GE IC693ALG220 Analog Input Module – Series 90-30 PLC
Imagine a continuous process line — a chemical reactor, a water treatment plant, or a paper mill — where temperature, pressure, and flow sensors feed real-time data into the control system. Without a reliable analog input module, those critical signals become noise. Alarms go undetected. Processes drift out of spec. Unplanned shutdowns cost tens of thousands of dollars per hour. The GE IC693ALG220 is the precision interface that prevents exactly that scenario, converting raw field-level analog signals into actionable digital data for the PLC controller.
Within the GE Series 90-30 PLC ecosystem — one of the most widely deployed modular PLC platforms in North American and global industrial automation — the IC693ALG220 occupies a foundational role as a high-density analog input module. Introduced as part of GE Fanuc’s mature Series 90-30 architecture, this module continues to serve active installations across oil & gas, power generation, food & beverage, and discrete manufacturing. Its longevity in the market reflects both the robustness of its design and the scale of the installed base that depends on it for ongoing operations and MRO (Maintenance, Repair & Overhaul) procurement.
Technical Specifications
- Part Number: IC693ALG220
- Series: GE Series 90-30 PLC
- Module Type: Analog Input
- Number of Channels: 16 (single-ended) / 8 (differential)
- Input Signal Types: Voltage and Current (configurable per channel)
- Voltage Input Range: ±10 V, 0–10 V, 0–5 V, 1–5 V
- Current Input Range: 4–20 mA, 0–20 mA
- Resolution: 12-bit (4096 counts)
- Isolation: Optical isolation between field and backplane
- Backplane Bus: Series 90-30 standard I/O bus
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: Supplied via Series 90-30 backplane
- Weight: Approx. 350 g
- Certifications: UL Listed, CE Marked
Note: Specifications are based on GE published datasheets. Always verify against your system’s engineering documentation before installation.
Key Features & Benefits
- High Channel Density: Up to 16 single-ended channels per module slot, maximizing I/O density in space-constrained control panels.
- Flexible Signal Configuration: Supports both voltage and current inputs, accommodating a wide range of field transmitters and sensors without additional signal conditioners.
- 12-Bit Resolution: Delivers sufficient precision for process control loops in temperature, pressure, flow, and level measurement applications.
- Optical Isolation: Protects the PLC backplane from field-side transients and ground loops, improving system reliability in electrically noisy environments.
- Drop-in Compatibility: Designed for direct installation into any Series 90-30 baseplate slot, with no additional hardware adapters required.
- Proven Field Reliability: Decades of deployment in harsh industrial environments validate the module’s durability and mean-time-between-failure (MTBF) performance.
- Software Configurability: Channel parameters are configured via GE Proficy Machine Edition (ME) or legacy Logicmaster 90 software, enabling rapid commissioning.
Industry & Equipment Applications
- Oil & Gas: Pipeline pressure monitoring, wellhead control panels, compressor station automation.
- Power Generation: Turbine inlet temperature measurement, boiler drum level control, generator excitation feedback.
- Water & Wastewater Treatment: Flow meter integration, pH and dissolved oxygen sensor inputs, pump station control.
- Food & Beverage: Pasteurization temperature loops, tank level monitoring, CIP (Clean-in-Place) process control.
- Chemical Processing: Reactor temperature and pressure feedback, batch process control, distillation column monitoring.
- Discrete Manufacturing: Conveyor tension control, press force monitoring, robotic cell analog feedback.
- HVAC & Building Automation: Chiller plant control, air handling unit (AHU) sensor integration.
System Integration & Compatible Parts
The IC693ALG220 is designed to operate within the GE Series 90-30 PLC platform. Compatible and commonly paired components include:
- CPU Modules: IC693CPU311, IC693CPU313, IC693CPU321, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU360, IC693CPU363, IC693CPU374
- Power Supplies: IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331
- Baseplates: IC693CHS391, IC693CHS392, IC693CHS393 (5, 10, 12-slot)
- Analog Output Modules: IC693ALG390, IC693ALG391, IC693ALG392
- Digital I/O Modules: IC693MDL340, IC693MDL645, IC693MDL740
- Communications: IC693CMM301 (Ethernet), IC693CMM311 (Genius Bus)
- Programming Software: GE Proficy Machine Edition (ME) Logic Developer
Our Quality Assurance Process
At Konmask.com, every IC693ALG220 unit goes through a structured verification process before shipment:
- Visual Inspection: Board-level inspection for physical damage, corrosion, bent pins, and component integrity.
- Label & Firmware Verification: Part number, revision level, and firmware version are confirmed against GE documentation.
- Functional Test (where applicable): Refurbished units undergo bench-level power-on and I/O channel verification.
- Anti-Static Packaging: All modules are shipped in ESD-safe bags with foam cushioning inside double-wall cartons.
- Traceability: Each order is logged with serial number records for post-sale support and warranty claims.
How to Order
- Submit an inquiry via our Request a Quote form on this page, or email support@konmask.com.
- Provide your required quantity, preferred condition (new / refurbished / exchange), and target delivery date.
- Our team will respond with availability, lead time, and a formal quotation within 1 business day.
- Upon PO confirmation, we arrange shipment via your preferred freight method (DHL, FedEx, UPS, sea freight).
- Tracking information and commercial invoice are provided upon dispatch.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, HMI, and industrial drive components — not a general electronics marketplace.
- Global Sourcing Network: Access to new, surplus, and refurbished inventory from verified suppliers across North America, Europe, and Asia.
- Fast Quotation: Most RFQs receive a response within 24 hours, with expedited options available for urgent plant shutdowns.
- Export Compliance: Experienced in international shipping documentation, export licensing, and customs requirements for industrial automation parts.
- Technical Support: Our team includes engineers with hands-on Series 90-30 experience who can assist with compatibility and integration questions.
- Secure Transactions: All orders are processed with full commercial documentation — purchase orders, invoices, packing lists, and certificates of conformance.
Frequently Asked Questions
Q: Is the IC693ALG220 still in production by GE?
A: The GE Series 90-30 platform has reached end-of-active-production, but Konmask.com maintains access to new-old-stock (NOS) and professionally refurbished units to support ongoing MRO requirements.
Q: Can the IC693ALG220 accept thermocouple or RTD inputs directly?
A: No. The IC693ALG220 accepts standard voltage and current analog signals. For thermocouple inputs, GE offers dedicated modules such as the IC693ALG221 (thermocouple) or IC693ALG223 (RTD). Signal conditioners can also be used to convert thermocouple/RTD outputs to 4–20 mA for use with the IC693ALG220.
Q: How many IC693ALG220 modules can I install in one Series 90-30 system?
A: The number of analog input modules is limited by the available I/O slots in your baseplate configuration and the CPU’s I/O capacity. Consult your CPU’s hardware manual for the maximum analog channel count per system.
Q: What programming software is required to configure the IC693ALG220?
A: GE Proficy Machine Edition (Logic Developer – PLC) is the current supported programming environment. Legacy systems may use Logicmaster 90-30 software for older CPU revisions.
Q: Do you offer a warranty on IC693ALG220 units?
A: Yes. Refurbished units carry a 90-day functional warranty. New-old-stock units are sold as-is with inspection certification. Contact us for full warranty terms.
Q: Can you ship the IC693ALG220 internationally?
A: Yes. We ship worldwide via DHL, FedEx International, UPS, and sea freight. We handle all export documentation including commercial invoices, packing lists, and certificates of origin.
