Process Control Solution — GE Fanuc IC670ALG320 | Series 90 Micro PLC Analog Output Module
Where This Product Is Used
The GE Fanuc IC670ALG320 Analog Output Module is deployed across demanding industrial environments where precise, continuous signal control is non-negotiable. Typical application scenarios include:
- Chemical & Petrochemical Plants — Modulating control valves for flow, pressure, and temperature loops in reactor and distillation systems.
- Water & Wastewater Treatment — Driving variable-speed pump drives and dosing valve actuators via 4–20 mA or 0–10 V command signals.
- Food & Beverage Processing — Proportional control of steam injection, mixing ratios, and conveyor speed references in hygienic production lines.
- HVAC & Building Automation — Analog setpoint output to VAV damper actuators, chiller capacity controllers, and boiler modulation systems.
- Discrete Manufacturing & Assembly — Tension control, servo amplifier reference signals, and analog position commands in machine tool and press applications.
- Oil & Gas Upstream/Midstream — Remote wellhead control panels requiring compact, DIN-rail-mounted analog output in hazardous-area enclosures.
Technical Specifications
| Part Number | IC670ALG320 |
| Manufacturer | GE Fanuc (now Emerson / GE Automation) |
| Series | Series 90 Micro PLC (GE 90-Micro) |
| Module Type | Analog Output |
| Output Channels | 2 channels (isolated) |
| Output Signal Range | 4–20 mA / 0–20 mA (current); 0–10 V (voltage, jumper-selectable) |
| Resolution | 12-bit (1 in 4,096) |
| Load Impedance (Current) | 0–500 Ω |
| Load Impedance (Voltage) | ≥ 1 kΩ |
| Accuracy | ±0.1% of full scale at 25 °C |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Power Consumption | Supplied via Series 90 Micro backplane bus |
| Mounting | Snap-on to Series 90 Micro base unit |
| Weight | ~300 g |
| SKU / Catalog No. | IC670ALG320 |
Why Engineers Specify This Model
- Dual-channel isolated outputs eliminate ground-loop interference between field devices — critical in long cable runs common in plant-floor environments.
- 12-bit resolution delivers fine-grained control authority (0.024% step size), meeting the accuracy demands of PID loops in process industries.
- Jumper-selectable current/voltage mode per channel allows a single module SKU to interface with both current-loop transmitters and voltage-input drives, reducing spare-parts inventory.
- Native Series 90 Micro compatibility — plug-and-play integration with IC670MDL series base units; no additional gateway or signal conditioner required.
- Compact DIN-rail footprint suits panel space-constrained OEM machine builds and retrofit projects where rack space is at a premium.
- Proven field reliability — the IC670 platform has an established multi-decade installed base, with readily available replacement modules and documented firmware.
Complete System Bill of Materials
For a fully operational Series 90 Micro analog output node, engineers typically specify the following alongside the IC670ALG320:
- IC670CHS002 — 5-slot Series 90 Micro base unit (DIN-rail mount)
- IC670PWR101 — 24 VDC power supply module
- IC670CPU101 / IC670CPU105 — Series 90 Micro CPU module
- IC670ALG320 — This analog output module (qty as required)
- IC670ALG240 — Analog input module (for closed-loop PID feedback)
- IC690ACC900 — Hand-held programmer / configuration tool
- Shielded twisted-pair cable (Belden 8761 or equivalent) for analog field wiring
Compliance & Industry Standards
- Designed and tested to IEC 61131-2 programmable controller hardware requirements
- CE Marking — EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU
- UL Listed for industrial control equipment (UL 508)
- RoHS compliant (Directive 2011/65/EU)
- Compatible with NAMUR NE 43 signal range conventions (4–20 mA with fault detection margins)
Quality Assurance & Sourcing
All IC670ALG320 units offered through Konmask.com are subject to the following quality controls:
- Visual & mechanical inspection — housing integrity, connector pin condition, label legibility, and firmware revision verification.
- Functional power-on test — module is energized on a Series 90 Micro base and output channel continuity is confirmed prior to shipment.
- Traceability — each unit is logged with serial number, inspection date, and technician ID for full audit trail.
- Anti-static packaging — shipped in ESD-safe bags with foam cushioning inside double-wall corrugated cartons.
- Sourcing transparency — units are sourced from decommissioned OEM equipment, authorized distributors, or certified surplus channels. Counterfeit-risk screening is applied to all inbound stock.
How to Source This Part
- Confirm compatibility — verify your existing Series 90 Micro base unit model (IC670CHS001/002/003) and CPU firmware revision support the IC670ALG320.
- Check stock availability — contact support@konmask.com or call +0086 19859288691 for real-time inventory confirmation and lead time.
- Request a quotation — provide quantity, required delivery date, and destination port. Volume pricing is available for orders of 3+ units.
- Place order — payment via T/T bank transfer, PayPal, or trade-platform escrow. Pro-forma invoice issued within 1 business day.
- Shipping & documentation — DHL / FedEx express or sea freight consolidation available. Commercial invoice, packing list, and test report included with every shipment.
Application-Specific FAQ
Q: Can the IC670ALG320 drive a 4–20 mA control valve positioner directly?
A: Yes. With current output mode selected and load impedance ≤ 500 Ω, the module will drive standard HART-compatible or conventional 4–20 mA positioners without an external loop power supply, provided the Series 90 Micro power supply is correctly sized.
Q: Is the IC670ALG320 compatible with the newer VersaMax Micro (IC200) platform?
A: No. The IC670 series is mechanically and electrically specific to the Series 90 Micro backplane. VersaMax Micro uses the IC200ALG320 equivalent. Konmask stocks both — contact us to confirm the correct part for your platform.
Q: What is the update rate for the analog outputs?
A: Output update rate is governed by the CPU scan cycle. At typical scan times of 5–20 ms for small I/O configurations, the effective analog output refresh rate is 50–200 Hz — adequate for all standard process control loops.
Q: Can I use this module in a hazardous area (Zone 2 / Class I Div 2)?
A: The IC670ALG320 itself is not ATEX/IECEx certified. For hazardous-area installations, mount the module in a purged and pressurized enclosure (Ex p) or use certified Zener barriers/galvanic isolators between the module outputs and field devices located in the hazardous zone.
Q: Do you provide a warranty?
A: Yes. Konmask offers a 90-day functional warranty on all tested units. If a module fails under normal operating conditions within the warranty period, we will replace or refund at our discretion. See our full warranty policy at Konmask.com.
