GE DS200TCQAG1ADC – Termination Board | Mark V SPEEDTRONIC Platform
Engineering Background
The DS200TCQAG1ADC is a critical I/O termination board engineered by General Electric as part of the DS200 series within the Mark V SPEEDTRONIC turbine control architecture. Designed to serve as the physical interface layer between field instrumentation and the Mark V control processor, this board provides robust, noise-immune signal conditioning and termination for gas and steam turbine applications operating in demanding industrial environments.
Product Positioning
Procurement engineers specifying replacement or spare components for GE Mark V SPEEDTRONIC systems will find the DS200TCQAG1ADC to be a direct OEM-equivalent solution. Konmask.com maintains verified stock of this board to support planned maintenance outages, emergency replacements, and long-term spare parts programs for power generation and industrial turbine operators worldwide.
Complete Technical Specifications
| Part Number | DS200TCQAG1ADC |
| Manufacturer | General Electric (GE) |
| Series | DS200 / Mark V SPEEDTRONIC |
| Board Type | Termination Board (I/O Interface) |
| Function | Field signal termination and conditioning for turbine control I/O |
| Compatible Platform | GE Mark V SPEEDTRONIC Turbine Control System |
| Application | Gas turbine, steam turbine, combined-cycle power plants |
| Weight | 980 g |
| Condition Available | Refurbished / Tested / New Surplus |
| Warranty | 12 months (Konmask standard) |
| Lead Time | In stock — ships within 3 business days |
| Export Classification | EAR99 (verify with your compliance team) |
Proven Application Environments
- Power Generation: Gas turbine and combined-cycle plants using GE Frame 5, Frame 6, Frame 7, and Frame 9 turbines with Mark V control systems
- Steam Turbine Control: Industrial steam turbines in refinery, petrochemical, and utility applications
- Oil & Gas: Compressor stations and pipeline booster stations with GE SPEEDTRONIC-based control panels
- Marine Propulsion: Vessel propulsion systems utilizing GE turbine control architectures
- Planned Maintenance Programs: Outage spare kits for Mark V-equipped facilities requiring certified replacement boards
Engineering Advantages
- Direct OEM Compatibility: Designed and manufactured by GE to exact Mark V SPEEDTRONIC specifications — no field modification required
- Signal Integrity: Provides noise-immune termination for analog and discrete I/O signals in high-EMI turbine environments
- Plug-and-Play Replacement: Drop-in replacement for failed or degraded DS200TCQAG1ADC boards with no firmware changes required
- Tested & Verified: Each unit sourced by Konmask undergoes functional verification prior to dispatch
- Long Service Life: Industrial-grade PCB construction rated for continuous operation in elevated-temperature control enclosures
- Reduced Downtime Risk: Immediate availability from Konmask stock eliminates extended lead times associated with OEM new orders
System Architecture & Signal Flow
Within the Mark V SPEEDTRONIC architecture, the DS200TCQAG1ADC serves as the physical termination layer in the I/O signal chain:
- Field Instruments (thermocouples, RTDs, pressure transmitters, proximity probes) → wire to terminal blocks on the DS200TCQAG1ADC
- DS200TCQAG1ADC → conditions and routes signals via ribbon cable or backplane connector to the corresponding Mark V I/O processor card (e.g., TCQA, TCQC series)
- Mark V Processor → executes turbine protection, sequencing, and control logic based on conditioned field signals
Proper installation and torque specification of field wiring terminations on this board is critical to signal accuracy and system reliability. Refer to GE Mark V SPEEDTRONIC System Guide (GEH-6195) for wiring diagrams and installation procedures.
Sourcing & Quality Verification
- Traceability: All DS200TCQAG1ADC units are sourced from documented supply chains including decommissioned OEM systems, authorized distributors, and certified repair facilities
- Inspection Protocol: Visual inspection, component-level verification, and functional bench testing performed prior to listing
- Packaging: Anti-static ESD packaging with foam cushioning; shipped in double-wall corrugated cartons
- Documentation: Certificate of conformance and test report available upon request
- Counterfeit Mitigation: Konmask applies a multi-point authentication check against known GE board markings, revision codes, and date codes
Procurement Process
- Confirm Part Number: Verify DS200TCQAG1ADC against your system’s BOM or existing board label (check revision suffix: G1ADC)
- Request Quote: Contact Konmask via email or phone for volume pricing, lead time confirmation, and export documentation
- Purchase Order: Submit PO referencing part number DS200TCQAG1ADC; net payment terms available for qualified accounts
- Shipping & Logistics: DHL / FedEx international express available; customs documentation (commercial invoice, packing list, COO) provided
- Incoming Inspection: Konmask recommends incoming inspection upon receipt; our team supports any technical queries during installation
Technical FAQ
Q: Is the DS200TCQAG1ADC compatible with Mark VI or Mark VIe systems?
A: No. This board is designed specifically for the Mark V SPEEDTRONIC platform. Mark VI and Mark VIe use a different I/O termination architecture (TRLY, TBCI series). Contact Konmask to identify the correct board for your system generation.
Q: What is the difference between DS200TCQAG1ADC and DS200TCQAG1BDC?
A: The revision suffix (ADC vs BDC) denotes a GE engineering change level. In most cases these are functionally interchangeable, but always verify against your system’s approved parts list or consult your GE service representative before substitution.
Q: Can Konmask provide a repair service for a failed DS200TCQAG1ADC?
A: Yes. Konmask offers board-level repair and exchange programs. Contact support@konmask.com with your board’s failure symptoms and revision code for a repair quotation.
Q: What warranty does Konmask provide?
A: All boards carry a 12-month warranty against defects in materials and workmanship from date of shipment. Warranty claims are processed via advance replacement to minimize your downtime.
Q: Is expedited shipping available?
A: Yes. Next-flight-out and same-day dispatch options are available for emergency outage situations. Contact us directly for urgent requirements.
