GE EPSCPE100-ABAE – PACSystems RX3i CPU Module | Programmable Controller Platform
Engineering Background: The GE EPSCPE100-ABAE is a high-performance CPU module designed for the PACSystems RX3i platform — GE’s flagship modular PLC architecture engineered for demanding industrial automation environments. Built on a universal backplane architecture, the RX3i platform supports seamless integration of legacy Series 90-30 I/O alongside modern high-speed modules, making it the preferred choice for brownfield upgrades and greenfield installations alike.
Product Positioning: The EPSCPE100-ABAE targets process control, discrete manufacturing, and hybrid automation applications where deterministic scan performance, robust communications, and long-term platform continuity are non-negotiable. It is widely deployed in power generation, oil & gas, water treatment, automotive assembly, and chemical processing facilities globally.
Complete Technical Specifications
- Part Number: EPSCPE100-ABAE
- Platform: GE PACSystems RX3i
- Module Type: CPU / Central Processing Unit
- Processor: 1.1 GHz Intel Celeron M
- User Memory: 64 MB standard (expandable)
- Program Memory: 10 MB logic / 512 KB configurable data
- Backplane Compatibility: IC695CHS007, IC695CHS012, IC695CHS016
- Communications Ports: 2× RS-232 serial, 1× Ethernet 10/100 Mbps (RJ-45)
- Ethernet Protocol Support: SRTP, Modbus TCP, EGD (Ethernet Global Data), OPC
- Serial Protocol Support: SNP, SNP-X, RTU, ASCII
- I/O Capacity: Up to 8,192 discrete I/O points; up to 4,096 analog channels
- Scan Time: <1 ms per 1K boolean logic (typical)
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Storage Temperature: -40°C to +85°C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: 4.5 W typical
- Dimensions (H × W × D): 230 × 30 × 130 mm (approx.)
- Weight: 300 g
- Certifications: UL, CE, cUL, FM Class I Div 2
- Firmware: RX3i firmware compatible (field upgradeable)
- Country of Origin: United States
Proven Application Environments
- Power Generation & Utilities: Turbine control, substation automation, load management
- Oil & Gas: Pipeline SCADA, compressor control, wellhead automation
- Water & Wastewater: Pump station control, treatment process sequencing
- Automotive Manufacturing: Assembly line control, robotic cell integration, conveyor systems
- Chemical & Pharmaceutical: Batch process control, reactor management, safety interlocks
- Food & Beverage: Filling line automation, CIP/SIP process control
- Building Automation: HVAC control, energy management systems
Engineering Advantages
- Universal Backplane Architecture: Accepts both RX3i and legacy Series 90-30 I/O modules — protects existing infrastructure investment during system upgrades.
- High-Speed Ethernet Native: Onboard 10/100 Mbps Ethernet eliminates the need for a separate communications module, reducing BOM cost and rack space.
- Multi-Protocol Flexibility: Simultaneous support for SRTP, Modbus TCP, EGD, and OPC enables seamless integration with SCADA, HMI, and MES layers.
- Deterministic Scan Performance: Sub-millisecond boolean scan times ensure real-time response for high-speed discrete and motion control applications.
- Field-Upgradeable Firmware: Firmware updates via Ethernet without module removal — minimizes planned downtime during system maintenance windows.
- Extended Temperature Range: Rated 0–60°C for operation in non-climate-controlled industrial enclosures.
- Long Platform Lifecycle: PACSystems RX3i is GE’s strategic PLC platform with documented long-term support — reduces obsolescence risk for capital-intensive installations.
System Architecture & Signal Flow
The EPSCPE100-ABAE occupies Slot 0 of the RX3i universal backplane. The CPU communicates with all I/O and specialty modules via the high-speed VME64 backplane bus (320 MB/s), ensuring deterministic data exchange across the rack. The onboard Ethernet port connects directly to plant LAN or dedicated control network for SCADA/HMI communications. Dual RS-232 serial ports support legacy device integration (drives, instruments, barcode readers) via SNP or Modbus RTU. The CPU manages the complete program scan cycle: input scan → logic solve → output update → communications service, with configurable constant sweep or demand modes.
Sourcing & Quality Verification
- Source: Sourced from authorized distributors, OEM decommissions, and verified industrial surplus channels.
- Inspection Protocol: Each unit undergoes visual inspection, label/firmware version verification, and functional power-on testing prior to shipment.
- Authenticity: All modules are verified against GE catalog specifications. Counterfeit-risk screening applied to every unit.
- Condition: New surplus or refurbished-to-spec; condition disclosed per order. Refurbished units carry full functional warranty.
- Packaging: Anti-static ESD packaging with moisture barrier; double-boxed for international freight.
- Documentation: GE datasheet, test report, and certificate of conformance available upon request.
Procurement Process
- Step 1 — Inquiry: Submit your RFQ via Konmask.com product page or email support@konmask.com with quantity and required delivery date.
- Step 2 — Quote: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Step 3 — Order Confirmation: Confirm PO or place order directly via the Konmask.com checkout. Net-30 terms available for qualified accounts.
- Step 4 — Quality Check & Dispatch: Unit inspected, tested, and dispatched within 1–3 business days. Tracking number provided upon shipment.
- Step 5 — After-Sales Support: Technical support available post-delivery for installation, configuration, and commissioning queries.
Technical FAQ
Q: Is the EPSCPE100-ABAE compatible with Series 90-30 I/O modules?
A: Yes. The PACSystems RX3i universal backplane accepts both RX3i-native and legacy Series 90-30 I/O modules, enabling phased migration without replacing existing field wiring.
Q: What programming software is required?
A: GE Proficy Machine Edition (PME) is the standard programming environment. The EPSCPE100-ABAE supports Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), and Instruction List (IL) per IEC 61131-3.
Q: Can this CPU be used in a redundant configuration?
A: The EPSCPE100-ABAE supports hot-standby CPU redundancy when paired with the IC695RMX128 redundancy memory xchange module and a redundant backplane configuration.
Q: What is the maximum number of I/O modules supported?
A: A single RX3i rack supports up to 12 I/O slots. With remote I/O expansion via PROFINET or Ethernet, the system scales to thousands of I/O points across distributed racks.
Q: Is firmware upgrade possible in the field?
A: Yes. Firmware can be updated via the Ethernet port using Proficy Machine Edition without removing the module from the rack, minimizing downtime.
Q: What warranty is provided?
A: Konmask.com provides a 12-month functional warranty on all verified units. Extended warranty options available — contact support@konmask.com for details.
