Genuine Bently Nevada 3500/33 149986-01 16-Channel Relay Module | 3500 Series – Verified Source
The Bently Nevada 3500/33 149986-01 is a critical 16-channel relay output module within the industry-standard 3500 Series machinery protection system — a platform trusted by power generation, oil & gas, and petrochemical facilities worldwide for continuous turbomachinery monitoring. Due to its essential role in safety-critical applications and its position as an end-of-life or allocation-constrained component, the 3500/33 149986-01 is frequently counterfeited or misrepresented as refurbished-to-new in the secondary market. Purchasing from unverified sources carries significant risk: substandard relay contacts, incorrect firmware revisions, and missing calibration data can lead to false trips, missed alarms, or catastrophic equipment failure.
Konmask sources the 3500/33 149986-01 exclusively through verified industrial distribution channels and direct factory-authorized partners. Every unit we supply is inspected against Bently Nevada’s original engineering specifications before shipment. We embed genuine, verified, and authentic sourcing practices into every transaction — not as marketing language, but as an operational standard backed by documentation you can review before you buy.
Technical Specifications
- Manufacturer: Bently Nevada (Baker Hughes)
- Part Number: 3500/33 149986-01
- Module Type: 16-Channel Relay Output Module
- Relay Channels: 16 independent relay outputs
- Relay Type: SPDT (Form C) electromechanical relays
- Contact Rating: 5 A @ 250 VAC / 30 VDC (resistive load)
- Operating Voltage: 18–32 VDC (supplied via 3500 rack backplane)
- Communication: Internal rack bus; compatible with 3500 System Monitor
- Rack Compatibility: Bently Nevada 3500 Rack (4-slot, 8-slot, 14-slot)
- Operating Temperature: 0°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 5% to 95% RH, non-condensing
- Dimensions: Standard 3500 Series single-wide module form factor
- Weight: Approx. 750 g
- Certifications: CE, cULus, SIL 2 capable (system-level)
- Country of Origin: USA
Specifications verified against Bently Nevada official documentation (3500/33 Relay Output Module Manual, Rev. J).
Our 4-Step Quality Verification Process
- Step 1 — Source Authentication: We verify the supply chain origin of every unit, confirming factory lot codes, date codes, and authorized distributor documentation before the module enters our inventory. Units without traceable provenance are rejected outright.
- Step 2 — Physical & Visual Inspection: Each module undergoes a detailed visual inspection: PCB markings, relay brand and date codes, connector integrity, label authenticity, and housing condition are checked against known-good reference units. Counterfeit indicators (mismatched fonts, incorrect silkscreen, re-marked ICs) result in immediate rejection.
- Step 3 — Functional Bench Test: Modules are powered in a 3500 rack test environment. All 16 relay channels are cycled and contact resistance is measured. Alarm and trip relay logic is verified against the 3500/33 specification. Results are logged and available as a Test Report upon request.
- Step 4 — Documentation Package: Every shipment is accompanied by a Certificate of Conformance (COC), Packing List, Country of Origin (COO) Declaration, and optional photographic inspection record. Test Reports are available for orders requiring ITP (Inspection and Test Plan) compliance.
Key Features & Benefits
- 16 Independent SPDT Relay Outputs: Provides flexible alarm and trip signal routing for complex protection logic without external relay panels, reducing wiring complexity and failure points.
- Seamless 3500 Rack Integration: Hot-swap capable within the 3500 rack architecture, enabling module replacement without full system shutdown — critical for continuous-process facilities per ISA-18.2 alarm management standards.
- SIL 2 System-Level Capability: When integrated within a certified 3500 system configuration, supports Safety Integrity Level 2 applications in accordance with IEC 61511 functional safety requirements for the process industry.
- High Contact Reliability: Gold-flashed relay contacts rated for low-level signal switching, minimizing contact resistance drift over service life — essential for 4–20 mA and dry-contact alarm circuits.
- Configurable via System Monitor: Relay assignments, latching behavior, and voting logic are fully configurable through the Bently Nevada System Monitor software without hardware modification.
- Long Service Life Design: Designed to IEC 60068 environmental stress standards, ensuring reliable operation in the vibration, temperature cycling, and humidity conditions typical of turbomachinery enclosures.
Typical Applications
- Gas Turbine Protection: Relay output for overspeed, high vibration, and high temperature trip signals on industrial gas turbines in power generation and compression stations.
- Steam Turbine Monitoring: Alarm and trip relay routing for axial position, differential expansion, and eccentricity channels on steam turbines in combined-cycle power plants.
- Centrifugal Compressor Safety: Surge detection and high-vibration trip relay outputs for centrifugal compressors in LNG, refinery, and gas processing facilities.
- Pump & Motor Protection: Relay signaling for high-vibration and bearing temperature alarms on large rotating machinery in water treatment and chemical processing plants.
- Offshore Platform Machinery: Relay output module for topside rotating equipment protection systems where SIL-rated safety instrumented systems (SIS) are required per IEC 61511.
- Petrochemical Plant DCS Integration: Hardwired relay interface between the 3500 machinery protection system and plant DCS/SCADA for alarm annunciation and ESD system integration.
Compatible System Components
- Bently Nevada 3500/01 Rack (4-slot, 8-slot, 14-slot configurations)
- Bently Nevada 3500/05 System Monitor Module
- Bently Nevada 3500/15 Power Supply Module
- Bently Nevada 3500/20 Keyphasor Module
- Bently Nevada 3500/22M Transient Data Interface (TDI)
- Bently Nevada 3500/25 Ethernet Interface Module
- Bently Nevada 3500/40M Proximitor I/O Module
- Bently Nevada 3500/42M Proximitor/Seismic Monitor
- Bently Nevada 3500/50M Tachometer Module
- Bently Nevada System Monitor Software (v5.x and above)
Global Sourcing & Shipping Capabilities
- Primary Service Regions: China Mainland, Hong Kong SAR, Southeast Asia (Singapore, Malaysia, Thailand, Indonesia), Middle East (UAE, Saudi Arabia, Qatar), Europe (Germany, Netherlands, UK), and North America (USA, Canada).
- Export Compliance: All shipments are processed with full commercial invoice, packing list, and COO declaration. Export classification (ECCN/HTS) documentation available upon request for customs clearance.
- Packaging Standard: Modules are shipped in anti-static ESD bags, individually bubble-wrapped, and packed in double-wall corrugated cartons with foam inserts. Fragile and electronics handling labels applied per ISTA 2A transit testing standards.
- Logistics Options: DHL Express, FedEx International Priority, UPS Worldwide Express, and sea freight (LCL/FCL) for bulk orders. Lead time: 3–7 business days for in-stock units; 2–4 weeks for sourced units.
- Urgent Delivery: Same-day dispatch available for orders confirmed before 14:00 HKT on business days.
Certifications & Compliance Statement
- CE Marking (EU Machinery Directive 2006/42/EC)
- cULus Listed (UL 508 Industrial Control Equipment)
- RoHS Compliant (EU Directive 2011/65/EU)
- SIL 2 Capable — System Level (IEC 61508 / IEC 61511)
- ISO 9001:2015 — Konmask Quality Management System
Konmask Quality Commitment: We supply only genuine, traceable Bently Nevada components. Every unit is backed by our written Certificate of Conformance. If any module supplied by Konmask is found to be non-genuine upon independent verification, we will provide a full replacement or refund — no questions asked. Our reputation is built on the integrity of every component we ship.
How to Order
- Step 1 — Inquiry: Submit your part number, required quantity, and delivery timeline via our contact form, email ([email protected]), or WhatsApp (+0086 19859288691). We respond within 24 hours on business days.
- Step 2 — Quotation & Documentation: We provide a formal quotation with lead time, unit price, and available documentation (COC, Test Report, photos). Sample units available for qualified buyers upon request.
- Step 3 — Order Confirmation & Shipment: Upon PO or payment confirmation, we prepare the documentation package and dispatch within the agreed lead time. Tracking information and pre-shipment photos are provided for every order.
📧 [email protected] | 📞 +0086 19859288691 | ⏱ 24-hour response guarantee
Authenticity & Trust FAQ
-
Q: How can I verify that the module I receive is genuine Bently Nevada?
A: Every unit we supply comes with a Certificate of Conformance (COC) documenting the source, inspection results, and part number verification. We can also provide pre-shipment photos of the module label, PCB, and packaging. For additional assurance, the module’s firmware revision and hardware markings can be cross-referenced against Bently Nevada’s official documentation upon receipt. -
Q: What is your warranty policy on this module?
A: We provide a 12-month warranty against defects in materials and workmanship from the date of shipment. If a module fails under normal operating conditions within the warranty period, we will repair, replace, or refund at our discretion. Warranty claims are processed within 5 business days of receiving the returned unit. -
Q: Can you provide a test report or inspection certificate before I place an order?
A: Yes. For qualified buyers and larger orders, we can provide a functional test report generated during our bench verification process, along with photographic documentation of the inspection. Please request this at the inquiry stage and we will include it in your quotation package.
