Genuine SIEMENS 6AV6642-0DA01-1AX1 OP177B Operator Panel | SIMATIC HMI Series – Verified Source
The SIEMENS 6AV6642-0DA01-1AX1 OP177B is a cornerstone HMI device within the SIMATIC HMI portfolio, widely deployed across discrete manufacturing, process automation, and critical infrastructure worldwide. Its combination of a 5.7″ STN display, multi-key operation, and robust PROFIBUS/MPI/Ethernet connectivity makes it one of the most specified operator panels in industrial automation — and consequently one of the most counterfeited. The market is saturated with refurbished units misrepresented as new, cloned firmware devices, and grey-market stock with falsified date codes. Purchasing from an unverified source carries real operational risk: premature failure, voided OEM warranty, and potential safety incidents in live production environments.
Konmask sources the 6AV6642-0DA01-1AX1 exclusively through authorized distribution channels and verified OEM-aligned supply networks. Every unit we ship is inspected against SIEMENS factory specifications before dispatch. Our procurement team cross-references batch traceability data, date codes, and firmware versions to confirm each panel is genuine, authentic, and verified — not refurbished, not cloned, and not grey-market. When you order from Konmask, you receive a product you can trust to perform in your facility from day one.
Technical Specifications
- Part Number: 6AV6642-0DA01-1AX1
- Product Family: SIMATIC HMI OP177B
- Display: 5.7″ STN color display, 320 × 240 px (QVGA)
- Keypad: 14 function keys (F1–F14), 4 cursor keys, numeric/alphanumeric input
- Interfaces: PROFIBUS DP (RS-485), MPI, USB (Type A + Type B), Ethernet RJ45
- Communication Protocols: PROFIBUS, MPI, TCP/IP, S7 protocol
- Memory: 512 KB user memory (project), 2 MB flash
- Operating Voltage: 24 V DC (20.4–28.8 V)
- Power Consumption: Approx. 8 W
- Operating Temperature: 0 °C to +50 °C (horizontal), 0 °C to +40 °C (vertical)
- Storage Temperature: −20 °C to +60 °C
- Protection Rating: IP65 (front panel), IP20 (rear)
- Dimensions (W × H × D): 260 × 200 × 55 mm
- Weight: Approx. 1.2 kg
- Certifications: CE, UL, cUL, FM, ATEX Zone 2 (with appropriate housing)
- Compatible Software: WinCC flexible 2008 SP3 and above
Specifications verified against SIEMENS official documentation (SIMATIC HMI OP177B Operating Instructions, Order No. 6AV6691-1DC01-0AB0).
Our 4-Step Quality Verification Process
- Step 1 — Source Traceability Audit: We verify the supply chain origin of every batch. Supplier credentials, OEM authorization letters, and batch traceability records are reviewed before purchase. Units from unverifiable sources are rejected outright.
- Step 2 — Physical Authenticity Inspection: Each unit undergoes visual inspection: label integrity, holographic seals, date code consistency, housing mold quality, and connector pin condition. Any cosmetic anomaly triggers rejection. We can provide unboxing photos upon request.
- Step 3 — Functional Power-On Test: Units are powered at 24 V DC and tested for display output, keypad response, USB enumeration, and communication port activity. Firmware version is confirmed against SIEMENS release records. A test report is available on request.
- Step 4 — Pre-Shipment Documentation Package: Every shipment is accompanied by a Packing List, Certificate of Conformance (COC), Country of Origin (COO) Declaration, and optional Test Report. We can also provide a Certificate of Authenticity (COA) for enterprise procurement requirements.
Key Features & Benefits
- Multi-Protocol Connectivity: Native PROFIBUS DP, MPI, and Ethernet support enables seamless integration into both legacy S7-300/400 architectures and modern TIA Portal environments — compliant with IEC 61158 fieldbus standards.
- IP65 Front Panel Protection: Rated to IEC 60529 IP65, the OP177B withstands dust ingress and direct water jets, making it suitable for washdown and harsh industrial environments without additional enclosure modification.
- Robust Keypad Interface: 14 dedicated function keys reduce operator error in high-stakes environments where touchscreen operation is impractical due to gloves, vibration, or contamination.
- WinCC Flexible Compatibility: Full compatibility with WinCC flexible 2008 SP3+ ensures straightforward project migration from existing SIMATIC HMI installations with no additional licensing overhead.
- Extended Temperature Range: Operates reliably from 0 °C to +50 °C, meeting the thermal demands of foundry, chemical, and outdoor cabinet applications.
- Compact Panel-Cut Footprint: Standard 260 × 200 mm cutout dimensions allow direct replacement of legacy OP170B and OP177A installations without cabinet modification — reducing retrofit downtime.
Typical Applications
- Automotive Manufacturing: Line HMI for robotic welding cells and conveyor control panels integrated with S7-300 PLCs via PROFIBUS DP.
- Water & Wastewater Treatment: Operator interface for pump station control, dosing systems, and SCADA-linked process visualization in IP65-rated field cabinets.
- Food & Beverage Processing: Washdown-rated HMI for filling, capping, and labeling lines requiring hygienic panel design and glove-compatible keypad operation.
- Chemical & Petrochemical Plants: Local operator station for reactor control, valve sequencing, and alarm management in Zone 2 classified areas (with appropriate housing).
- Power Generation & Distribution: Substation and switchgear HMI for breaker status visualization and protection relay parameter entry via MPI/PROFIBUS.
- Building Automation & HVAC: Central operator panel for BMS integration, chiller plant control, and energy monitoring dashboards in commercial facilities.
Compatible System Components
- SIEMENS SIMATIC S7-300 CPUs (e.g., CPU 315-2 PN/DP, CPU 317-2 DP)
- SIEMENS SIMATIC S7-400 CPUs (e.g., CPU 414-3 PN/DP, CPU 416-3 PN/DP)
- SIEMENS PROFIBUS DP network cables and connectors (6ES7972-0BA52-0XA0)
- SIEMENS SIMATIC NET CP 343-1 / CP 443-1 Ethernet modules
- SIEMENS 24 V DC power supplies (e.g., SITOP PSU100S 6EP1334-2BA20)
- WinCC flexible 2008 SP3 / SP4 engineering software
- SIEMENS USB/MPI programming cable (6ES7972-0CB20-0XA0)
- Panel mounting gaskets and cutout templates (available on request)
Global Sourcing & Shipping Capabilities
- Primary Service Regions: Mainland China, Hong Kong SAR, Southeast Asia (Vietnam, Thailand, Indonesia, Malaysia), Middle East (UAE, Saudi Arabia), Europe (Germany, Poland, Netherlands), and North America (USA, Canada, Mexico).
- Export Packaging Standard: Anti-static foam insert, moisture-barrier poly bag, double-wall corrugated carton with shock-absorbing corner pads. Fragile and ESD labels applied per IEC 61340-5-1 handling guidelines.
- Logistics Options: DHL Express (2–5 business days), FedEx International Priority, sea freight LCL/FCL for bulk orders, and air cargo for urgent requirements. All shipments include tracking and insurance.
- Lead Time: In-stock units ship within 1–3 business days of payment confirmation. Pre-order or bulk procurement: 7–15 business days depending on sourcing requirements.
- Export Documentation: Commercial Invoice, Packing List, COO Declaration, and HS Code classification (8537.10) provided as standard for customs clearance.
Certifications & Compliance Statement
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL / cUL Listed — UL 508 Industrial Control Equipment
- FM Approved — Class I, Division 2 (with appropriate enclosure)
- RoHS Compliant — Directive 2011/65/EU
- ATEX Zone 2 Capable — EN 60079-15 (with certified housing)
Konmask Quality Commitment: All products sold by Konmask.com are sourced from verified supply chains and inspected prior to shipment. We do not sell refurbished, repaired, or counterfeit goods. If any unit fails to meet the specifications stated on this page, we will arrange replacement or full refund within our warranty period. Our quality commitment is backed by documented inspection records available to enterprise buyers upon request.
How to Order
- Step 1 — Confirm Your Requirement: Add the 6AV6642-0DA01-1AX1 to your cart, or contact us directly at support@konmask.com with your quantity, delivery timeline, and any documentation requirements (COC, test report, COO).
- Step 2 — Receive Quotation & Availability Confirmation: Our team responds within 24 hours (business days, UTC+8). For urgent requirements, call or WhatsApp: +0086 19859288691. We will confirm stock availability, lead time, and pricing before you commit.
- Step 3 — Place Order & Ship: Upon payment confirmation, your order is processed, inspected, packed to export standard, and dispatched with full tracking. Sample units and pre-shipment test reports are available for qualified enterprise buyers — please request at the time of inquiry.
Authenticity & Trust FAQ
-
Q: How can I verify the unit I receive is genuine SIEMENS?
A: Each unit ships with a Certificate of Conformance (COC) and, upon request, a pre-shipment test report documenting power-on results and firmware version. You can also verify the product’s date code and serial number against SIEMENS’ product identification guidelines. We welcome third-party inspection arrangements for large orders. -
Q: What is your warranty policy?
A: Konmask provides a 12-month warranty against manufacturing defects and authenticity issues from the date of shipment. If a unit is found to be non-genuine or fails under normal operating conditions within the warranty period, we will replace it or issue a full refund — no dispute required. -
Q: Can you provide a test report or inspection photos before shipment?
A: Yes. Pre-shipment test reports, unboxing photos, and COC documents are available for all orders upon request. For orders above 5 units, these are provided as standard. Enterprise buyers may also request a video inspection call prior to dispatch.
