The GE Multilin UR Series represents GE Grid Solutions’ flagship platform for universal protection, control, and monitoring of power system assets. Designed for utility-grade and industrial substation environments, the UR platform delivers IEC 61850-compliant communications, high-speed protection algorithms, and modular I/O architecture in a single, standardized chassis. The UR 6CH is a specific I/O or communications module within this platform, engineered to extend the relay’s channel capacity and integration capability.
Product Positioning
The UR 6CH module is targeted at protection engineers and substation automation specialists who require deterministic, high-integrity signal handling within GE Multilin UR-series relay systems. It is the preferred choice for greenfield substation builds, protection scheme upgrades, and legacy system modernization projects where GE Multilin compatibility is mandatory.
Complete Technical Specifications
| Manufacturer | GE Grid Solutions (GE Multilin) |
| Part Number / SKU | UR 6CH |
| Series | UR Universal Relay Platform |
| Module Type | Universal Relay Module (Channel / I/O Expansion) |
| Form Factor | Modular plug-in card for UR chassis |
| Operating Temperature | -40°C to +85°C (storage); -20°C to +60°C (operating, typical UR platform) |
| Power Supply | Per UR chassis specification (24–250 V DC / 100–240 V AC options) |
| Communication Protocols | IEC 61850 GOOSE/MMS, DNP3, Modbus RTU/TCP, IEC 60870-5-103/104 (platform-level) |
| Compliance Standards | IEC 60255, IEEE C37.90, UL, CE, CSA |
| Mounting | 19-inch rack / panel-mount UR chassis |
| Weight | Approx. 268 g (module only) |
| Country of Origin | Canada / USA (GE Multilin manufacturing) |
Note: Detailed electrical parameters (CT/VT input ratings, contact ratings, channel count) are available upon request or in the GE Multilin UR Series Instruction Manual. Contact support@konmask.com for the full datasheet.
Proven Application Environments
- Transmission & Distribution Substations — Line, transformer, bus, and feeder protection schemes requiring modular I/O expansion
- Industrial Power Systems — Motor, generator, and capacitor bank protection in heavy industry (oil & gas, mining, petrochemical)
- Protection Scheme Upgrades — Replacement of legacy electromechanical or first-generation numerical relays with UR platform modules
- Utility Grid Modernization — Smart grid integration projects demanding high-speed, deterministic protection response
- Renewable Energy Integration — Wind farm and solar plant collector system protection
- Platform Modularity — Plug-in card architecture allows field-level module replacement without full relay changeout, minimizing outage windows
- Deterministic Performance — GE Multilin UR platform delivers sub-cycle protection operating times, critical for high-speed fault clearance
- IEC 61850 Native — Full GOOSE and MMS support enables seamless integration into modern digital substation architectures
- Unified Platform — Common hardware, firmware, and EnerVista software suite across all UR modules reduces engineering and maintenance overhead
- Cybersecurity Ready — Role-based access control (RBAC) and encrypted communications align with NERC CIP requirements
- Long Service Life — GE Multilin’s global installed base and long-term parts availability ensure 20+ year asset lifecycle support
- Input Acquisition — Analog (CT/VT) and digital (contact) inputs are sampled at high frequency by dedicated DSP hardware on each I/O module
- Backplane Communication — Sampled values and status data are transmitted to the CPU module via the UR chassis backplane at deterministic intervals
- Protection Processing — The CPU executes protection algorithms (overcurrent, differential, distance, etc.) on the consolidated dataset
- Output Execution — Trip and control outputs are driven by dedicated output modules, with hardware-enforced latency guarantees
- SCADA / SA Integration — IEC 61850, DNP3, or Modbus data is published via the front or rear Ethernet/serial ports to the station HMI or RTU
- Source Authentication — All units are sourced exclusively from authorized GE Grid Solutions distributors, certified system integrators, or verified surplus channels with documented chain of custody
- Physical Inspection — Each module undergoes visual inspection for label authenticity, firmware version verification, connector integrity, and absence of counterfeit indicators
- Functional Bench Test — Where applicable, modules are powered and communications-tested using GE EnerVista software to confirm firmware version and module identity
- Documentation Package — Shipment includes available original GE documentation, test records, and Konmask.com verification certificate
- Submit Inquiry — Email support@konmask.com with your required part number (UR 6CH), quantity, required delivery date, and project details
- Quotation & Lead Time — Konmask.com will respond within 1 business day with pricing, availability, and estimated lead time
- Order Confirmation — Issue a Purchase Order (PO) referencing the Konmask.com quotation number
- Quality Hold Period — Final inspection and documentation preparation (1–2 business days)
- Shipment & Tracking — DHL / FedEx / UPS express or freight forwarding per customer preference; tracking number provided within 24 hours of dispatch
- Post-Delivery Support — Konmask.com provides 30-day post-delivery technical support for installation and commissioning queries
Engineering Advantages
System Architecture & Signal Flow
The UR 6CH module integrates into the UR chassis backplane, interfacing directly with the UR CPU module via the internal high-speed bus. Signal flow within the UR platform follows a deterministic, interrupt-driven architecture:
The UR 6CH module’s role within this architecture is to extend the available channel count (analog inputs, digital inputs, or output contacts) beyond the base chassis configuration, enabling protection engineers to implement complex multi-function schemes within a single UR chassis.
Sourcing & Quality Verification
Konmask.com operates a structured 4-step verification process for all GE Multilin UR series modules:
All units are shipped in ESD-safe packaging with humidity indicators. Traceability records are retained for a minimum of 5 years.
Procurement Process
For urgent requirements or large-volume procurement, contact us directly at +0086 19859288691.
Technical FAQ
Q: Is the UR 6CH compatible with all UR chassis sizes?
A: The UR 6CH is designed for the GE Multilin UR modular chassis. Compatibility depends on the specific chassis model and slot configuration. Please provide your chassis model when inquiring to confirm fit.
Q: Can the UR 6CH be field-replaced without relay reconfiguration?
A: In most UR platform configurations, module replacement requires re-downloading the relay settings file via EnerVista software. Konmask.com can provide guidance on the replacement procedure.
Q: What firmware version does the supplied unit carry?
A: Firmware version varies by unit. We will confirm the firmware version during the quotation stage and can advise on upgrade paths if required.
Q: Do you supply the GE EnerVista software with the module?
A: EnerVista software is available directly from GE Grid Solutions. Konmask.com can provide guidance on obtaining the correct software version for your UR platform.
Q: What is your warranty policy?
A: Konmask.com provides a 90-day warranty against defects in materials and workmanship for all verified units. Extended warranty options are available upon request.
Q: Can you supply multiple UR series modules for a complete protection panel build?
A: Yes. Konmask.com maintains inventory across the full GE Multilin UR series. Contact us with your complete BOM for a consolidated quotation.
