GE IC755CSS15CDA-AA QuickPanel+ 15″ Touchscreen HMI | Industrial Operator Interface
Engineering Background
The IC755CSS15CDA-AA is part of GE Automation & Controls’ QuickPanel+ platform — a purpose-built HMI series engineered for demanding industrial environments. Designed to replace legacy operator panels, it delivers high-resolution touch interaction, robust connectivity, and seamless integration with GE PACSystems, third-party PLCs, and SCADA architectures.
Product Positioning
Targeted at process engineers and OEM machine builders requiring a reliable, field-proven HMI with a large display footprint, the IC755CSS15CDA-AA is the preferred choice for control rooms, production lines, and remote monitoring stations where operator clarity and system uptime are non-negotiable.
Complete Technical Specifications
- Part Number: IC755CSS15CDA-AA
- Series / Platform: QuickPanel+ (GE Automation & Controls)
- Display Size: 15″ (diagonal) TFT LCD
- Resolution: 1024 × 768 (XGA)
- Touch Technology: Resistive touchscreen
- Processor: ARM Cortex-A8, 800 MHz
- RAM: 512 MB DDR3
- Flash Storage: 256 MB internal NAND
- Operating System: Windows Embedded Compact 7
- Communication Ports: 2× USB 2.0 Host, 1× USB Device, 2× Ethernet (10/100 Mbps), 1× RS-232/485 (configurable), 1× CAN
- SD Card Slot: Yes (microSD, up to 32 GB)
- Power Supply: 24 VDC (18–32 VDC range)
- Power Consumption: ≤ 30 W typical
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -20°C to +70°C
- Humidity: 5–95% RH (non-condensing)
- Protection Rating: IP65 (front panel)
- Mounting: Panel mount (cutout required)
- Dimensions (W × H × D): ~400 × 310 × 65 mm (approx.)
- Weight: ~4.5 kg
- Certifications: CE, UL, cUL
- HS Code: 853710
- Country of Origin: USA
Proven Application Environments
- PACSystems RX3i / RSTi-EP PLC visualization and control
- Water & wastewater treatment SCADA terminals
- Oil & gas upstream/downstream process monitoring
- Pharmaceutical batch control and recipe management
- Automotive assembly line operator stations
- Power generation and substation HMI panels
- Food & beverage packaging line control
- Building automation and HVAC supervisory control
Engineering Advantages
- Large 15″ XGA Display: Reduces operator error with clear, high-contrast visualization of process data and alarms.
- Dual Ethernet Ports: Enables simultaneous connection to plant network and device-level network without additional switches.
- IP65 Front Panel: Withstands wash-down, dust ingress, and splashing fluids in harsh production environments.
- Windows Embedded Compact 7: Supports Proficy Machine Edition, Cimplicity, and third-party SCADA/HMI software.
- Multi-Protocol Support: Native EtherNet/IP, Modbus TCP/RTU, SRTP, OPC DA/UA — no additional gateways required.
- Fanless Design: Eliminates mechanical wear points, extending MTBF in continuous-duty applications.
System Architecture & Signal Flow
The IC755CSS15CDA-AA operates as a standalone HMI node within a distributed control architecture. Ethernet Port 1 (ETH1) connects to the plant LAN or PLC backplane network via EtherNet/IP or Modbus TCP. Ethernet Port 2 (ETH2) can be dedicated to a device-level network or remote I/O ring. The RS-232/485 serial port provides legacy connectivity to older PLCs or field instruments. The CAN port supports CANopen device integration. All I/O data is rendered in real time through the Proficy Machine Edition HMI runtime, with alarm management, trending, and recipe control handled natively on the Windows CE 7 platform.
Sourcing & Quality Verification
- Source: Verified surplus and refurbished industrial stock — traceable to original OEM or authorized distributor channels.
- Inspection: Each unit undergoes visual inspection, power-on functional test, and communication port verification prior to shipment.
- Authenticity: All units carry original GE part markings and serial numbers. Counterfeit-free guarantee.
- Condition: Surplus new, refurbished, or used-tested — condition confirmed at time of order. Contact us for current stock status.
- Warranty: 90-day Konmask operational warranty. Extended warranty available on request.
Procurement Process
- Submit your RFQ via the product page or email support@konmask.com with your required quantity and delivery timeline.
- Receive a formal quotation with stock confirmation, lead time, and shipping options within 24 business hours.
- Place order — we accept T/T wire transfer, PayPal, and major credit cards.
- Unit is tested, packaged in anti-static ESD-safe materials, and shipped with tracking.
- Post-delivery technical support available via email and WhatsApp.
Technical FAQ
Q: Is the IC755CSS15CDA-AA compatible with PACSystems RX3i?
A: Yes. It natively supports SRTP and EtherNet/IP protocols used by PACSystems RX3i and RX7i controllers via Proficy Machine Edition.
Q: Can I run third-party SCADA software on this HMI?
A: Yes. The Windows Embedded Compact 7 OS supports compatible CE-based SCADA/HMI runtimes including Wonderware InTouch CE, Ignition Edge (ARM-compatible builds), and others.
Q: What is the panel cutout dimension?
A: Refer to GE document GFK-2847 for exact cutout dimensions. Approximate cutout is 380 × 290 mm — always verify against the official installation datasheet before fabrication.
Q: Is firmware upgrade possible?
A: Yes. Firmware and OS updates are available via USB or Ethernet using GE’s update utility. Contact Konmask for the latest firmware package if required.
Q: Do you ship internationally?
A: Yes. We ship worldwide via DHL, FedEx, and UPS Express. Export documentation (commercial invoice, packing list, HS code 853710) is provided for customs clearance.
