GE IS200WEORG1ACD Exciter Output Relay Board – Mark VI Turbine Control System
When a gas or steam turbine’s exciter output relay board fails, the consequences are immediate and severe: the generator loses voltage regulation, protective relay signals go dark, and the entire turbine-generator unit must be taken offline. In power plants and industrial facilities running GE Mark VI control systems, an unplanned outage caused by a failed I/O board can cost tens of thousands of dollars per hour. The GE IS200WEORG1ACD is the precision-engineered solution that keeps exciter control loops intact and turbine protection circuits fully operational.
The IS200WEORG1ACD occupies a critical position within the Mark VI turbine control architecture — GE’s flagship distributed control platform for gas turbines, steam turbines, and combined-cycle power plants. As the Exciter Output Relay (WEOR) board, it interfaces directly with the excitation system, translating digital control commands from the Mark VI controller into hardwired relay outputs that govern field flashing, exciter protection trips, and voltage regulator enable signals. Deployed globally across GE Frame 5, Frame 6, Frame 7, and Frame 9 turbine installations, this board is a cornerstone of reliable power generation infrastructure.
Technical Specifications
- Part Number: IS200WEORG1ACD
- Series: GE Mark VI Turbine Control System
- Board Type: Exciter Output Relay (WEOR)
- Form Factor: VME-style plug-in I/O board
- Compatible Controllers: Mark VI VCMI, VCRC, VTUR, VGEN modules
- Output Type: Hardwired relay contact outputs
- Operating Environment: Industrial control panel / turbine control enclosure
- Revision: Revision ACD
- Weight: Approx. 800 g
- Manufacturer: GE Energy / GE Power
Note: Detailed electrical specifications (voltage ratings, contact ratings, I/O count) should be verified against the GE Mark VI technical manual for your specific turbine configuration. Konmask does not fabricate or alter specifications.
Key Features & Benefits
- Direct Exciter Interface: Provides hardwired relay outputs to the excitation system, ensuring deterministic response times critical for generator protection.
- Mark VI Native Compatibility: Designed and manufactured by GE to integrate seamlessly with the Mark VI control backbone — no firmware patching or adapter boards required.
- Relay Contact Isolation: Galvanically isolated relay outputs protect the control system from high-voltage transients originating in the excitation circuit.
- Hot-Swap Ready Architecture: VME-style form factor supports replacement during scheduled maintenance windows with minimal downtime.
- Long Service Life: Industrial-grade components rated for continuous operation in demanding turbine control environments.
- Revision ACD Stability: The ACD revision incorporates GE’s field-proven design improvements for enhanced relay contact reliability.
Industry & Equipment Applications
- Power Generation: Gas turbine generators (GE Frame 5, 6B, 7EA, 7FA, 9E, 9FA series) and steam turbine generators in utility and IPP plants.
- Combined-Cycle Plants: HRSG and combined-cycle configurations where Mark VI controls both gas and steam turbine trains.
- Oil & Gas: Mechanical-drive gas turbines in pipeline compression stations and offshore platforms.
- Industrial Cogeneration: Captive power plants in petrochemical, steel, and cement facilities.
- LNG Facilities: Turbine-driven compressor trains in liquefaction and regasification terminals.
System Integration & Compatible Parts
The IS200WEORG1ACD operates within the GE Mark VI I/O subsystem alongside the following commonly paired modules:
- IS200VCRCH1BBB — Mark VI VCRC Controller Board
- IS200VCMIH2C — Mark VI VCMI I/O Interface Module
- IS200TREGH1B — Turbine Regulation Board
- IS200EXHSG1A — Exciter Hardware Signal Board
- IS200WROBH1A — Relay Output Board (complementary relay I/O)
- DS200TCQAG1BHF — Mark V/VI Transition I/O Board
Contact our technical team to verify compatibility with your specific Mark VI panel revision and turbine model before ordering.
Our Quality Assurance Process
- Visual Inspection: Every board is inspected for physical damage, burnt components, corrosion, and connector integrity upon receipt.
- Functional Verification: Boards are bench-tested against GE Mark VI I/O specifications where test fixtures are available.
- Authenticity Check: Part numbers, revision codes, and GE manufacturing markings are verified against known-good references.
- ESD-Safe Handling: All boards are handled in ESD-controlled environments and shipped in anti-static packaging.
- Documentation: Test records and inspection reports available upon request for critical plant applications.
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your part number (IS200WEORG1ACD), required quantity, and delivery timeline.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and stock availability.
- Confirm & Pay: Approve the proforma invoice and complete payment via T/T bank transfer or other agreed method.
- Ship & Track: Parts are dispatched with full tracking. Express air freight available for urgent requirements.
Why Choose Konmask.com?
- ✅ Industrial Automation Specialists: We focus exclusively on PLC, DCS, and turbine control components — not a general electronics reseller.
- ✅ Global Sourcing Network: Access to genuine GE Mark VI parts from verified supply channels worldwide.
- ✅ Technical Support: Our team includes engineers with hands-on Mark VI experience who can assist with part identification and compatibility questions.
- ✅ Fast Response: Inquiries answered within 1 business day. Emergency sourcing support available.
- ✅ Secure Packaging: ESD-safe, double-boxed shipping to protect sensitive electronics in transit.
- ✅ Trusted by Plants Worldwide: Serving power generation and industrial automation customers across Asia, the Middle East, Europe, and the Americas.
Frequently Asked Questions
Q: Is the IS200WEORG1ACD in stock?
A: Stock levels vary. Please submit an inquiry for real-time availability. We maintain an active sourcing network and can typically locate this board within 3–7 business days if not immediately available.
Q: What does the “ACD” revision mean?
A: The revision suffix (ACD) identifies the specific engineering change level of the board. Always specify the full part number including revision when ordering to ensure compatibility with your Mark VI panel configuration.
Q: Can this board be used as a direct replacement for IS200WEORG1ABB or other revisions?
A: Revision interchangeability depends on your specific Mark VI panel and software version. Our technical team can advise — please provide your panel serial number and current board revision when inquiring.
Q: Do you offer a warranty?
A: Yes. We offer a standard warranty on all parts supplied. Warranty terms are confirmed at the time of quotation based on part condition (new, refurbished, or tested surplus).
Q: Can you ship internationally?
A: Yes. We ship globally via DHL, FedEx, and UPS Express. Export documentation including commercial invoice and packing list is provided for customs clearance.
Q: What if I need technical documentation?
A: We can assist with locating GE Mark VI technical manuals and wiring diagrams for reference purposes. Contact us with your request.
