GE IS200TBACIH1B – Turbine Analog I/O Interface Board | Mark VI Control Platform
Engineering Background
The IS200TBACIH1B is a terminal board assembly within GE’s Mark VI Turbine Control System — one of the most widely deployed distributed control architectures in gas turbine, steam turbine, and combined-cycle power generation facilities worldwide. Designed to interface analog field signals with the Mark VI controller backbone, this board plays a critical role in real-time turbine monitoring and closed-loop control.
Product Positioning
Konmask.com supplies the IS200TBACIH1B as a verified replacement and spare component for maintenance engineers, OEM integrators, and plant procurement teams operating GE Mark VI control systems. Each unit is sourced through traceable supply channels and undergoes functional inspection prior to dispatch.
Complete Technical Specifications
| Part Number | IS200TBACIH1B |
| Manufacturer | GE (General Electric) Energy Controls |
| Platform | Mark VI Turbine Control System |
| Board Type | Analog I/O Terminal Board |
| Signal Types | Analog input / output (voltage & current) |
| Mounting | DIN rail / panel mount (Mark VI rack compatible) |
| Operating Temperature | 0°C to +60°C |
| Power Supply | Supplied via Mark VI backplane |
| Communication | Integrated with Mark VI IONet / ARCNET backbone |
| Weight | 380 g |
| Condition Available | Refurbished / Tested / New Surplus |
| Warranty | 12 months (Konmask standard) |
Proven Application Environments
- Gas turbine power plants (GE Frame 6, 7, 9 series)
- Steam turbine control systems in combined-cycle facilities
- Compressor station automation with Mark VI architecture
- Offshore platform turbine control and monitoring
- Industrial co-generation plants requiring high-reliability analog I/O
- Retrofit and upgrade projects replacing legacy Mark V systems
Engineering Advantages
- Drop-in Compatibility: Fully compatible with existing Mark VI racks — no firmware modification required for standard replacement.
- High Signal Fidelity: Precision analog conditioning circuitry minimizes noise and drift in critical turbine sensor loops.
- Redundancy Support: Supports TMR (Triple Modular Redundancy) configurations for fault-tolerant control architectures.
- Proven Field Record: Deployed in hundreds of GE turbine installations globally across power generation and oil & gas sectors.
- Rapid Deployment: Pre-tested units reduce commissioning time and minimize plant downtime during maintenance windows.
System Architecture & Signal Flow
The IS200TBACIH1B interfaces field-side analog sensors (thermocouples, RTDs, 4–20 mA transmitters) to the Mark VI controller via a structured terminal board layout. Field wiring terminates on the board’s screw terminals; signals are conditioned and routed through the I/O pack connector to the VCMI or VAIC I/O pack. The board operates within the Mark VI’s distributed I/O architecture, where each terminal board is paired with a dedicated I/O pack module mounted on the controller rack.
Signal flow: Field Sensor → IS200TBACIH1B Terminal Board → I/O Pack (VAIC/VCMI) → Mark VI Controller → IONet/ARCNET → HMI/SCADA
Sourcing & Quality Verification
- Traceability: All units sourced from documented supply chains — decommissioned plant spares, authorized distributors, or new surplus stock.
- Inspection Protocol: Visual inspection, board-level continuity check, and functional test against GE Mark VI I/O specifications.
- Cleaning & Reconditioning: Refurbished units undergo ultrasonic cleaning and conformal coating inspection.
- Packaging: Anti-static ESD packaging with desiccant; double-boxed for international freight.
- Documentation: Test report and inspection certificate available upon request.
Procurement Process
- Inquiry: Submit part number, required quantity, and delivery timeline via email or phone.
- Quotation: Receive itemized quote with unit price, lead time, and shipping options within 24 hours.
- Order Confirmation: Purchase order accepted; payment terms discussed (T/T, L/C, or platform checkout).
- Quality Hold: Final inspection and test report issued before dispatch.
- Shipment: DHL / FedEx / sea freight with full tracking; export documentation provided.
- After-Sales: 12-month warranty; technical support available for installation and commissioning queries.
Technical FAQ
Q: Is the IS200TBACIH1B compatible with Mark VIe systems?
A: The IS200TBACIH1B is designed for the Mark VI platform. Compatibility with Mark VIe requires verification of I/O pack and rack configuration — contact our engineers for a compatibility assessment.
Q: Can you supply the matching I/O pack (e.g., VAIC or VCMI)?
A: Yes. Konmask.com stocks a broad range of Mark VI I/O packs and controller modules. Request a complete BOM and we will quote the full assembly.
Q: What is the lead time for in-stock units?
A: In-stock units ship within 3–5 business days after order confirmation. Lead time for sourced units is typically 2–4 weeks.
Q: Do you provide a test report?
A: Yes. A functional test report and inspection certificate are included with every refurbished unit. New surplus units include original manufacturer documentation where available.
Q: What warranty terms apply?
A: All units carry a 12-month warranty against manufacturing defects and functional failure under normal operating conditions.
