GE IC695ALG616 16-Channel Analog Input Module | PACSystems RX3i

GE IC695ALG616 16-Channel Analog Input Module – PACSystems RX3i

Imagine a critical process line where temperature, pressure, and flow signals from dozens of field sensors must be continuously monitored with millisecond precision. Without a reliable, high-density analog input module, signal dropouts, noise interference, or slow scan rates can cascade into unplanned shutdowns, product quality failures, or even safety incidents. In high-stakes industrial environments — from petrochemical refineries to automotive assembly lines — the analog front-end is not a commodity; it is the sensory nervous system of the entire control architecture.

The GE IC695ALG616 is a 16-channel analog input module engineered for the PACSystems RX3i platform — GE’s flagship modular PLC system that has set the benchmark for high-performance industrial automation since its introduction. Within the IC695 series, the ALG616 occupies a strategic position as a high-density, universal analog input solution, supporting both voltage and current input ranges on a single module. Its adoption spans global industries including oil & gas, power generation, water treatment, and discrete manufacturing, making it one of the most widely deployed analog input modules in the GE automation ecosystem.

Technical Specifications

• Model: IC695ALG616
• Series: PACSystems RX3i (IC695 Series)
• Manufacturer: GE (General Electric Automation)
• Number of Channels: 16 analog input channels
• Input Types: Voltage and current (configurable per channel)
• Voltage Input Ranges: ±10V, ±5V, 0–10V, 0–5V
• Current Input Range: 0–20 mA, 4–20 mA
• Resolution: 16-bit
• Isolation: Channel-to-channel isolation
• Backplane Compatibility: RX3i Universal Backplane
• Configuration: Software-configurable via Proficy Machine Edition
• Operating Temperature: 0°C to 60°C
• Form Factor: Single-slot RX3i module
• Weight: Approx. 500 g

Note: Always verify specifications against the official GE PACSystems RX3i Hardware Reference Manual for your specific application.

Key Features & Benefits

• High Channel Density: 16 channels in a single backplane slot reduces cabinet footprint and wiring complexity.
• Universal Input Flexibility: Supports both voltage and current inputs, eliminating the need for separate modules for different sensor types.
• 16-Bit Resolution: Delivers fine-grained signal resolution critical for precision process control applications.
• Channel-to-Channel Isolation: Protects against ground loops and cross-channel interference in noisy industrial environments.
• Software-Configurable: All channel parameters are configured via Proficy Machine Edition, enabling rapid commissioning and remote reconfiguration.
• RX3i Backplane Integration: Seamless plug-and-play integration with the PACSystems RX3i universal backplane architecture.
• Diagnostics Support: Built-in channel-level diagnostics for open-wire detection and over-range alarms.
• Hot-Swap Capable: Supports module replacement without full system shutdown (subject to system configuration).

Industry & Equipment Applications

• Oil & Gas: Pipeline pressure and flow monitoring, wellhead control systems
• Power Generation: Turbine control, boiler temperature monitoring, generator excitation systems
• Water & Wastewater Treatment: Level, pH, and flow measurement in treatment plants
• Automotive Manufacturing: Robotic welding process monitoring, paint booth environmental control
• Chemical & Petrochemical: Reactor temperature and pressure profiling
• Food & Beverage: Pasteurization temperature control, filling line pressure monitoring
• Pulp & Paper: Dryer section temperature control, stock consistency measurement

System Integration & Compatible Parts

The IC695ALG616 is designed to operate within the GE PACSystems RX3i ecosystem. Compatible and commonly paired components include:

• CPU Modules: IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400
• Power Supplies: IC695PSA040, IC695PSD040, IC695PSA140
• Backplanes: IC695CHS007, IC695CHS012, IC695CHS016
• Communication Modules: IC695ETM001 (Ethernet), IC695PBM300 (PROFIBUS)
• Analog Output Modules: IC695ALG704, IC695ALG708
• Programming Software: GE Proficy Machine Edition (PME)
