GE IS200PTURH1A – Turbine Vibration Monitor Card | Mark VI Control Platform
Engineering Background: The GE IS200PTURH1A is a dedicated vibration monitoring card engineered for GE’s Mark VI turbine control system — one of the most widely deployed distributed control architectures in gas turbine, steam turbine, and combined-cycle power generation facilities worldwide. Designed to operate within the VME-based I/O rack, this card provides real-time vibration signal acquisition and conditioning critical for machinery protection and predictive maintenance programs.
Product Positioning: The IS200PTURH1A serves as the primary interface between turbine shaft proximity probes (Bently Nevada-compatible) and the Mark VI controller, enabling continuous vibration amplitude and phase monitoring. It is an essential component for plants operating under API 670 machinery protection standards. Konmask.com supplies this module as a tested, OEM-equivalent replacement with full traceability documentation.
Complete Technical Specifications
- Part Number: IS200PTURH1A
- Manufacturer: GE (General Electric) — Energy / Power Conversion Division
- Platform Compatibility: Mark VI Turbine Control System (VME I/O Rack)
- Module Function: Turbine Vibration Signal Conditioning & Monitoring Card
- Input Signal Type: Proximity probe (eddy-current) / velocity transducer inputs
- Channels: Multi-channel vibration input (per rack slot configuration)
- Signal Range: Compatible with standard 5 mm / 8 mm proximity probe systems
- Output: Conditioned analog signals to Mark VI VCMI / VCRC controllers
- Communication: Internal VME backplane bus
- Power Supply: Supplied via Mark VI I/O rack backplane (28 VDC nominal)
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Form Factor: Single-slot VME card
- Weight: 1,040 g (approx.)
- Compliance: Designed to API 670 machinery protection interface standards
- Country of Origin: USA
Proven Application Environments
- Gas turbine generator sets (Frame 6B, 7E, 7F, 9E, 9F series)
- Steam turbine control systems in combined-cycle power plants
- Compressor train protection systems in LNG and petrochemical facilities
- Hydro turbine monitoring upgrades with Mark VI retrofit packages
- Industrial co-generation plants requiring API 670-compliant vibration monitoring
- OEM spare parts programs for EPC contractors and plant maintenance teams
Engineering Advantages
- High-Fidelity Signal Conditioning: Minimizes noise interference from high-voltage turbine environments, ensuring accurate vibration amplitude and phase data.
- Seamless Mark VI Integration: Plug-and-play replacement within existing Mark VI VME racks — no firmware modification required for standard configurations.
- API 670 Alignment: Supports continuous monitoring of shaft relative vibration, meeting international machinery protection standards for critical rotating equipment.
- Redundancy Support: Compatible with TMR (Triple Modular Redundancy) and dual-redundant Mark VI architectures for high-availability plant configurations.
- Long Service Life: Industrial-grade components rated for continuous duty in harsh electrical environments typical of power generation facilities.
System Architecture & Signal Flow
The IS200PTURH1A installs into the Mark VI I/O rack and interfaces directly with proximity probe field wiring via the terminal board (TRPB or equivalent). Conditioned vibration signals are transmitted over the VME backplane to the VCMI or VCRC controller cards, where they are processed by the Mark VI application software for alarm, trip, and trending functions. The card supports both simplex and redundant I/O configurations depending on the plant’s protection philosophy.
Signal Flow: Proximity Probe → Field Terminal Board → IS200PTURH1A (Signal Conditioning) → VME Backplane → VCMI/VCRC Controller → Mark VI HMI / Alarm System
Sourcing & Quality Verification
- Source: Procured from authorized OEM channels and verified surplus with full traceability
- Inspection: Each unit undergoes visual inspection, functional bench test, and firmware version verification prior to shipment
- Documentation: Certificate of conformance, test report, and shipping manifest available upon request
- Warranty: 12-month limited warranty against manufacturing defects
- Counterfeit Prevention: All units sourced with verifiable markings, date codes, and OEM packaging where available
Procurement Process
- Submit your RFQ via support@konmask.com or the product page inquiry form
- Receive a formal quotation with lead time, unit price, and shipping options within 24 hours
- Confirm purchase order — payment via T/T, PayPal, or trade terms for qualified accounts
- Unit ships with full documentation package (CoC, test report, packing list)
- Post-delivery technical support available for installation and commissioning queries
Technical FAQ
Q: Is the IS200PTURH1A compatible with both Mark VI and Mark VIe systems?
A: The IS200PTURH1A is designed for the Mark VI VME-based platform. Mark VIe uses a different I/O architecture (PROFINET-based IONet). Please confirm your controller generation before ordering.
Q: Can this card interface with Bently Nevada 3500 series proximity probes?
A: Yes, the IS200PTURH1A is compatible with standard eddy-current proximity probe systems including Bently Nevada 3300/3500 series probes when used with the appropriate terminal board configuration.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 3–5 business days. For urgent requirements, expedited shipping is available. Contact us for current stock status.
Q: Do you provide exchange or repair services?
A: Yes, Konmask.com offers exchange programs and third-party repair evaluation for IS200PTURH1A units. Contact our technical team for details.
Q: Is firmware pre-loaded on replacement units?
A: Units are supplied with the firmware version as received. Firmware upgrade services are available upon request for specific Mark VI application requirements.
