GE IC693MDL753 Discrete Output Module | Series 90-30 PLC

GE IC693MDL753 – 16-Point Relay Discrete Output Module | Series 90-30 PLC Platform

Engineering Background: The GE Fanuc Series 90-30 PLC platform has been a backbone of industrial process control since the early 1990s, deployed extensively across petrochemical refineries, power generation facilities, and municipal water treatment plants. Within the Series 90-30 rack architecture, discrete output modules serve as the final control element interface — translating CPU logic states into physical switching actions that drive motors, solenoid valves, contactors, and indicator systems. The IC693MDL753 occupies the relay output tier of this architecture, providing galvanic isolation between the PLC backplane and field devices, a critical requirement in environments with high electrical noise or mixed-voltage field wiring.

Product Positioning: The IC693MDL753 is a 16-point relay output module distinguished from transistor-output alternatives (such as the IC693MDL740/741) by its inherent isolation and AC/DC load compatibility. Unlike solid-state output modules that require matched voltage rails, this relay module accommodates mixed field wiring — 24 VDC solenoids alongside 120 VAC pilot lights on the same module — making it the preferred choice for retrofit projects and legacy panel integrations where rewiring is cost-prohibitive. It is not suited for high-frequency switching applications (>10 Hz) or applications requiring sub-millisecond response times.

Complete Technical Specifications

Electrical

• Output Type: Relay (Form A, SPST-NO)
• Number of Output Points: 16
• Output Voltage Range: 5–125 VDC / 5–240 VAC
• Maximum Output Current: 2 A per point (resistive load)
• Maximum Module Current: 8 A total (all points combined)
• Minimum Load Current: 10 mA
• Output Common Configuration: 4 points per common (4 isolated commons)
• Backplane Current Draw: 800 mA @ 5 VDC
• Isolation: 1500 VAC optical isolation (field side to backplane)
• Relay Mechanical Life: >10,000,000 operations
• Relay Electrical Life: >100,000 operations at rated load

Mechanical

• Form Factor: Single-slot Series 90-30 I/O module
• Connector: 40-pin IDC field wiring connector (IC693ACC300 terminal block compatible)
• Weight: Approx. 300 g
• Dimensions: Standard Series 90-30 module profile

Environmental

• Operating Temperature: 0°C to +60°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% to 95% non-condensing
• Vibration: IEC 68-2-6 compliant
• Shock: IEC 68-2-27 compliant

Certifications

• UL Listed (UL 508)
• CE Marked (EMC Directive)
• CSA Certified
• FM Approved (Class I, Division 2, Groups A–D)

Data source: GE Fanuc Series 90-30 PLC I/O Module Specifications Manual, GFK-0898; GE Automation & Controls product datasheet IC693MDL753.

Proven Application Environments

• Petrochemical Refinery | Pump Station Control Panel | Continuous 24/7 Operation: Controls motor starter contactors and valve actuators in crude transfer pump stations where mixed AC/DC field wiring and high ambient electrical noise demand relay isolation.
• Thermal Power Plant | Boiler Auxiliary Control System | High-Temperature Ambient: Drives solenoid valves and damper actuators in boiler feed water and combustion air systems operating at sustained ambient temperatures up to 55°C.
• Municipal Water Treatment | SCADA-Integrated Dosing System | Corrosive Atmosphere: Switches chemical dosing pump contactors and alarm annunciators in chlorination and pH-correction skids where relay isolation prevents ground loop interference with 4–20 mA instrumentation.
• Automotive Assembly | Conveyor Line PLC Panel | High-Cycle Retrofit: Replaces failed relay output modules in legacy Series 90-30 panels controlling conveyor indexing and part-present indicators, leveraging existing rack infrastructure without rewiring.
• Pulp & Paper Mill | Digester Control System | High-Humidity Environment: Manages steam valve actuators and agitator motor starters in digester control loops where 95% RH non-condensing rating ensures reliable operation.
• Oil & Gas Offshore Platform | Safety Instrumented System Support Panel | Hazardous Area Adjacent: Provides discrete output switching in non-SIL-rated auxiliary panels adjacent to FM Class I Div 2 zones, leveraging the module’s FM approval for simplified area classification compliance.

Engineering Advantages

• For mixed-voltage field wiring environments, this relay output module eliminates the need for interposing relays, because each of the four isolated commons can be wired to a different voltage rail (e.g., 24 VDC, 120 VAC) simultaneously.
• For retrofit projects on existing Series 90-30 racks, this output module installs without rack modification or CPU firmware changes, because it conforms to the original Series 90-30 I/O bus protocol and slot addressing scheme.
• For applications in electrically noisy environments (VFD-heavy panels, large motor switchgear), this relay output module provides 1500 VAC galvanic isolation, because the relay coil and contact circuits share no electrical path with the PLC backplane.
• For facilities with FM Class I Division 2 area classification requirements, this output module simplifies compliance documentation, because it carries FM approval for Groups A–D hazardous locations.
• For maintenance teams managing aging installed bases, this output module reduces mean time to repair, because it is a direct plug-in replacement requiring no parameter reconfiguration in the CPU hardware configuration table.
• For procurement engineers managing multi-site spares inventory, this output module consolidates stock requirements, because a single part number covers both AC and DC load applications across the entire Series 90-30 installed base.

System Architecture & Signal Flow

Signal Flow: CPU logic state → Series 90-30 backplane I/O bus → IC693MDL753 internal logic → optical isolator → relay coil energization → relay contact closure → field device load circuit. Each output point status is reflected in the CPU output image table and is readable via the programmer (Proficy Machine Edition / Logicmaster 90).

Compatible Racks & CPUs:

• IC693CHS391 / IC693CHS392 / IC693CHS393 (5, 10, 12-slot baseplate) — direct slot compatibility
• IC693CPU364 / IC693CPU374 / IC693CPU360 — all Series 90-30 CPUs support this module without configuration changes
• IC693PWR321 / IC693PWR322 power supplies — backplane current budget must account for 800 mA draw

Compatible Terminal Block: IC693ACC300 (40-pin removable terminal block, sold separately)

Substitution Conditions: The IC693MDL752 (8-point relay output) may substitute in applications where only 8 outputs are required and slot space is at a premium. The IC693MDL740 (transistor output, 0.5 A/point, 24 VDC only) is an alternative only when all loads are 24 VDC and switching frequency exceeds 1 Hz — it is not a drop-in replacement due to differing field wiring requirements and load voltage constraints.

Sourcing & Quality Verification

Units offered through Konmask.com are sourced from decommissioned industrial control panels, authorized distributor overstock, and verified secondary market channels. Each unit undergoes the following 4-step verification process before listing:

1. Visual Inspection: Front panel label integrity, connector pin condition, housing cracks, and burn marks assessed against OEM reference standards.
2. Functional Bench Test: Module installed in a Series 90-30 test rack; all 16 output points cycled under resistive load; relay contact continuity and isolation resistance verified with calibrated test equipment.
3. Firmware / Revision Check: Hardware revision level recorded and disclosed; known revision-specific issues cross-referenced against GE Fanuc field notices.
4. Packaging & Documentation: Anti-static packaging applied; unit serial number photographed and logged for traceability.

Available Documentation Upon Request:

• Functional test report (point-by-point)
• Hardware revision disclosure
• High-resolution pre-shipment photographs
• GE Fanuc OEM datasheet (GFK-0898 extract)
• Certificate of conformance (on request for orders ≥5 units)

Procurement Process

1. Inquiry & Confirmation: Submit the required quantity and delivery timeline via the product page or directly to support@konmask.com. Hardware revision preference and any application-specific requirements should be noted at this stage.
2. Quote & Stock Verification: A confirmed stock availability response and formal quotation will be issued within 24 hours of inquiry receipt, including unit condition grade, revision level, and lead time.
3. Order & Dispatch: Upon purchase confirmation, units are packaged in anti-static materials, photographed, and dispatched with tracking. Express shipping options are available for emergency maintenance situations.

Technical Support: Pre-sales application engineering support is available for rack compatibility verification, power budget calculations, and substitution assessments. Post-sales support covers installation guidance and Proficy Machine Edition hardware configuration steps. Contact: support@konmask.com | +0086 19859288691.

Technical FAQ

Q: Is the IC693MDL753 compatible with the IC693CHS392 10-slot rack running an IC693CPU374 CPU?
A: Yes. The IC693MDL753 is compatible with all Series 90-30 baseplates (5, 10, and 12-slot) and all Series 90-30 CPUs. No hardware configuration changes are required in Proficy Machine Edition — the module is auto-detected by the CPU during power-up I/O scan. Verify the rack power supply (IC693PWR321/322) has sufficient current margin to accommodate the 800 mA backplane draw of this module.

Q: Can the IC693MDL740 transistor output module substitute for the IC693MDL753 in an existing installation?
A: Only under specific conditions. The IC693MDL740 is a 24 VDC-only, 0.5 A/point transistor output module. It cannot substitute if any field loads operate on AC voltage, exceed 0.5 A, or if the existing field wiring uses the IC693MDL753’s isolated common configuration. For AC loads or mixed-voltage panels, the IC693MDL753 or IC693MDL752 (8-point relay) are the appropriate alternatives.

Q: Does the IC693MDL753 carry FM approval for use in panels adjacent to Class I Division 2 hazardous areas?
A: Yes. The IC693MDL753 is FM approved for Class I, Division 2, Groups A, B, C, and D locations. This approval applies to the module itself when installed in a Series 90-30 rack within a suitably rated enclosure. The complete panel assembly must still comply with NEC Article 501 and applicable local electrical codes. Konmask.com can provide the FM approval documentation upon request.

---
