Remote I/O Expansion Solution – GE HE693RTM705 | Series 90-30
Where This Product Is Used
The GE HE693RTM705 Remote Terminal Module is engineered for industrial environments where distributed I/O is essential. Typical deployment scenarios include:
- Automotive Assembly Lines – Extends PLC control to remote tooling stations and conveyor endpoints without additional CPUs.
- Oil & Gas Processing Plants – Connects remote field instruments and actuators back to a central Series 90-30 controller over long cable runs.
- Water & Wastewater Treatment – Manages distributed pump stations and valve banks from a single PLC rack.
- Food & Beverage Production – Integrates remote filling, capping, and labeling stations into a unified control architecture.
- Power Generation & Utilities – Provides reliable remote I/O connectivity in high-noise electrical environments.
- Discrete Manufacturing – Supports multi-zone machine control where I/O points are physically separated from the main control panel.
Technical Specifications
- Part Number: HE693RTM705
- Series: GE Series 90-30
- Module Type: Remote Terminal Module (RTM)
- Function: Remote I/O rack controller / bus interface
- Communication: GE Series 90-30 Remote I/O Bus
- Backplane Compatibility: Series 90-30 I/O racks (5-slot, 10-slot)
- Power Requirement: Supplied via backplane (5 VDC)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Weight: Approx. 200 g
- Mounting: Series 90-30 backplane slot
- Certifications: UL Listed, CE Marked
Why Engineers Specify This Model
- Seamless Series 90-30 Integration – Drop-in compatible with existing GE Series 90-30 racks; no additional configuration hardware required.
- Deterministic Remote I/O Scan – Maintains predictable scan-cycle performance even across extended remote drops.
- Robust Industrial Design – Conformal-coated PCB withstands vibration, humidity, and airborne contaminants common in process environments.
- Simplified Wiring Architecture – Reduces home-run cabling costs by consolidating field I/O at the remote rack level.
- Long Product Lifecycle Support – GE Series 90-30 platform has an extensive installed base with broad spare-parts availability.
Complete System Bill of Materials
For a fully operational remote I/O drop using the HE693RTM705, engineers typically specify:
- GE HE693RTM705 – Remote Terminal Module (this item)
- GE Series 90-30 I/O Rack (5-slot: IC693CHS391 / 10-slot: IC693CHS392)
- GE Series 90-30 Power Supply (e.g., IC693PWR321 or IC693PWR330)
- GE Series 90-30 Digital Input / Output Modules (as required by application)
- Remote I/O Cable (shielded, per GE installation guidelines)
- GE Series 90-30 CPU with Remote I/O Master capability (e.g., IC693CPU374)
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Marking – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- IEC 61131-2 – Programmable Controllers Hardware Requirements
- RoHS Compliant (where applicable to production date)
Quality Assurance & Sourcing
All GE Series 90-30 modules sourced through Konmask.com undergo a multi-point inspection process:
- Visual inspection for physical damage, corrosion, and component integrity
- Firmware and label verification against OEM documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card
- Traceable lot documentation available on request
We supply new, surplus-new, and professionally refurbished units. Condition is clearly stated at time of quotation.
How to Source This Part
- Request a Quote: Email [email protected] with your required quantity and delivery timeline.
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days.
- Export & Customs: We handle export documentation, HS code classification, and commercial invoices for international shipments.
- Payment: T/T (Wire Transfer), PayPal, and major credit cards accepted.
Application-Specific FAQ
Q: Can the HE693RTM705 be used with GE PACSystems RX3i racks?
A: No. The HE693RTM705 is designed exclusively for the GE Series 90-30 remote I/O bus architecture and is not compatible with PACSystems RX3i or RX7i backplanes.
Q: How many remote drops can a Series 90-30 CPU support?
A: Depending on the CPU model, the Series 90-30 supports up to 7 remote I/O drops. Consult your CPU datasheet for the exact limit.
Q: Is programming required when replacing an HE693RTM705?
A: Typically no. The RTM is a bus interface module; replacing it with an identical unit does not require PLC program changes, only correct rack addressing.
Q: What cable type is required for the remote I/O bus?
A: GE specifies shielded twisted-pair cable per the Series 90-30 Remote I/O Installation Manual (GFK-0898). Maximum cable length depends on baud rate selection.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty options are available upon request.
