GE IC693CHS397 Modular CPU Baseplate | Replacement, Equivalent & Selection Guide
The GE IC693CHS397 is a Modular CPU Baseplate designed for the GE Fanuc Series 90-30 PLC platform. It serves as the structural and electrical backbone for mounting CPU and I/O modules in modular rack configurations. This page provides full technical specifications, compatible replacement models, application guidance, and a selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: IC693CHS397
- Manufacturer: GE Fanuc / GE Automation & Controls
- Series: Series 90-30 PLC
- Type: Modular CPU Baseplate (Rack)
- Slot Configuration: 5-slot baseplate (CPU + 4 I/O slots)
- Backplane Bus: Series 90-30 parallel backplane
- Power Supply Compatibility: IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
- Humidity: 5% to 95% non-condensing
- Mounting: DIN rail or panel mount
- Weight: Approx. 600 g
- Certifications: UL, CE, cUL
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the IC693CHS397. Always verify electrical and mechanical compatibility before substitution.
- IC693CHS391 — 5-slot baseplate, standard version; direct functional equivalent in most applications
- IC693CHS392 — 10-slot baseplate; use when additional I/O expansion is required
- IC693CHS393 — 5-slot baseplate with enhanced grounding; suitable for high-noise environments
- IC693CHS398 — Expansion baseplate; used in multi-rack configurations as a remote I/O chassis
- IC693CHS399 — 10-slot expansion baseplate; for large-scale distributed I/O setups
- Third-party equivalents: Select industrial automation suppliers offer compatible Series 90-30 baseplates — confirm backplane pinout and slot spacing before installation
Note: Konmask.com supplies both genuine GE Fanuc original parts and verified compatible alternatives. Contact us to confirm the best fit for your system.
Why Choose the Original IC693CHS397
- Guaranteed Compatibility: Factory-designed for seamless integration with all Series 90-30 CPU and I/O modules
- Proven Reliability: Validated for use in continuous industrial environments with strict uptime requirements
- OEM Traceability: Full manufacturer traceability for regulated industries (automotive, energy, water treatment)
- Firmware & Diagnostics Support: Native support for GE Proficy Machine Edition and Logicmaster 90 programming environments
- Long Service Life: Designed for 10+ years of continuous operation in industrial rack systems
Typical Applications
- Discrete manufacturing automation (assembly lines, conveyors, stamping)
- Process control systems (chemical, pharmaceutical, food & beverage)
- Water and wastewater treatment plant control
- Power generation and distribution monitoring
- Oil & gas upstream and midstream automation
- Building management and HVAC control systems
- Machine tool and CNC integration
System Compatibility
The IC693CHS397 baseplate is compatible with the following GE Series 90-30 components:
- CPUs: IC693CPU311, IC693CPU313, IC693CPU321, IC693CPU323, IC693CPU331, IC693CPU340, IC693CPU341, IC693CPU350, IC693CPU351, IC693CPU360, IC693CPU363, IC693CPU364, IC693CPU374
- Power Supplies: IC693PWR321, IC693PWR322, IC693PWR330, IC693PWR331
- I/O Modules: All standard Series 90-30 discrete and analog I/O modules
- Communications: IC693CMM301, IC693CMM302, IC693CMM311, IC693CMM321 (Ethernet, Genius, Profibus)
- Programming Software: GE Proficy Machine Edition, Logicmaster 90-30
Selection Guide
Use the following criteria to select the correct baseplate for your application:
- Slot Count: IC693CHS397 provides 5 slots (1 CPU + 4 I/O). If more than 4 I/O modules are needed in a single rack, consider IC693CHS392 (10-slot) or add an expansion rack via IC693CHS398/399.
- Single vs. Multi-Rack: For systems requiring more than 10 I/O slots, use IC693CHS397 as the main rack and IC693CHS398/399 as expansion racks connected via IC693BEM331 bus expander.
- Environment: Standard industrial environments → IC693CHS397 or IC693CHS391. High EMI/noise environments → IC693CHS393 (enhanced grounding).
- Replacement vs. Upgrade: If replacing a failed baseplate in an existing system, match the slot count and power supply model exactly. If upgrading, evaluate whether additional I/O capacity is needed.
- Budget Consideration: Genuine OEM parts ensure full warranty and traceability. Verified compatible alternatives may reduce cost for non-critical or legacy maintenance applications.
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified industrial surplus channels
- Pre-shipment inspection: visual, functional, and continuity testing
- Anti-static packaging with humidity indicators for sensitive electronics
- Batch traceability records available upon request
- Warranty: 90-day replacement warranty on all stocked units
- Counterfeit prevention: all parts verified against OEM markings and datecodes
How to Order
- Confirm your current CPU model and power supply model to ensure baseplate compatibility
- Determine required slot count (5-slot IC693CHS397 or 10-slot IC693CHS392)
- Add to cart or contact us for bulk/project pricing
- Provide your shipping address — we ship worldwide with DHL, FedEx, and UPS
- Lead time: In-stock items ship within 1–3 business days; special orders within 7–14 days
For urgent requirements or project BOM support, email support@konmask.com or call +0086 19859288691.
Replacement & Compatibility FAQ
Q: Can IC693CHS391 directly replace IC693CHS397?
A: In most cases, yes. Both are 5-slot Series 90-30 baseplates. Verify power supply connector and mounting hole positions match your enclosure before installation.
Q: Is IC693CHS397 compatible with Series 90-70 modules?
A: No. The Series 90-30 and Series 90-70 use different backplane architectures and are not cross-compatible.
Q: Can I expand beyond 5 slots without replacing the main baseplate?
A: Yes. Use IC693CHS398 or IC693CHS399 as expansion racks connected to the main rack via the IC693BEM331 Bus Expander Module.
Q: Do you supply refurbished units?
A: We supply both new and tested-refurbished units. All refurbished units are clearly labeled and carry the same 90-day warranty.
Q: How do I verify authenticity of the part I receive?
A: Each unit ships with a test report and OEM label verification. Batch traceability documentation is available on request.
Q: What is the lead time for out-of-stock units?
A: Typically 7–14 business days. Contact us for expedited sourcing options.
