Process Control & Distributed Automation Solution — GE IC695CHS016 | PACSystems RX3i
Where This Product Is Used
The GE IC695CHS016 is a 16-slot CPU Universal Backplane designed for the PACSystems RX3i platform. It serves as the physical and electrical backbone of the control rack, hosting the CPU, power supply, and I/O modules in a unified chassis. Engineers specify this backplane across a wide range of demanding industrial environments:
- Oil & Gas Processing Plants — Supervisory control of compressors, separators, and pipeline SCADA systems requiring high-density I/O in a single rack.
- Automotive Manufacturing Lines — Coordinating multi-axis motion, conveyor sequencing, and quality inspection stations where rack space and deterministic scan times are critical.
- Water & Wastewater Treatment — Centralized PLC control of pumping stations, chemical dosing, and filtration processes with redundant power configurations.
- Power Generation & Utilities — Turbine governor control, load management, and substation automation requiring IEC 61850-compatible architectures.
- Pharmaceutical & Food Processing — FDA 21 CFR Part 11 and GMP-compliant batch control systems where validated hardware configurations must remain stable.
- Discrete Manufacturing & Assembly — High-speed packaging lines, robotic cell integration, and press control where mixed analog/digital I/O modules share a single backplane.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | IC695CHS016 |
| Series | PACSystems RX3i |
| Manufacturer | GE Vernova / Emerson (formerly GE Automation) |
| Backplane Type | CPU Universal Backplane |
| Number of Slots | 16 (including CPU and power supply slots) |
| Bus Architecture | Universal Backplane Bus (supports both legacy Series 90-30 and RX3i modules) |
| Power Supply Compatibility | IC695PSA040, IC695PSD040, IC695PSA140 and compatible RX3i power supplies |
| CPU Compatibility | IC695CPE302, IC695CPE305, IC695CPE310, IC695CPE330, IC695CPE400 and compatible RX3i CPUs |
| Mounting | DIN rail or panel mount |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Weight | Approx. 150 g (chassis only) |
| Dimensions | Refer to GE PACSystems RX3i System Manual, GFK-2314 |
| Agency Approvals | UL, CE, cUL |
Why Engineers Specify This Model
- Universal Slot Compatibility — Accepts both legacy Series 90-30 I/O modules and native RX3i modules in the same rack, protecting existing investments during system upgrades.
- High-Density I/O in a Single Chassis — 16 slots eliminate the need for expansion racks in most mid-size applications, reducing wiring complexity and panel footprint.
- Deterministic Backplane Bus — The RX3i universal bus delivers consistent, low-latency communication between CPU and I/O modules, essential for time-critical control loops.
- Redundancy-Ready Architecture — Supports hot-standby CPU redundancy configurations (with IC695CRU320) for applications requiring continuous availability.
- Simplified Maintenance — Modules are hot-swappable (with appropriate CPU configuration), minimizing planned downtime during module replacement.
- Long Product Lifecycle — PACSystems RX3i is a mature, widely supported platform with a committed long-term supply chain from GE Vernova / Emerson.
Complete System Bill of Materials
A typical PACSystems RX3i control rack built around the IC695CHS016 includes the following components:
- IC695CHS016 — CPU Universal Backplane (this item)
- IC695CPE305 / IC695CPE310 — RX3i CPU Module
- IC695PSA040 — 40W AC Power Supply
- IC695ETM001 — Ethernet Interface Module (SRTP / Modbus TCP)
- IC694MDL340 — 32-Point 24VDC Discrete Input Module
- IC694MDL740 — 32-Point 24VDC Discrete Output Module
- IC695ALG600 — 8-Channel Analog Input Module (4–20 mA / 0–10 V)
- IC695ALG704 — 8-Channel Analog Output Module
- IC695CRU320 — CPU Redundancy Module (for high-availability configurations)
- IC695ACC400 — Rack Mounting Kit
Contact Konmask for bundle pricing and availability on complete rack assemblies.
Compliance & Industry Standards
- UL 508A — Industrial Control Panels
- CE Marking — EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
- cUL — Canadian safety certification
- IEC 61131-2 — Programmable Controllers: Equipment Requirements and Tests
- RoHS Compliant — Restriction of Hazardous Substances (where applicable to production date)
- ATEX / IECEx — Consult Konmask for zone-rated enclosure and barrier configurations
Quality Assurance & Sourcing
Every IC695CHS016 unit sourced through Konmask.com undergoes a structured verification process before dispatch:
- Visual Inspection — Connector pins, PCB surface, and chassis integrity checked against OEM reference standards.
- Label & Firmware Verification — Part number, revision level, and date code confirmed against GE documentation.
- Functional Bench Test — Where applicable, units are powered and bus communication is verified prior to shipment.
- Traceability — Each unit ships with a Konmask inspection record and, where available, original OEM packaging and documentation.
- Warranty — 90-day replacement warranty on all verified units. Extended warranty available on request.
Konmask specializes in industrial automation components for B2B buyers. We do not sell consumer-grade or counterfeit parts. All inventory is sourced from authorized distributors, OEM surplus, or verified industrial decommissions.
How to Source This Part
- Add to Cart — Click “Add to Cart” above to purchase at the listed price. Bulk pricing available for orders of 3+ units.
- Request a Quote — Email support@konmask.com with your required quantity, delivery timeline, and project details for a formal quotation.
- Urgent Requirements — Call or WhatsApp +0086 19859288691 for same-day response on critical spares and emergency procurement.
- Freight & Export — Konmask ships globally. DDP, DAP, and EXW Incoterms available. Export documentation (CO, packing list, commercial invoice) provided on request.
- Payment — T/T (bank transfer), PayPal, and major credit cards accepted. LC available for large orders.
Application-Specific FAQ
Q: Can the IC695CHS016 accept legacy Series 90-30 modules?
A: Yes. The universal backplane bus is backward-compatible with Series 90-30 I/O modules, allowing mixed-generation racks during phased upgrades.
Q: Is this backplane compatible with the IC695CPE400 high-performance CPU?
A: Yes. The IC695CHS016 supports all current RX3i CPU modules including the CPE302, CPE305, CPE310, CPE330, and CPE400.
Q: Can I use two power supplies in this chassis for redundancy?
A: The IC695CHS016 supports a single power supply slot. For power redundancy, an external redundant power supply module (e.g., IC695PSD040 with external redundancy kit) is required.
Q: What is the maximum number of I/O modules per rack?
A: With one CPU and one power supply occupying dedicated slots, up to 14 I/O or communication modules can be installed in the remaining slots.
Q: Do you provide GE PACSystems programming software (Machine Edition)?
A: Konmask supplies hardware only. GE Machine Edition (Proficy ME) software licenses are available through GE Vernova / Emerson authorized channels.
Q: What is the lead time for this part?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical lead time is 2–4 weeks. Contact us for real-time availability.
