
- Packaging: ESD-safe anti-static packaging with foam cushioning
- Traceability: Lot tracking and serial number records maintained
- Warranty: 12-month warranty on tested units; consult listing for new OEM warranty terms
How to Order
- Online: Add to cart directly on this page — stock availability confirmed at checkout
- Bulk / Project Inquiry: Email support@konmask.com with quantity, required condition, and delivery timeline
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day response
- RFQ: Submit part number DS200TCQAG1A with your system details for a tailored quote
- Export / International: We ship globally — contact us for customs documentation and Incoterms options
Replacement & Compatibility FAQ
Q: Can DS200TCQAG1B replace DS200TCQAG1A directly?
A: In most Mark V TCQA panel configurations, yes — the G1B is a revised version with the same form factor. However, verify the firmware revision of your Mark V controller before swapping.
Q: Is DS200TCQAG1A compatible with GE Mark VI systems?
A: No. Mark VI uses the IS200 series boards with a different backplane architecture. Use IS200TCQAG1A or equivalent IS200-series parts for Mark VI.
Q: What is the difference between DS200TCQAG1A and DS200TCDAG1A?
A: Both are analog I/O boards within the Mark V DS200 family, but they belong to different sub-panel series (TCQA vs. TCDA). They are not interchangeable without verifying slot assignments and system wiring diagrams.
Q: Can I use a refurbished DS200TCQAG1A in a safety-critical loop?
A: Refurbished units that have passed full functional testing are suitable for many applications. For SIL-rated or primary protection loops, consult your system integrator and review GE’s maintenance guidelines.
Q: How do I verify the board revision before ordering?
A: The revision suffix (G1A, G1B, G2A) is printed on the board label. Share a photo of your existing board or your system BOM with Konmask support for confirmation before purchase.
Q: What is the lead time for DS200TCQAG1A?
A: Konmask maintains stock of common Mark V boards. Contact us to confirm current availability — in-stock orders typically ship within 1–3 business days.
