GE IC660ERD025B – Genius Bus Controller Remote Drop Module | Series 90-60 PLC Platform
Engineering Background: The IC660ERD025B is a GE Genius I/O Remote Drop Controller designed for distributed I/O architectures within GE’s Series 90-60 PLC ecosystem. It serves as the intelligent interface between the Genius Bus and remote I/O drop assemblies, enabling high-speed, deterministic data exchange across large-scale industrial control networks.
Product Positioning: Purpose-built for procurement engineers and system integrators requiring a proven, field-hardened remote drop controller for process automation, discrete manufacturing, and critical infrastructure applications. The IC660ERD025B delivers reliable bus communication with minimal configuration overhead, making it the preferred choice for both greenfield installations and legacy system expansions.
Complete Technical Specifications
- Part Number: IC660ERD025B
- Manufacturer: GE (General Electric Automation)
- Series / Platform: GE Genius I/O / Series 90-60
- Module Type: Remote Drop Controller (Bus Controller)
- Bus Interface: Genius Bus (Serial)
- Communication Protocol: Genius Bus Protocol
- Max I/O Points per Drop: Up to 64 discrete or 32 analog channels (configuration dependent)
- Bus Speed: 153.6 Kbaud (standard Genius Bus rate)
- Power Supply Voltage: 24 VDC (nominal)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Enclosure / Form Factor: DIN-rail / rack-mount compatible module
- Weight: Approx. 7.54 kg (packaged)
- Certifications: UL Listed, CE Marked (verify current revision datasheet)
- Country of Origin: USA
Proven Application Environments
- Automotive assembly lines with distributed I/O drops across conveyor zones
- Oil & gas pipeline monitoring and SCADA integration
- Water/wastewater treatment plant automation
- Power generation and substation control systems
- Pharmaceutical batch processing with GMP-compliant control architectures
- Food & beverage packaging lines requiring high-speed discrete I/O
- Legacy Series 90-60 system expansions and capacity upgrades
Engineering Advantages
- Deterministic Bus Communication: Genius Bus protocol guarantees scan-cycle synchronization, critical for time-sensitive process control.
- Distributed Architecture: Reduces panel wiring complexity by placing I/O drops close to field devices, cutting installation costs significantly.
- Hot-Standby Redundancy Support: Compatible with GE redundancy configurations for high-availability systems.
- Broad I/O Compatibility: Interfaces with the full GE Genius I/O module family — discrete, analog, and specialty modules.
- Proven Field Reliability: Decades of deployment in harsh industrial environments with documented MTBF performance.
- Simplified Diagnostics: Onboard LED status indicators and bus-level fault reporting accelerate troubleshooting.
System Architecture & Signal Flow
The IC660ERD025B connects to the Genius Bus via a single twisted-pair serial cable (daisy-chain topology). Each remote drop is assigned a unique device number (0–31) on the bus. The host PLC’s Bus Controller (e.g., IC660BBA020) polls each drop controller cyclically. The IC660ERD025B manages local I/O scanning, buffers input data, and transmits consolidated I/O images to the host controller within each bus scan cycle. This architecture decouples local I/O scan time from the host CPU scan, enabling scalable, high-point-count systems without degrading controller performance.
Typical Signal Flow: Field Device → Genius I/O Module → IC660ERD025B (Drop Controller) → Genius Bus → Host Bus Controller (IC660BBA020) → Series 90-60 CPU
Sourcing & Quality Verification
- Stock Condition: New surplus and professionally refurbished units available; all units inspected and function-tested prior to shipment.
- Authenticity: Sourced exclusively from verified industrial distributors and OEM-authorized channels — no counterfeit risk.
- Warranty: 12-month replacement warranty on all units shipped from Konmask.com.
- Traceability: Full lot traceability documentation available upon request for regulated industries.
- Packaging: Anti-static ESD packaging with foam cushioning; export carton rated for international freight.
Procurement Process
- Confirm Part Number: Verify IC660ERD025B matches your BOM or existing system documentation.
- Request Quote: Contact support@konmask.com with quantity and required delivery timeline.
- Review Datasheet: We provide the GE IC660ERD025B datasheet and wiring diagrams upon request.
- Place Order: Secure checkout via Konmask.com or PO-based procurement for qualified B2B accounts.
- Receive & Inspect: Units ship within 1–3 business days; inspection report included with each shipment.
Technical FAQ
Q: Is the IC660ERD025B compatible with GE Series 90-30 systems?
A: The IC660ERD025B is designed for the Genius Bus architecture used across GE Series 90-60 and Series 90-30 platforms. Compatibility depends on the host Bus Controller model — contact our engineers to confirm your specific configuration.
Q: Can this module operate in a redundant bus configuration?
A: Yes. The IC660ERD025B supports dual-bus redundancy when paired with appropriate GE redundancy hardware. Refer to GE publication GFK-0098 for detailed redundancy wiring guidelines.
Q: What is the maximum number of IC660ERD025B drops per Genius Bus segment?
A: Up to 32 devices (device numbers 0–31) can be addressed on a single Genius Bus segment, subject to cable length and bus loading constraints.
Q: Do you provide programming or configuration support?
A: Yes. Konmask.com offers pre-sales technical consultation and post-sales configuration guidance. Contact support@konmask.com for engineering assistance.
Q: What is the lead time for bulk orders?
A: Standard orders (1–5 units) ship within 1–3 business days. Bulk orders (6+ units) are quoted individually — typical lead time is 5–10 business days depending on stock availability.
